Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail info@apterpower.com
  • Lifecycle Status

    Active / Available from OEM
    Apter Power provides immediate quotations, full technical documentation, and sourcing support for Triconex 4609 modules.

4609

/ 4.9
1001 reviews | Need a Specific Revision?
The Triconex 4609 Advanced Communication Module is a dedicated hardware interface between the Tricon safety controller and the Foxboro I/A Series DCS, operating as a native safety node on the I/A Series Nodebus.
In Stock
Ships by Wednesday, September 30
Fast Shipping Available
Get a quick price for 4609
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 4609

  • Manufacturer:
    Invensys
  • Part Number:
    4609
  • Product Family:
    Triconex
  • Product Type:
    Advanced Communication Module
  • Stock:
    1
  • Module Type:
    Advanced Communication Module (ACM).
  • Nodebus Ports:
    1 BNC connector for RG58 50-ohm thin cable (reserved); 1 15-pin D connector for AUI cable to DNBI; 1 9-pin RS-423 connector for Control Bus to DNBI.
  • NET 2 Port:
    1 BNC connector for RG58 50-ohm thin coaxial cable to Ethernet network.
  • Serial Ports:
    2 x 9-pin serial ports with RS-232/RS-485 protocol support (reserved).
  • Port Isolation:
    500 VDC (Ethernet and RS-232 ports).
  • Communication Speed:
    BNC and 15-pin D connectors: 10 Mbps; 9-pin Nodebus.
  • connector:
    2400 baud
  • Power Module Load:
    20 watts
  • Protocols Supported on NET 2:
    TriStation 1131 software protocol, TSAA protocol for Triconex applications, TSAA/TCP (UDP/IP) for user-written applications on external hosts
  • Module Status:
    PASS, FAULT, ACTIVE
  • Nodebus Activity:
    ONLINE, SBRDY
  • Port Activity:
    TX and RX (1 pair per active port)
  • Hardware Features:
    Node Address rotary switches for TS/TSAA node configuration, hot-spare capability for uninterrupted Nodebus communication
  • Weight:
    2.15 kg
  • Estimated shipping dimensions:
    305 x 30 x 267 mm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Compatibility & Interoperability Configuration & Programming Installation

Features:

  • Dedicated interface connecting Tricon controllers to Foxboro Intelligent Automation (I/A) Series DCS Nodebus networks.
  • Operates at 10 Mbps data rates with 500 VDC galvanic isolation across Ethernet and RS-232 communication interfaces.
  • Features an independent NET 2 BNC port supporting TriStation 1131 programming tools and TSAA/TCP protocols.
The Schneider Triconex 4609 Advanced Communication Module (ACM) is supplied as a factory-tested communication unit designed to establish direct communication between Tricon safety controllers and Foxboro I/A Series DCS platforms.

This communication module executes real-time alarm propagation, system status telemetry, and aliased data exchange using the Object Management Database (OMDB) across plant-wide operator workstations.

Installation requires proper slot positioning within the chassis, support for hardware write protection, and manual node address selection via front-panel rotary switches.

The Triconex 4609 module availability and lead times are subject to stock verification and manufacturer lead times upon order confirmation by the manufacturer (OEM).
Schneider Triconex 4609 Advanced Communication Module Manuals, Datasheets, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Interfacing Tricon safety systems with Foxboro I/A Series DCS networks as a recognized safety node.
  • Propagating safety controller alarms and events to operator consoles and logging printers.
  • Executing high-speed aliased data read and write transfers via the Object Management Database (OMDB).
  • Integrates seamlessly with Foxboro Intelligent Automation (I/A) Series DCS platforms via native Nodebus protocol architecture.
  • Receives direct time synchronization signals broadcast from the connected Foxboro I/A Series system environment.
  • Supports TSAA/TCP (UDP/IP) communication protocols for custom user-written software applications running on external hosts.
  • Incorporates hardware write protection features to lock out unauthorized controller logic changes from external network sources.
  • Features front-panel TS/TSAA Node Address rotary switches for precise manual node ID configuration.
  • Provides hot-spare hardware capability to ensure continuous, uninterrupted communication with the Nodebus during module servicing.
  • Installs into designated communication slots within the Tricon main chassis, interfacing with the I/A Series Nodebus via DNBI cabling.
  • Supports online hot-spare module insertion to maintain active communication link continuity during live hardware servicing.
  • Connects directly to external systems via physical 15-pin D connectors, 9-pin RS-423 serial ports, and 50-ohm BNC Ethernet interfaces.
Description
Schneider Triconex 4609 Advanced Communication Module (ACM) serves as a specialized system interface connecting Tricon safety controllers directly into Foxboro Intelligent Automation (I/A) Series Distributed Control Systems (DCS). Operating as a recognized safety node on the I/A Series Nodebus, this module transfers critical safety variables and diagnostic telemetry at full network data rates to operator workstations in standard display formats. Physical Nodebus connection points include a 15-pin D connector for AUI cable attachment to DNBI and a 9-pin RS-423 serial control bus interface running at 2400 baud.

Engineered to streamline process safety integration, the Triconex 4609 module captures controller alarms and propagates them as standard system messages to user-defined I/A Series consoles and printers. Utilizing the Object Management Database (OMDB), it coordinates aliased data exchanges, accepts system time synchronization from the I/A Series DCS, and provides hardware write protection to block unauthorized logic modifications from external sources. A separate BNC port labeled NET 2 provides 10 Mbps network access for TriStation 1131 software tools and TSAA/TCP protocol applications.

Designed for high-availability industrial safety environments, the Triconex 4609 module incorporates full hot-spare capability to ensure continuous, uninterrupted Nodebus communication during system servicing or module replacement. Dual front-panel rotary switches enable precise manual selection of TS/TSAA node addresses, while clear diagnostic LEDs deliver continuous operational status. Operating with a 20-watt power module load, all Ethernet and serial ports feature 500 VDC galvanic isolation to shield backplane electronics.
Alternative Names
4609-ACM 4609 ACM Tricon 4609 Triconex 4609 Invensys 4609 Schneider Electric 4609 Invensys Tricon 4609 Foxboro IA Interface Triconex 4609 Advanced Communication Module
Technical notes
The Triconex 4609 module includes hardware write protection to lock out unauthorized system changes and features front-panel rotary switches for manual TS/TSAA node address configuration.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does the Triconex 4609 module appear to the connected Foxboro system?
The Triconex 4609 module appears to the Foxboro I/A Series system as a native safety node on the I/A Series Nodebus.
What is the function of the NET 2 port on the Triconex 4609 module?
The NET 2 port on the Triconex 4609 module features a 50-ohm BNC connector used for Ethernet communication with TriStation 1131 software and TSAA protocol applications.
Does the Triconex 4609 module support hot-spare redundancy?
Yes, the Triconex 4609 module features hot-spare capability to ensure continuous and uninterrupted communication with the Foxboro I/A Series Nodebus.
How are node addresses configured on the Triconex 4609 module?
Node addresses on the Triconex 4609 module are configured manually using the front-panel TS/TSAA Node Address rotary switches.
How does the Triconex 4609 module handle alarm messages from the safety controller?
The Triconex 4609 module processes Tricon controller alarms and propagates them as system messages to user-defined I/A Series destinations such as consoles and printers.
How can users inquire about pricing, availability, and technical support for the Triconex 4609 module?
Customers can request an official price quote and technical integration assistance for Triconex 4609 modules by contacting our sales engineering team via email or online request form.
