Triconex 8311 Power Module is a redundant chassis power supply unit designed for Tricon systems, converting line power into regulated DC power for all system modules. It supports online replacement and ensures continuous power delivery for Main, Expansion, and RXM chassis configurations.
Get a quick price for 8311
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 8311

  • Manufacturer:
    Invensys
  • Part Number:
    8311
  • Product Family:
    Triconex
  • Product Type:
    Power Module
  • Nominal Voltage:
    24 VDC
  • Input VAC @ 47-63 Hz:
    n/a
  • Input VDC:
    22-31
  • Fuse Rating and Type:
    15 amps, time-delay
  • Output Hold Time (nominal to 0 volts):
    2.8 ms minimum
  • Diagnostic Indicators:
    PASS, FAULT, ALARM, TEMP, BAT LOW
  • Output Power:
    175 watts at 140°F (60°C)
  • Output Voltage:
    6.5 VDC, ±1% under all operating conditions
  • Output Current:
    27 amps maximum at 140°F (60°C) ambient
  • Weight:
    2.6 kg
  • Estimated shipping dimensions:
    6.1x40.5x17.6cm
  • Tariff Code:
    8517795000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Monitoring Application Scenarios Protection

Features:

  • Redundant dual-module architecture ensures continuous power delivery under full system load conditions
  • Regulated DC output with defined voltage and current limits supports stable chassis operation
  • Integrated diagnostic and alarm functions enable real-time system status monitoring
The Triconex 8311 Power Module is designed for use in Tricon system chassis including Main, Expansion, and RXM configurations. The Triconex 8311 Power Module converts incoming DC power into regulated system power for all connected modules. In industrial control environments, it supports stable power distribution across critical system components. The Triconex 8311 Power Module operates with redundant structure to maintain continuous system operation. It is installed on the left side of the chassis for structured power integration.

Within the system architecture, the Triconex 8311 Power Module provides regulated 6.5 VDC output with controlled current capacity. The Triconex 8311 Power Module supports consistent power delivery under defined temperature and load conditions. Each chassis contains two modules, ensuring one unit can fully support system operation if required. The Triconex 8311 Power Module maintains stable electrical conversion for all system modules. Its design supports continuous industrial operation in safety-critical environments.

The Triconex 8311 Power Module includes built-in diagnostic indicators such as PASS, FAULT, ALARM, TEMP, and BAT LOW for system status monitoring. The Triconex 8311 Power Module triggers alarm contacts under defined fault and configuration conditions. It supports online replacement to minimize system interruption during maintenance. The Triconex 8311 Power Module is designed for long-term operational reliability with controlled power input requirements. Overall, it functions as a core power conversion element within Tricon system architectures.

The 8311 Triconex Power Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Triconex 8311 Power Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Triconex 8311 Power Module Specs

General

  • Manufacturer Triconex
  • Model 8311
  • Condition New Original ready stock
  • Product Family 8310,8312
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Real-time Status Feedback: The panel integrates multi-color LED indicators, instantly displaying input source status, output health, and module over-temperature warnings.
  • Remote Alarm Integration: Supports transmission of power fault signals to the main processor via the rack backplane, enabling second-level fault warnings on the host computer monitoring interface.
  • Load Balancing Tracking: In dual-redundancy configuration, the system automatically monitors the current distribution between the two power modules, ensuring long-term stability of the power supply system.
  • Internal Parameter Diagnosis: Built-in self-diagnostic circuitry continuously monitors internal capacitor status and voltage fluctuations, proactively predicting potential failure risks.
  • Core Rack Power Supply: Provides a stable and reliable 24VDC power supply to the CPU rack of the Tricon control system, ensuring the operation of the system's core.
  • Remote Expansion Station Support: Deployed in distributed cabling I/O expansion racks, providing independent power for remote sensing and signal processing logic.
  • High Availability Industrial Sites: Deployed in chemical and nuclear power plant control cabinets requiring "zero downtime," serving as the power foundation for the entire automation control chain.
  • Critical Interlocking Circuit Power Supply: Provides isolated and regulated safe power to the output circuits of safety systems (such as solenoid valves and relay groups).
  • Automatic Overload Cut-off: When the downstream load current exceeds the safety threshold, the module activates its self-protection mechanism to prevent overheating and potential fire hazards.
  • Redundant Fault-Tolerant Design: Supports parallel operation of two power modules; failure of either module will not cause rack shutdown, ensuring uninterrupted power supply.
  • Input Surge Suppression: Built-in high-performance filtering and lightning protection units effectively resist the impact of instantaneous high-voltage pulses from the power grid on precision electronic components.
  • Reverse Voltage Shielding: Features comprehensive reverse polarity protection to prevent physical damage to hardware caused by wiring errors during installation or maintenance.
Description
The Triconex 8311 Power Module is designed for use in Main, Expansion, and RXM chassis types, operating with a nominal voltage of 24 VDC and an input range of 22–31 VDC. It does not support AC input, and system grounding and power termination are handled through dedicated terminal strips located on the backplane. The Triconex 8311 Power Module provides regulated power conversion for all Tricon system modules.

Each Triconex 8311 Power Module is capable of delivering 6.5 VDC output with ±1% regulation under all operating conditions. It supports a maximum output current of 27 amps at 140°F (60°C) ambient temperature, with an output power rating of 175 watts at the same condition. The module is designed with a minimum output hold time of 2.8 ms when transitioning to 0 volts.

The Triconex 8311 Power Module is configured in a redundant architecture, where each Tricon chassis includes two power modules, and either module can fully support system load at rated temperature. Modules are located on the left side of the chassis and are designed for online replacement without system interruption. The Triconex 8311 Power Module converts incoming line power into DC power suitable for all system components.

Diagnostic functions of the Triconex 8311 Power Module include PASS, FAULT, ALARM, TEMP, and BAT LOW indicators. Alarm contacts are activated when a module is missing, fails, or when configuration conflicts, system faults, primary power failure, low battery, or over-temperature conditions occur. The Triconex 8311 Power Module requires a minimum incoming power rating of 240 watts per supply and supports continuous system monitoring through built-in diagnostic signals.
Alternative Names
3625 4329 3008 3511 3664 4210 8312 3006
Technical notes
Triconex 8311 Power Module, Chassis Type Main/Expansion/RXM, nominal voltage 24 VDC, input 22–31 VDC, no AC input supported, fuse rating 15 amps time-delay, output voltage 6.5 VDC ±1%, output current max 27 amps at 140°F (60°C), output power 175 watts at 60°C, output hold time minimum 2.8 ms, diagnostic indicators PASS FAULT ALARM TEMP BAT LOW, two power modules per Tricon chassis with full load capability, modules located left side of chassis, online replacement supported, incoming power minimum 240 watts per supply, alarm contacts activated under module missing, configuration conflict, module failure, main processor system fault, primary power failure, low battery or over temperature condition.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does the Triconex 8311 handle output regulation?
It maintains 6.5 VDC output with ±1% regulation under all operating conditions.
What happens when a power module fault is detected?
Diagnostic indicators such as FAULT or ALARM are activated, and alarm contacts respond to system conditions.
How is the 8311 Power Module installed in the system?
It is located on the left side of the chassis and can be replaced online without shutting down the system.
Why does the system use two power modules per chassis?
The redundant configuration allows either module to fully support system load, ensuring continuous operation if one module fails.
