    Apter Power distributes authentic system integration components to establish reliable multi-protocol plant network connectivity.

MVI56E-MNET

/ 4.9
1001 reviews | Need a Specific Revision?
The MVI56E-MNET is a Modbus TCP/IP client/server communication module designed for ControlLogix processors, enabling seamless interface with a variety of Modbus-compatible devices.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for MVI56E-MNET
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MVI56E-MNET

  • Manufacturer:
    ProSoft
  • Part Number:
    MVI56E-MNET
  • Product Family:
    ProSoft
  • Product Type:
    Modbus TCP/IP Interface
  • Stock:
    1
  • Ethernet Connector Type:
    RJ45
  • LED Display:
    4-Character Scrolling Display
  • Backplane Current Rating:
    800 mA at 5V DC, 3 mA at 24V DC
  • Operating Shock:
    30 G
  • Non-Operating Shock:
    50 G
  • Operating Temperature:
    32 to 140 degrees Fahrenheit
  • Storage Temperature:
    -40 to 185 degrees Fahrenheit
  • Weight:
    0.26 kg
  • Estimated shipping dimensions:
    3.5x14x14.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Certifications & Standards Temperature & Humidity Range

Features:

  • Modbus TCP/IP Client/Server Communication Interface for ControlLogix Processors
  • Enables Seamless Data Exchange Between ControlLogix and Modbus Compatible Devices
  • Operates in Conjunction with Rockwell Automation ControlLogix Systems and Modbus Networks
The MVI56E-MNET operates as the Modbus TCP/IP Client/Server Communication Module in a ControlLogix rack, providing reliable communication capabilities between the processor and Modbus TCP/IP networks. It continuously facilitates data exchange through a 5000-word register space that transfers information between the ControlLogix processor and connected Modbus compatible devices. Seamless integration is standard with the MVI56E-MNET, allowing direct communication with Modicon Programmable Automation Controllers (PACs) as well as a wide variety of instruments and devices without protocol conversion complexity. The MVI56E-MNET has established robust connectivity solutions for industrial automation environments requiring Modbus TCP/IP protocol support.

The MVI56E-MNET provides essential communication functions common to the entire Modbus network integration, and is a critical component of the data exchange path, directly affecting the proper, normal operation of the overall communication system. One MVI56E-MNET module is required per ControlLogix rack to establish Modbus TCP/IP connectivity. The MVI56E-MNET occupies a standard slot in the ControlLogix rack and interfaces directly with the processor through the backplane connection.

For standard process applications, the MVI56E-MNET delivers full client/server functionality supporting both master and slave operations on the Modbus TCP/IP network. In addition to standard communication operation, the MVI56E-MNET configuration also performs automatic data synchronization. The MVI56E-MNET communication configuration executes data transfer using the internal register mapping specified in the module configuration. Using this method, the MVI56E-MNET continually monitors the data exchange between the ControlLogix processor and Modbus network devices. If the system detects communication requests from either the processor side or the network side, it will automatically process the data transfer and update the corresponding register locations in the 5000-word memory space.

The MVI56E-MNET PROSOFT Communication Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
PROSOFT MVI56E-MNET Communication Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
PROSOFT MVI56E-MNET Communication Module Specs

General

  • Manufacturer PROSOFT
  • Model MVI56E-MNET
  • Condition New Original ready stock
  • Product Family MVI56E-MNETC,MVI56E-MNETCR,MVI56E-MNETXT
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Standard Process Control: Interfacing with Modicon PACs, power monitors, and flow meters.
  • SCADA/DCS Integration: Acting as a server to provide data to higher-level SCADA or DCS systems.
  • Device Polling: Serving as a client to actively poll data from field instruments.
  • Remote I/O: Operating in remote racks via EtherNet/IP or ControlNet.
  • Harsh Environments: The MVI56E-MNETXT variant is specifically designed for extreme environments with caustic conditions.
  • Hazardous Locations: UL and cUL listed for Class I, Division 2, Groups A, B, C, and D.
  • Explosive Atmospheres: ATEX and IECEx certified for use in Category 3 environments (protected against explosive gases).
  • Marine/Offshore: DNV Type Approval Certificate for use on ships and offshore installations.
  • Environmental Standards: Conforms to EN60079-0 and EN60079-15 for applications in extreme temperature and caustic environments (specifically the XT model).
  • Standard Operating Temperature: 0°C to 60°C (32°F to 140°F).
  • Extended Operating Temperature (XT Model): -25°C to 70°C (-13°F to 158°F).
  • Storage Temperature: -40°C to 85°C (-40°F to 185°F).
  • Relative Humidity: 5% to 95% (Non-condensing).
Description
The MVI56E-MNET is a Modbus TCP/IP Client/Server Communication Module specifically designed for Rockwell Automation ControlLogix processors, enabling seamless interface capabilities with a broad range of Modbus compatible devices. This MVI56E-MNET module facilitates communication with Modicon Programmable Automation Controllers (PACs) as well as diverse instruments and devices across industrial networks. Featuring a 5000-word register space, the MVI56E-MNET ensures efficient data exchange between the processor and the Modbus TCP/IP network, supporting robust industrial communication requirements.

The MVI56E-MNET is functionally identical to the MVI56E-MNETXT variant, with the MVI56E-MNET specifically engineered for standard process applications. This MVI56E-MNET module is ideal for manufacturing facilities, process control environments, and automation systems requiring reliable Modbus TCP/IP connectivity. The MVI56E-MNET addresses the critical need for protocol conversion and data integration between Rockwell Automation systems and third-party Modbus devices, eliminating communication barriers in mixed-vendor industrial environments.


 By deploying the MVI56E-MNET, engineers can establish comprehensive network connectivity that bridges ControlLogix processors with existing Modbus infrastructure, ensuring streamlined data flow and enhanced system interoperability without compromising operational efficiency.

Revisions

Revision Part #

Also known as

MVI56E-MNET Ser A
MVI56E-MNET/A, Series A, Rev A
Alternative Names
MVI56E MNET MVI56E-GSC MVI56E-MCM MVI56-CSC MVI56E-MNET/A MVI56E-MNETXT MVI56E-MNETC MVI56E-MNETCR
Technical notes
The ProSoft MVI56E-MNET is a single-slot enhanced Modbus TCP/IP client/server communication module designed to seamlessly connect Rockwell Automation ControlLogix processors to Modbus TCP/IP networks, enabling direct integration with SCADA systems, HMIs, and external PACs.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the MVI56E-MNET module?
The MVI56E-MNET is a Modbus TCP/IP Client/Server communication module designed for Rockwell Automation ControlLogix processors, enabling integration with Modbus-compatible devices.
What types of devices can the MVI56E-MNET communicate with?
It can interface with Modicon PACs, instruments, and various third-party Modbus-compatible devices across industrial networks.
In which environments is the MVI56E-MNET typically used?
It is commonly used in manufacturing plants, process control systems, and industrial automation environments requiring Modbus TCP/IP connectivity.
