IS200BPIAG1A

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IS200BPIAG1A is an IGBT drive bridge personality interface board that links Innovation Series drive control signals with three-phase power electronics.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS200BPIAG1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS200BPIAG1A

  • Manufacturer:
    General Electric
  • Part Number:
    IS200BPIAG1A
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    IGBT Drive Bridge Personality Interface Board
  • Stock:
    1
  • System:
    Innovation Series Drive
  • Functional Acronym:
    BPIA
  • Rack Position:
    VME-type rack, slot 6
  • Backplane Interface:
    P1 connector
  • Phase Connectors:
    APL, BPL and CPL
  • Amplifier Supply Connectors:
    AAPL, BAPL and CAPL
  • Isolated Supplies:
    Nine from three transformers
  • Adjustable Hardware:
    None
  • Fuses and Testpoints:
    None
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Phase Interfaces Isolated Supplies Rack Integration Service Boundaries

Features:

  • Links drive control electronics to a three-phase IGBT power bridge.
  • Separates gate-drive and feedback paths through isolated circuitry.
  • Uses dedicated phase connectors for A, B and C bridge sections.
The board divides the power bridge into three matching phase interfaces, keeping control and feedback routing consistent across the drive.

Nine isolated supplies originate from three transformers, with one transformer group serving each phase.

Board identification and revision information reside in serial memory, while the hardware contains no field adjustments or user testpoints.

Verify the rack slot, bridge phase connectors and revision when matching General Electric IS200BPIAG1A to an Innovation Series drive.
General Electric IS200BPIAG1A IGBT Drive Bridge Personality Interface Board Manuals,Datasheets,Link Important Notice: Confirm the slot-6 assignment and full G1A revision before applying any connected-drive information.

Bridge phase connector assignments

  • Phase A: APL carries the phase-A IGBT interface.
  • Phase B: BPL serves the phase-B power section.
  • Phase C: CPL connects the phase-C IGBT circuitry.
  • Upper Supplies: AAPL, BAPL and CAPL feed the matching upper amplifiers.

How auxiliary power remains separated

  • Transformer Groups: Three transformers divide the auxiliary power by phase.
  • Supply Count: Nine isolated supply outputs are produced on the board.
  • Control Separation: Isolation keeps logic-side circuits apart from bridge potentials.
  • Feedback Return: Isolated VCO paths report bridge current and voltage signals.

Mechanical and backplane positioning

  • Assigned Slot: The faceplate identifies slot 6 as the required rack position.
  • Backplane Link: P1 carries the bridge-control connection into the rack.
  • Mechanical Format: The assembly installs in a VME-type board rack.
  • Board Identity: Serial memory retains the hardware identification and revision record.

Fixed hardware and handling limits

  • User Adjustments: No adjustable hardware is provided.
  • Protection Parts: The board has no replaceable onboard fuses.
  • Measurement Access: User testpoints are not included.
  • Handling: The printed wiring board contains static-sensitive components.
Description
General Electric IS200BPIAG1A is an IGBT Drive Bridge Personality Interface Board for the Innovation Series drive platform. It forms the electrical interface between the control section and the power electronics of a three-phase IGBT bridge.

Six isolated gate-driver paths on IS200BPIAG1A carry phase-control signals, while isolated feedback circuits return bridge-current and voltage information to the control side. This separation lets the drive exchange command and measurement signals without joining the high-power and logic circuits directly.

The phase wiring on IS200BPIAG1A is divided among APL, BPL and CPL connectors for phases A, B and C, with AAPL, BAPL and CAPL assigned to the corresponding upper-amplifier supplies. Three transformers provide nine isolated supplies, maintaining a phase-based power arrangement across the interface.

A P1 backplane connector seats IS200BPIAG1A in slot 6 of a VME-type rack. The board has no adjustable hardware, fuses or user testpoints, and its serial memory stores board-identification and revision data.
Alternative Names
GE IS200BPIAG1A IS200-BPIA-G1A IS 200 BPIA G1A BPIA G1A Interface Board General Electric IS200BPIAG1A Innovation Series IS200BPIAG1A IS200BPIA G1A IS200BPIAGIA
Technical notes
General Electric IS200BPIAG1A connects three-phase IGBT control, isolated feedback and phase-specific driver supplies through a slot-6 VME interface.
