3500/22M 147364-01

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 3500/22M 147364-01 is the legacy 3500 buffered signal output module used to route rack transducer signals for external analysis and condition-monitoring interfaces.
In Stock
Ships by Wednesday, September 30
Fast Shipping Available
Get a quick price for 3500/22M 147364-01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 3500/22M 147364-01

  • Manufacturer:
    Bently Nevada
  • Part Number:
    3500/22M 147364-01
  • Product Family:
    3500 System
  • Product Type:
    Buffered Signal Output Module
  • Stock:
    1
  • Part Number:
    147364-01
  • Installation position:
    Rear rack I/O position
  • System association:
    Legacy 3500/22M TDI arrangement
  • Primary function:
    Buffered transducer-signal routing
  • Monitoring role:
    External analysis and condition-monitoring signal access
  • Primary protection path:
    Not part of the rack's critical monitoring path
  • Mating requirement:
    Must match the installed front TDI and rack generation
  • Grounding requirement:
    Verify rack signal common and instrument-ground arrangement
  • Replacement status:
    Not listed in the current 3500/22M ordering table
  • Associated TDI function:
    Continuous collection of steady-state and transient waveform data
  • Signal source:
    Buffered outputs from compatible 3500 rack monitor channels
  • External destination:
    Compatible condition-monitoring or data-acquisition equipment
  • Channel mapping:
    Defined by installed rack and cable documentation
  • Upgrade control:
    Engineering compatibility review required
  • Associated rack location:
    TDI occupies Slot 1 next to power supplies
  • Documentation family:
    3500/22M Transient Data Interface
  • Weight:
    0.44 lbs (0.2 kg)
  • Estimated shipping dimensions:
    241.3 x 24.4 x 99.1 mm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Signal Routing Rack Integration Lifecycle & Replacement

Features:

  • Routes buffered 3500 rack signals to compatible external acquisition equipment.
  • Occupies the rear interface position associated with a legacy 3500/22M arrangement.
  • Preserves a historical signal-output path not shown in the current TDI ordering table.
The current ordering identity is 3500/22M 147364-01, the legacy Buffered Signal Output Module documented for earlier 3500 TDI installations.

It makes selected buffered transducer signals available outside the rack for condition monitoring or diagnostic acquisition without becoming the primary protection processor.

Before replacement, identify the front TDI, rack revision, rear-slot wiring, signal destinations, grounding and any approved migration components.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Bently Nevada 3500/22M 147364-01:
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Maintains buffered-signal access in legacy 3500 machinery-monitoring racks.
  • Feeds compatible diagnostic or data-acquisition equipment from conditioned transducer channels.
  • Supports like-for-like repair where the rack was originally engineered around part 147364-01.
  • Buffered transducer signals are routed from the rack to compatible external interfaces.
  • Channel destinations must follow the existing rack and cable documentation.
  • Signal common and shielding must preserve the grounding design of the monitoring system.
  • The module belongs in the rear I/O position associated with the documented TDI arrangement.
  • The mating front module and rack generation must be identified before insertion.
  • A 3500/20 RIM rear I/O module must not remain installed when converting a rack to a TDI.
  • Part 147364-01 is not included in the current 3500/22M ordering table.
  • Like-for-like sourcing should be based on the complete part label and rack drawings.
  • Any move to current TDI I/O hardware requires a documented compatibility and rewiring assessment.
Description
3500/22M 147364-01 is the historical Bently Nevada 3500 Buffered Signal Output Module identified in 3500 TDI documentation. It provides rear-rack access to buffered transducer signals rather than performing the primary TDI processing function.

The module belongs to earlier 3500/22M interface arrangements used to deliver conditioned rack signals to compatible external acquisition or diagnostic equipment. Signal routing, grounding and channel assignment depend on the installed TDI generation and rack wiring.

This part is intended for maintenance of legacy 3500 installations that were engineered around the 147364-01 output module. Replacement requires confirmation of the rear slot, mating front module, cable destinations and the approved upgrade path because current 3500/22M ordering tables use different I/O options.
Alternative Names
3500/22M 147364-01 350022M14736401 3500 22M 147364 01 3500/22M 147364-01 Buffered Signal Output Module 3500/22M 147364-01 Buffered Output I/O Module Bently Nevada 147364-01 Bently Nevada 3500 Buffered Signal Output Module Bently Nevada 3500 System Buffered Output I/O Module
Technical notes
3500/22M 147364-01 is not the TDI main module; never substitute it for a current rear I/O option without a documented rack-upgrade and signal-routing review.
