General Electric IS200HFPAG2A is the G2 high-frequency AC/fan power supply board that converts an isolated AC or drive DC-link source into auxiliary AC and fan-power outputs.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS200HFPAG2A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS200HFPAG2A

  • Manufacturer:
    General Electric
  • Part Number:
    IS200HFPAG2A
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    High-Frequency AC/Fan Power Supply Board
  • Stock:
    1
  • Configuration:
    G2
  • AC Input:
    Isolated 230 V ac at ACF1/ACF2
  • DC-Link Input:
    230–1000 V dc at DCF1/DCF2
  • High-Frequency Output:
    52 Vac at 25 kHz
  • Isolated Output:
    19.1 Vac at 25 kHz
  • Fan Supply:
    Unregulated 52 Vdc
  • Combined Load Limit:
    90 VA
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Source Inputs Conversion Path Output Routing Status & Protection

Features:

  • Two defined source interfaces let IS200HFPAG2A accept isolated AC or drive DC-link power.
  • The G2 transformer section supplies separate 52 Vac, 19.1 Vac, and 52 Vdc paths.
  • Independent indicators and four fuses divide supervision across the conversion branches.
IS200HFPAG2A routes its source through a limited buck stage before the self-oscillating inverter excites the transformer.

Connector families on IS200HFPAG2A keep the high-frequency loads, fan supply, and reference conductors assigned to distinct plug pairs.

Because IS200HFPAG2A has no adjustable hardware, installation control centers on source selection, connector allocation, and the aggregate 90 VA boundary.

The General Electric IS200HFPAG2A High-Frequency AC/Fan Power Supply Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IS200HFPAG2A High-Frequency AC/Fan Power Supply Board Manuals, Datasheets, LinksImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Accepted Feed Paths

  • AC pair: ACF1 and ACF2 accept the isolated 230 Vac source.
  • DC pair: DCF1 and DCF2 accept the 230–1000 Vdc link.
  • Alternative feeds: The AC and DC terminals are defined source options for the same assembly.
  • Input protection: Separate fuses protect the AC and DC entry paths.

Power Processing Stages

  • Buck stage: Current and voltage limiting reduce the high-voltage DC input.
  • DC level: The regulated intermediate bus is approximately 118 Vdc.
  • Inverter: A self-oscillating circuit drives the transformer primary.
  • Isolation: Separate transformer windings establish the auxiliary outputs.

Assigned Plug Groups

  • HFPL1/HFPL2: These plugs carry the 52 Vac G2 high-frequency supply.
  • DPPL1/DPPL2: This pair delivers the isolated 19.1 Vac G2 output.
  • FAPL1/FAPL2: Fan-load connections receive the unregulated 52 Vdc supply.
  • FRPL/FRPL1: The reference plugs carry COM48 and FREF conductors.

Branch Supervision

  • DS1: The first green indicator follows the 19.1 Vac output section.
  • DS2: The second green indicator covers the 52 Vac and 52 Vdc sections.
  • FU1–FU4: Four fuses divide protection between source and output branches.
  • Hardware setup: The board contains no configurable jumpers or switches.
Description
General Electric IS200HFPAG2A is the G2 High Frequency AC/Fan Power Supply Board used in a GE drive power-conversion assembly. Its input can be taken from isolated 230 V ac at ACF1/ACF2 or from a 230–1000 V dc link at DCF1/DCF2.

Within IS200HFPAG2A, a current- and voltage-limited buck regulator reduces the dc-link source to an intermediate level of approximately 118 V dc. A self-oscillating inverter then energizes the transformer that separates the auxiliary output windings.

The G2 output set on IS200HFPAG2A comprises 52 Vac and 19.1 Vac square-wave paths at 25 kHz together with an unregulated 52 Vdc fan supply. HFPL, DPPL, FAPL, and FRPL plug pairs assign these outputs and reference connections to different loads, while the combined loading across the board must remain at or below 90 VA.

Output supervision on IS200HFPAG2A is divided between DS1 for the 19.1 Vac path and DS2 for the 52 Vac and 52 Vdc paths. FU1 through FU4 protect the input and output branches, and the board has no configurable hardware items.
Alternative Names
IS200-HFPA-G2A GE IS200HFPAG2A IS200 HFPA G2A General Electric IS200HFPAG2A HFPA G2 AC Fan Power Board IS200HFPA G2A GE HFPA Group 2 Power Supply IS200HFPAGZA
Technical notes
The G2 IS200HFPAG2A converts either of two permitted source paths into separately fused 52 Vac, 19.1 Vac, and 52 Vdc auxiliary outputs.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
The replacement output labels differ from the old board; which values identify IS200HFPAG2A as the G2 configuration?
IS200HFPAG2A uses 52 Vac, 19.1 Vac, and 52 Vdc outputs. Those G2 levels distinguish it from the lower-voltage G1 arrangement.
When DS1 is off but DS2 remains green on IS200HFPAG2A, which branch has been isolated by the indication?
DS1 monitors the 19.1 Vac section of IS200HFPAG2A, while DS2 monitors the 52 Vac and 52 Vdc sections. FU4 belongs to the DS1-monitored output path.
Where should a drive DC-link source be landed on IS200HFPAG2A instead of the isolated AC feed?
Use DCF1 and DCF2 for the 230–1000 Vdc source on IS200HFPAG2A. ACF1 and ACF2 are reserved for the isolated 230 Vac alternative.
Several IS200HFPAG2A outputs sag together even though the branch fuses are intact—what shared limit should be checked?
Add the connected output loads and verify that the combined demand on IS200HFPAG2A does not exceed 90 VA.
A fan harness was connected to an HFPL plug on IS200HFPAG2A; how should the plug families be separated?
FAPL1/FAPL2 carry the IS200HFPAG2A fan supply, HFPL1/HFPL2 carry the 52 Vac path, and DPPL1/DPPL2 carry the isolated 19.1 Vac path.
No setup jumpers are present on IS200HFPAG2A after installation. Is a configuration step missing?
No. IS200HFPAG2A has no configurable hardware; correct source terminals, output plugs, and total loading define the installation boundary.
