Siemens 6ES7677-2DB40-0AA0 is a SIMATIC ET 200SP CPU 1515SP PC2 basic device that provides PC-based controller hardware with PROFINET, Ethernet, USB, and DisplayPort connections.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7677-2DB40-0AA0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7677-2DB40-0AA0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7677-2DB40-0AA0
  • Product Family:
    Siemens Simatic ET 200SP
  • Product Type:
    CPU 1515SP PC2 Basic Device
  • Stock:
    1
  • Hardware Scope:
    Basic device without CFast card or software
  • Main Memory:
    8 GB RAM
  • Rated Supply:
    24 V DC
  • PROFINET Connection:
    1 BusAdapter position
  • Industrial Ethernet:
    1 x RJ45, 10/100/1000 Mbit/s
  • USB 3.0 Interfaces:
    2
  • USB 2.0 Interfaces:
    2
  • Display Interface:
    1 x DisplayPort
  • Removable-Media Slots:
    1 x CFast and 1 x SD/MMC
  • Included Accessories:
    Server module, strain relief, and 24 V DC plug
  • BusAdapter:
    Not included; ordered separately
  • Protection Rating:
    IP20 / open equipment
  • Weight:
    2.229 lbs (1.011 kg)
  • Estimated shipping dimensions:
    14.2x18.9x9.2cm
  • Tariff Code:
    85371091
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Hardware Scope Interfaces Storage Slots ET 200SP Fit

Features:

  • The exact order number is the CPU 1515SP PC2 basic hardware device, not a Windows or Industrial OS bundle.
  • A BusAdapter position provides PROFINET access while a separate RJ45 port carries gigabit Ethernet traffic.
  • Four USB ports, DisplayPort, CFast, and SD/MMC slots connect service peripherals and removable media.
Siemens 6ES7677-2DB40-0AA0 supplies the CPU 1515SP PC2 hardware at the head of an ET 200SP station.

Its hardware scope includes the server module, strain relief, and 24 V DC plug, while CFast, software, and the BusAdapter remain separate selections.

This separation lets the basic unit receive the storage, operating system, controller software, and PROFINET connector required by the final configuration.

Product documentation, quotations, and model-selection support for Siemens 6ES7677-2DB40-0AA0 are available from Apter Power.
Siemens 6ES7677-2DB40-0AA0 CPU 1515SP PC2 Basic Device Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Basic Device Supply Boundary

  • Included unit: The CPU 1515SP PC2 basic device forms the controller and industrial-PC hardware base.
  • Included parts: A server module, strain relief, and 24 V DC plug accompany the basic unit.
  • Excluded storage: The CFast card belongs to a separately selected bundle and is not included here.
  • Excluded software: An operating system and S7-1500 Software Controller are not supplied under this article number.

Separated Network and Peripheral Paths

  • PROFINET path: The BusAdapter position connects the control side to the selected PROFINET physical interface.
  • PC network: The independent RJ45 port handles 10/100/1000 Mbit/s Industrial Ethernet traffic.
  • USB groups: Two USB 3.0 and two USB 2.0 ports accept supported service and peripheral devices.
  • Display output: DisplayPort carries the local video signal to an attached monitor.

Removable-Media Roles

  • CFast slot: A separately ordered CFast card can carry the operating environment and controller bundle.
  • SD/MMC slot: The separate SD/MMC position accepts supported removable media for PC-side use.
  • Order-code check: Storage contents must be identified by the CFast article number rather than the basic-device order number.
  • Service boundary: Removing or replacing media changes the installed software scope but does not change the CPU basic-unit article number.

Station Assembly

  • Mounting position: The basic device installs on the ET 200SP mounting rail at the head of the station.
  • Backplane continuation: The supplied server module closes the configured ET 200SP module chain.
  • Power entry: The supplied two-by-two-pin plug brings 24 V DC into the controller hardware.
  • Connector selection: The separately ordered BusAdapter determines the physical PROFINET connector used by the station.
Description
Siemens 6ES7677-2DB40-0AA0 is the hardware-only CPU 1515SP PC2 basic device for the SIMATIC ET 200SP Open Controller platform. It supplies the industrial PC and controller hardware while leaving the CFast card, operating system, and software controller outside this order number.

Through its BusAdapter position, 6ES7677-2DB40-0AA0 connects the controller side to PROFINET devices. A separate gigabit RJ45 interface carries PC-network traffic, so the two network paths serve different connection roles rather than sharing one port.

Peripheral access on 6ES7677-2DB40-0AA0 is divided among two USB 3.0 ports, two USB 2.0 ports, DisplayPort, an SD/MMC slot, and a CFast slot. The removable-media slots accept the storage required by a selected bundle, but no CFast card or software is included with this basic-device article number.

Mounted at the head of an ET 200SP station, 6ES7677-2DB40-0AA0 receives 24 V DC through the supplied plug and extends the backplane through the included server module. The PROFINET BusAdapter must be selected and ordered separately for the intended network connector type.
Alternative Names
6ES76772DB400AA0 6ES7677 2DB40 0AA0 6ES 7677 2DB40 0AA0 Siemens 6ES7677-2DB40-0AA0 6ES7677-2DB40-0AA0 CPU 1515SP PC2 Basic Device 6E57677-2DB40-0AA0 6ES7677-2D840-0AA0 6ES7677-2DB4O-0AA0
Technical notes
The Siemens 6ES7677-2DB40-0AA0 order number identifies the hardware-only CPU 1515SP PC2 basic device. Its CFast card, software, and PROFINET BusAdapter are selected separately.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does Siemens 6ES7677-2DB40-0AA0 include a CFast card and controller software?
No. Siemens 6ES7677-2DB40-0AA0 is the CPU 1515SP PC2 basic hardware device; its CFast card, operating system, and controller software are ordered separately.
Which parts arrive with 6ES7677-2DB40-0AA0 even though the software bundle is excluded?
The 6ES7677-2DB40-0AA0 scope includes the basic unit, server module, strain relief, and a 24 V DC two-by-two-pin plug.
Why can the RJ45 port on 6ES7677-2DB40-0AA0 not replace the PROFINET BusAdapter connection?
The gigabit RJ45 port on 6ES7677-2DB40-0AA0 serves PC-network traffic, while PROFINET control communication uses the separate BusAdapter position.
What must be ordered before 6ES7677-2DB40-0AA0 can connect to the intended PROFINET cable?
A BusAdapter matching the required connector and media type must be selected separately for 6ES7677-2DB40-0AA0.
How should the correct operating environment be identified for Siemens 6ES7677-2DB40-0AA0?
For Siemens 6ES7677-2DB40-0AA0, verify the separate CFast article number and its installed operating system and software-controller bundle.
What local service connections are available on 6ES7677-2DB40-0AA0?
The 6ES7677-2DB40-0AA0 hardware provides two USB 3.0 ports, two USB 2.0 ports, DisplayPort, and SD/MMC and CFast slots.
