Siemens 6ES7195-7HB00-0XA0 is the BM 2 x 40 bus module for two 40 mm SIMATIC ET 200M I/O modules. It supports removal and insertion of configured modules in an IM 153 station.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7195-7HB00-0XA0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7195-7HB00-0XA0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7195-7HB00-0XA0
  • Product Family:
    Siemens Simatic S7-300
  • Product Type:
    Bus Module
  • Stock:
    1
  • Supported module positions:
    2
  • Operating ambient temperature:
    0 to 60 °C
  • Product function:
    Removal and insertion bus module
  • Station interface:
    SIMATIC ET 200M active backplane bus
  • Module assignment:
    Two S7-300 I/O modules, 40 mm each
  • Mechanical format:
    DIN-rail bus module
  • Siemens product designation:
    SIMATIC DP BM 2x40 bus module for ET 200M
  • Removal and insertion function:
    Supported
  • Spare-part designation:
    Yes
  • eClass 16:
    27-24-26-03
  • ETIM 10:
    EC001598
  • IDEA 4:
    3560
  • UNSPSC 15:
    32-15-17-04
  • Hazardous-location approval:
    FM listed in the Siemens data sheet
  • Marine approvals:
    NK and CCS listed in the Siemens data sheet
  • Weight:
    0.291 lbs (0.132 kg)
  • Estimated shipping dimensions:
    10.30 x 10.30 x 6.80 cm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Installation Compatibility Operating Environment

Features:

  • Carries the ET 200M backplane connection beneath two 40 mm I/O positions.
  • Allows configured modules to be removed and inserted within the supported station arrangement.
  • Uses the BM 2 x 40 format identified by the exact 6ES7 order number.
This ordering configuration is a two-position bus module rather than an active signal-processing card.

It provides the mechanical base and internal bus continuity used by modular ET 200M stations.

Station order, module width and neighbouring bus-module engagement must be checked before the rail is energized.

Apter Power can review sourcing, documentation and system matching for 6ES7195-7HB00-0XA0.
Verified resources for Siemens 6ES7195-7HB00-0XA0: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Process I/O stations requiring exchangeable S7-300 modules can use this two-position active-backplane section.
  • Maintenance-oriented cabinets benefit from replacing an I/O module without dismantling the complete station bus.
  • Expansion layouts use the unit where two adjacent 40 mm module positions are specified in the hardware configuration.
  • The unit snaps into the ET 200M rail arrangement beneath two adjacent I/O modules.
  • Both 40 mm positions must engage correctly with the bus connectors before module insertion.
  • The assembled width is 80 mm in the station even though the loose component measures 97 mm overall.
  • It belongs to ET 200M stations built around the IM 153-1 or IM 153-2 interface family.
  • Only the two-position 40 mm layout matches this bus-module execution.
  • Hardware configuration must reflect the physical slot order used in the installed station.
  • Operation is specified from 0 to 60 °C in the documented ET 200M installation conditions.
  • The component is intended for enclosed industrial control cabinets and the specified mounting rail.
  • Mechanical seating and clean backplane contacts are essential for stable station communication.
Description
6ES7195-7HB00-0XA0 forms a two-position section of the active ET 200M backplane. Its 97 mm body accepts two 40 mm I/O modules and preserves the station bus path through the modular assembly.

The bus module lets a configured I/O position remain part of an ET 200M station while the removable module above it is serviced. This mechanical and electrical arrangement is used where maintenance access must not require rebuilding the complete rail assembly.

Replacement planning must retain the IM 153 station layout, adjacent bus-module order and 40 mm module widths. The BM 2 x 40 identity should be checked directly because other ET 200M bus modules support different module counts or widths.
Alternative Names
6ES7195-7HB00-0XA0 Siemens 6ES7195-7HB00-0XA0 6ES7195 7HB00 0XA0 6ES71957HB000XA0 6ES7195-7HB00-0XA0 Bus Module Siemens SIMATIC ET 200M IM 153-1/153-2 Siemens 6ES7195-7HB00-0XA0 Bus Module
Technical notes
Keep the 6ES7195-7HB00-0XA0 bus-module sequence intact; a wrong module width or position can interrupt the ET 200M backplane path.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What physical slot arrangement does Siemens 6ES7195-7HB00-0XA0 create?
It creates two adjacent ET 200M positions for 40 mm S7-300 I/O modules.
Which station interface must be present before selecting Siemens 6ES7195-7HB00-0XA0?
Use it only in an ET 200M layout engineered for the IM 153-1 or IM 153-2 active backplane.
Why is Siemens 6ES7195-7HB00-0XA0 useful in serviceable remote I/O cabinets?
It supports the documented removal-and-insertion concept without rebuilding the full backplane section.
How should the current lifecycle position affect procurement of Siemens 6ES7195-7HB00-0XA0?
Siemens lists the product in its phase-out lifecycle; obtain an exact-model quotation and plan spares accordingly.
What must remain unchanged during a Siemens 6ES7195-7HB00-0XA0 replacement?
Preserve the rail position, two 40 mm slot assignments, neighbour order and configured ET 200M hardware sequence.
Which evidence is most useful when requesting Siemens 6ES7195-7HB00-0XA0?
Provide the station hardware configuration, interface-module identity, required quantity and destination with the enquiry.
