Vibro-Meter 200-582-500-013 is an earlier VM600 RPS6U AC-input configuration that converts autoranging mains power into the rack +5 V and ±12 V rails.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 200-582-500-013
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 200-582-500-013

  • Manufacturer:
    Vibro-Meter
  • Part Number:
    200-582-500-013
  • Product Family:
    VM600 RPS6U Rack Power Supplies
  • Product Type:
    Rack Power Supply
  • Stock:
    1
  • Nominal input:
    115/230 VAC or 220 VDC
  • Input range:
    90–132 VAC, 180–264 VAC, or 178–264 VDC
  • Input current:
    6.4 A max at 115 VAC; 4 A max at 230 VAC
  • Efficiency:
    84% typical
  • Module type:
    6U rack power supply
  • Maximum output power:
    330 W
  • Nominal output 1:
    +5 VDC up to 50 A
  • Nominal output 2:
    +12 VDC up to 8 A
  • Nominal output 3:
    -12 VDC up to 4 A
  • Ripple and noise:
    <50 mV peak-to-peak, 20 MHz bandwidth
  • Line regulation:
    <±1% for all outputs
  • Load regulation, +5 V:
    <±1%
  • Load regulation, ±12 V:
    <±2%
  • Inrush current:
    <10 times nominal input current
  • System use:
    VM600 machinery protection rack
  • Mounting:
    Dedicated VM600 rack power-supply slots
  • Front status:
    Input and output status indicators
  • Redundant operation:
    Supported with two supplies and correct rear panel
  • Weight:
    4.85 lbs (2.2 kg)
  • Estimated shipping dimensions:
    6 x 19 x 26.1 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Switzerland
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Compatibility Performance Efficiency

Features:

  • Supplies up to 330 W across +5 VDC and ±12 VDC rack rails.
  • Accepts 115/230 VAC or 220 VDC according to the selected input version.
  • Maintains low ripple with specified line and load regulation.
The exact supply configuration is 200-582-500-013, identified for 115/230 VAC or 220 VDC input service.

The module occupies the dedicated RPS6U rack position and distributes three regulated rails through the VM600 backplane.

Verify rear-panel fuse, mains input and early-version front indication before exchanging this 01-series RPS6U.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Vibro-Meter 200-582-500-013: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Powers a VM600 rack containing machinery-protection, communications and relay cards.
  • Supports single-supply installations or approved redundant rack arrangements.
  • Provides regulated low-voltage rails for centralized turbine and rotating-equipment monitoring.
  • The AC version accepts 115 or 230 VAC nominal at 47 to 63 Hz.
  • Input autoranging covers 90–132 VAC and 180–264 VAC without a manual voltage selector.
  • The same front supply can also accept 178–264 VDC when the approved rear panel is used.
  • Factory adjustment establishes +5.41 VDC and ±12.5 VDC under the defined load condition.
  • Line regulation remains below ±1% for all three outputs.
  • Ripple and noise are limited to less than 50 mV peak-to-peak across a 20 MHz bandwidth.
  • Typical conversion efficiency is specified at 84% for the AC-input version.
  • Maximum combined output power is 330 W across the +5 V and ±12 V rails.
  • Rack thermal planning must account for supply losses at the expected card load.
Description
Vibro-Meter 200-582-500-013 Autoranging mains circuitry allows this earlier RPS6U supply to work across documented low-line and high-line AC windows without a manual voltage selector. The converter then produces the regulated +5 V and ±12 V rails required by the installed VM600 card set.

Protection and condition-monitoring electronics benefit from controlled line regulation, load response, and ripple performance as plant voltage or rack demand changes. Conversion efficiency also limits heat released inside the cabinet, making clear airflow an important part of sustained operation.

Replacement planning should distinguish this early front-panel arrangement from later RPS6U designs. Rear input hardware, fuse selection, mains frequency, connector condition, total rack demand, and the existing indication scheme should be reconciled before power is restored.
Alternative Names
200-582-500-013 200 582 500 013 200582500013 Vibro-Meter 200-582-500-013 Meggitt 200-582-500-013 VM600 RPS6U 200-582-500-013 200-582-500-013 Rack Power Supply
Technical notes
200-582-500-013: Verify rear-panel fuse, mains input and early-version front indication before exchanging this 01-series RPS6U.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does 200-582-500-013 accept both 115 and 230 VAC?
Its AC input is autoranging across the documented low-line and high-line voltage windows.
What frequency and current limits apply to 200-582-500-013?
The AC version operates at 47–63 Hz with maximum input current dependent on the selected mains voltage.
Which efficiency value is published for 200-582-500-013?
The data sheet gives 84% typical efficiency for the AC-input RPS6U version.
What should be stated in a 200-582-500-013 purchase request?
Include the full code, mains voltage, early-version rack arrangement, condition, quantity and destination.
How is the front indication on 200-582-500-013 different from later RPS6U units?
Earlier AC versions use an AC input label, while later common front panels use IN for both AC and DC types.
Which rear-panel data must be compared for 200-582-500-013?
Check input type, fuses, filters, switches, earth connection and whether sources are common or individual.
