    Apter Power provides ANR10D pricing, records, sourcing, and dual-ER topology support.

ANR10D-415

/ 4.9
1001 reviews | Need a Specific Revision?
Yokogawa ANR10D-415 Dual-Redundant ER Bus Node Unit for CENTUM VP Remote FIO Node Units.
In Stock
Ships by Saturday, October 31
Fast Shipping Available
Get a quick price for ANR10D-415
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for ANR10D-415

  • Manufacturer:
    Yokogawa
  • Part Number:
    ANR10D-415
  • Product Family:
    Centum CS-Centum VP
  • Product Type:
    Dual-Redundant ER Bus Node Unit
  • Stock:
    1
  • Bus Type:
    dual-redundant ER bus
  • Node Role:
    remote FIO node
  • Power Configuration:
    dual-redundant
  • Power Input:
    100-120 V AC, 50/60 Hz
  • I/O Capacity:
    up to 8 I/O modules
  • Weight Basis:
    approximately 10 kg, including eight I/O modules
  • Weight:
    22.05 lbs (10 kg)
  • Estimated shipping dimensions:
    482.6 x 146 x 221.5 mm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    Japan
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Dual ER Node Remote Topology ER Hardware

Features:

  • Bus Type: dual-redundant ER bus
  • Node Role: remote FIO node
  • Power Configuration: dual-redundant
This ordering code identifies dual-ER-bus remote node with redundant power modules, 100-120 V AC input, and basic non-explosion configuration.

Matched EB401 master hardware connects the remote rack through two redundant ER Bus paths.

Verify YCB146, EB401 master slots, total node count, insulating partitions, and the /NDEL requirement.

Availability of ANR10D-415 is subject to Apter Power inventory and sourcing confirmation.
Yokogawa ANR10D-415 Specifications

General

  • ManufacturerYokogawa
  • ModelANR10D-415
  • ConditionNew and factory sealed
  • Product FamilyCentum CS-Centum VP
  • Interfaces: two ER-bus slave paths
  • Power: two supply modules
  • Use: remote FIO collection and transmitter power
  • Masters: pair with supported EB401 master hardware
  • Nodes: up to eight remote nodes on each ER bus
  • FCU: observe total local and remote node limits
  • Connector: YCB146 T-type ER Bus connector is supplied
  • Consumption: 200 VA maximum at 100-120 V AC
  • Weight: approximately 10 kg including eight I/O modules
Description
Yokogawa ANR10D-415 is a remote FIO node unit with dual-redundant ER bus communication.

Two ER paths connect supported remote I/O to matched EB401 master hardware, with redundant power in the node rack.

Confirm the T-type connector, master-slot arrangement, /NDEL requirement, and total local-plus-remote node count.
Alternative Names
ANR10D415 ANR10D 415 Yokogawa ANR10D-415 ANR10D-415 Dual-Redundant ER Bus Node Unit ANR10D-415 CENTUM VP
Technical notes
ANR10D-415 provides dual-redundant ER communication and redundant power. Its 10 kg weight includes eight I/O modules.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does ANR10D-415 differ from ANR10S-415?
ANR10D provides dual-redundant ER-bus communication instead of a single ER bus.
Are both power and communications redundant?
Yes. The model combines dual ER-bus paths with redundant power modules.
What is the maximum remote-node count per ER bus?
The official limit is eight remote nodes per ER bus.
Which field terminals supply the rack?
Power and grounding use the M4 connections defined for the node unit.
Can barrier-equipped I/O be installed without separation hardware?
No. Yokogawa requires the specified insulating partition.
What does the 5 environmental code identify?
It identifies the basic non-explosion-protected type.
