  • Lifecycle Status

    Discontinued

    Discontinued date: 2022-12-31

    Replacement category: Functional Replacement

    Functional replacement: 2198-E1007-ERS

2071-AP8

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 2071-AP8 is a discontinued Kinetix 3 800 W single-axis component servo drive for 220 V AC indexing applications.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 2071-AP8
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2071-AP8

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2071-AP8
  • Product Family:
    Kinetix Servo Drive
  • Product Type:
    Kinetix 3 Component Servo Drive
  • Stock:
    1
  • Input Voltage:
    170…264 V rms
  • Input Phase:
    Single-phase or three-phase
  • Input Frequency:
    47…63 Hz
  • Mains Input Current:
    10.52 A single-phase; 6.25 A three-phase
  • Continuous Output Power:
    0.80 kW
  • Continuous Output Current:
    5.05 A rms
  • Continuous Output Current (0-pk):
    7.07 A
  • Peak Output Current:
    14.99 A rms
  • Peak Output Current (0-pk):
    21.21 A
  • Nominal Bus Voltage:
    311 V DC
  • Internal Shunt Resistance:
    30 Ω
  • Internal Shunt Power:
    70 W continuous; 700 W peak
  • Bus Capacitance:
    1170 µF
  • Energy Absorption:
    39 J
  • Operating Temperature:
    0…50 °C
  • Maximum Feedback Cable Length:
    30 m
  • Dimensions:
    8.1 × 15.5 × 19.86 cm
  • Weight:
    1.75 kg
  • Tariff Code:
    8503009090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Input Shunt Mounting Application
  • Kinetix 3 single-axis drive supporting single-phase or three-phase input
  • Includes internal regenerative-energy absorption for the documented duty
  • Uses supported programming, feedback, and I/O breakout accessories
2071-AP8 supplies one compatible servo axis and supports the two documented input-phase arrangements within the Kinetix 3 platform.

The drive combines indexing functions, controller communication, motor feedback, machine I/O, and an internal shunt circuit in one coordinated component-drive installation.

Select the input-phase arrangement and verify branch protection, motor-feedback compatibility, regenerative duty, mounting hardware, cable clearance, parameter archive, and controller settings.

Availability, condition, price, and shipping time for 2071-AP8 are confirmed during quotation.

Allen-Bradley 2071-AP8 Kinetix 3 Component Servo Drive Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The documented supply range supports single-phase or three-phase connection
  • Input wiring and protective devices must match the selected phase arrangement
  • Control-power and mains connections are checked independently
  • The internal shunt resistance is 30 Ω
  • Continuous shunt power is rated 70 W
  • Peak shunt power is rated 700 W
  • The official enclosure uses M5 mounting holes
  • Connector access must be included in the enclosure layout
  • Top, bottom, and cable-bend clearances follow the installation drawing
  • Single-axis indexers that require the higher-output Kinetix 3 frame
  • Machines supplied from an approved single-phase or three-phase source
  • Replacement projects with verified controller, motor, feedback, cabling, and regenerative duty
Description
2071-AP8 is an Allen-Bradley Kinetix 3 component servo drive for one 800 W indexing axis and supports 170…264 V rms single-phase or three-phase input power.

The drive provides 5.05 A rms continuous and 14.99 A rms peak output. Its documented configuration includes a 30 Ω internal shunt, 70 W continuous shunt power, 1170 µF bus capacitance, and 39 J energy absorption.

Before installation or replacement, confirm the selected input phase, motor-feedback combination, regenerative duty, M5 mounting requirements, cable clearances, parameter archive, controller settings, grounding, and branch protection.
Alternative Names
2071-AP8 2071AP8 2071 AP8 Allen-Bradley 2071-AP8 Allen Bradley 2071-AP8 AB 2071-AP8 Rockwell Automation 2071-AP8 Kinetix 3 2071-AP8
Technical notes
Confirm single- or three-phase input, motor-feedback compatibility, internal-shunt duty, M5 mounting, cable clearances, parameter backup, and branch protection.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can Allen-Bradley 2071-AP8 be supplied from either single-phase or three-phase power?
Yes. Rockwell Automation rates the 2071-AP8 for 170…264 V rms single-phase or three-phase input. Size branch protection and wiring for the selected phase arrangement and documented input current.
How should the internal shunt of Allen-Bradley 2071-AP8 be evaluated?
The official data lists a 30 Ω internal shunt rated 70 W continuously and 700 W peak. Compare those limits with the actual regenerative energy and repeated deceleration duty.
Which mounting hardware is documented for Allen-Bradley 2071-AP8?
The official installation drawing uses M5 mounting holes for the 81.0 mm wide enclosure. Confirm the full 155.0 mm height, 198.6 mm depth, and connector clearances.
Which breakout boards are supported with Allen-Bradley 2071-AP8?
Rockwell Automation lists the 2071-TBMF motor-feedback breakout board and 2071-TBIO I/O breakout board for Kinetix 3 installations. Match all signals to the machine drawings.
Where can firmware for Allen-Bradley 2071-AP8 be obtained?
Rockwell Automation provides Kinetix 3 firmware through its Product Compatibility and Download Center. Record the installed firmware and save the parameter file before updating or replacing the drive.
What changes should be expected when replacing Allen-Bradley 2071-AP8 with 2198-E1007-ERS?
The listed replacement is functional. Re-engineer the controller integration, motor-feedback interface, cabling, safety, mounting, supply, and tuning rather than treating it as plug compatible.
What documentation should accompany an Allen-Bradley 2071-AP8 inquiry?
Include the exact catalog number, nameplate photographs, input phase, motor and feedback catalog numbers, cable and breakout-board references, quantity, condition, and destination.
