1734-IE4S

/ 4.9
1001 reviews | Need a Specific Revision?
Validated analog safety functions can acquire supervised current or voltage signals through the four POINT Guard I/O channels of 1734-IE4S.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1734-IE4S
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1734-IE4S

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1734-IE4S
  • Product Family:
    Point I/O 1734
  • Product Type:
    POINT Guard I/O Four-Channel Safety Analog Input Module
  • Stock:
    1
  • Safety analog inputs:
    4 channels
  • Current ranges:
    0...20 mA and 4...20 mA
  • Voltage ranges:
    -10...10 V and -5...5 V
  • Input resolution:
    24 bits
  • Terminal-base requirement:
    Two supported POINT I/O terminal bases
  • Operating temperature:
    -20...55 °C
  • Weight:
    0.068 kg
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Safety Inputs Terminal Setup Proof Testing Product Applications

Features:

  • Four safety analog channels: current and voltage input support
  • Diagnostic acquisition: channel and sensor-power status for the safety task
  • POINT Guard I/O integration: distributed analog inputs for supported GuardLogix systems
1734-IE4S extends POINT Guard I/O from discrete safety signals to four analog measurement channels.

Its value depends on the complete safety architecture, including the selected sensor, channel mode, wiring, diagnostics, logic, and proof-test interval.

Two terminal bases, field power, keying, firmware, safety ownership, and validated project records should be treated as one installation package.

Availability of 1734-IE4S is subject to Apter Power inventory and sourcing confirmation.
Allen-Bradley 1734-IE4S POINT Guard I/O Four-Channel Safety Analog Input Module Manuals, Datasheets, and Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Input mode: select the documented current or voltage range.
  • Channel architecture: configure single or dual-channel equivalent operation from the safety design.
  • Sensor power: route and supervise power without back-feeding the module output.
  • Acceptance: test normal values, limits, faults, and the required machine response.
  • Terminal bases: install the required two supported bases with correct keying.
  • Field power: apply the documented supply during operation and firmware update.
  • Firmware: reconcile module revision with the approved safety project.
  • Ownership: restore the correct safety network number and signature records.
  • Stimulus: apply traceable current or voltage values at each configured range.
  • Channel response: record measured data, status, fault detection, and safe-state behavior.
  • Logic path: verify the safety task, signatures, and reaction time with the actual project.
  • Records: retain calibration, wiring, firmware, test results, and approval responsibility.
  • Safety pressure: acquire supported analog transmitters within a validated function.
  • Safety position: monitor analog displacement or position signals where the system design permits.
  • Process protection: bring current or voltage measurements into GuardLogix safety logic.
  • Distributed safety: locate safety analog acquisition in a supported POINT Guard I/O station.
Description
Safety-related transmitters can be brought into a GuardLogix architecture through 1734-IE4S when the complete sensor, wiring and logic path is validated. The four analog channels support the documented current and voltage modes together with status and diagnostic information.

A safety measurement using 1734-IE4S may use an approved single-channel or dual-channel equivalent arrangement. Sensor-power supervision and channel diagnostics help reveal faults, but neither feature replaces the application risk assessment, project signature or required proof test.

Installation of 1734-IE4S must preserve the supported terminal-base arrangement, keying, field power and safety ownership. After replacement or firmware work, the site procedure should challenge the actual sensors, channel ranges, fault reactions and safe-state response before operation resumes.
Revisions

Revision Part #

Also known as

1734-IE4S Series A
1734-IE4S/A, Series A
Alternative Names
Allen-Bradley 1734-IE4S Rockwell Automation 1734-IE4S AB 1734-IE4S 1734IE4S 1734 IE4S POINT Guard I/O four-channel safety analog input
Technical notes
Back-feeding a sensor-power output is the critical wiring risk for 1734-IE4S. When a transmitter has an external supply, follow the approved circuit and keep that source off the module output; verify commons, channel configuration and fault response before applying the safety signature and authorizing the proof test.
