1747-OCPCM2

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1747-OCPCM2 is an Open Controller PCMCIA interface kit combining 1747-OCPCM1 hardware with CardSoft for DOS.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1747-OCPCM2
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1747-OCPCM2

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1747-OCPCM2
  • Product Family:
    SLC 500
  • Product Type:
    Open Controller PCMCIA Interface Module Kit
  • Stock:
    1
  • Interface Standard:
    PCMCIA 2.1-compatible PC Cards
  • Kit Hardware:
    1747-OCPCM1 interface module
  • Included Software Component:
    SystemSoft CardSoft for DOS
  • Card/Socket Services:
    DOS and Windows 3.x support documented
  • Installation Position:
    Open Controller PCI expansion-bus slot, not a standard 1746 I/O slot
  • Backplane Current:
    0.15 A at 5 V DC, excluding installed PC Card
  • Operating Temperature:
    0…60°C
  • Storage Temperature:
    -40…85°C
  • Relative Humidity:
    5…95%, noncondensing
  • Operating Shock:
    30 g peak for 11 ms
  • Storage Shock:
    50 g peak for 11 ms
  • Weight:
    0.227 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Kit Contents PC Card Support Installation Application
  • Open Controller PCMCIA interface module kit
  • Supports PC Cards conforming to PCMCIA 2.1
  • Includes 1747-OCPCM1 hardware plus CardSoft for DOS

1747-OCPCM2 is intended for maintaining legacy Open Controller systems that rely on removable PC Card media or PCMCIA-based communication hardware.

Its supplied CardSoft for DOS services support card recognition, but actual operation still depends on the installed card, compatible drivers, and the controller’s existing software environment.

For a controlled replacement, record the PCI position, cabling, card type, driver set, socket-services configuration, and available 5 V capacity before disturbing the assembly.

Availability, condition, price, and shipping time for 1747-OCPCM2 are confirmed during quotation.

Allen-Bradley 1747-OCPCM2 Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The kit contains the 1747-OCPCM1 interface hardware
  • CardSoft for DOS is the documented software component
  • A CardSoft documentation disk is included in the original kit description
  • Supported cards must conform to PCMCIA 2.1
  • Card and socket services connect system software to the socket adapter
  • The selected PC Card still requires compatible drivers and operating-system support
  • The module uses an Open Controller PCI expansion slot
  • It cannot occupy a normal 1746 I/O slot
  • Power calculations must include the interface and the installed PC Card
  • DH+ or DH-485 access through a compatible 1784-PCMK PC Card
  • DeviceNet link configuration through a compatible 1784-PCD PC Card
  • Ethernet connectivity through a compatible Ethernet PC Card and protocol drivers
Description
1747-OCPCM2 adds PC Card capability to a legacy Allen-Bradley Open Controller through its dedicated PCI expansion architecture.

The kit combines the interface hardware with CardSoft for DOS, while the installed PC Card and its network or storage drivers remain application-specific.

Before replacement, identify the PC Card, operating system, CardSoft and socket services, driver files, PCI slot, cables, and total 5 V load.
Alternative Names
1747-OCPCM2 1747 OCPCM2 1747OCPCM2 Allen-Bradley 1747-OCPCM2 Allen Bradley 1747-OCPCM2 Rockwell Automation 1747-OCPCM2 Open Controller 1747-OCPCM2
Technical notes
1747-OCPCM2 requires a compatible Open Controller PCI slot, PCMCIA 2.1 card, CardSoft/socket services, OS drivers, and power budget; a standard 1746 I/O slot is incompatible.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does Allen-Bradley 1747-OCPCM2 include the PC Card needed for the intended network?
The documented kit provides the 1747-OCPCM1 interface hardware and CardSoft for DOS; the application-specific network or storage PC Card must be confirmed separately in the stock description.
Can Allen-Bradley 1747-OCPCM2 be installed in a normal 1746 I/O slot?
No. Open Controller option modules belong in the dedicated PCI expansion-bus slots and cannot be placed in standard 1746 I/O slots.
Which PC Cards can Allen-Bradley 1747-OCPCM2 accept?
The official system overview states that the interface supports cards adhering to PCMCIA 2.1; the card and its drivers must also be compatible with the installed card/socket services and OS.
Can Allen-Bradley 1747-OCPCM2 provide DH+ or DH-485 communication?
It can host a compatible 1784-PCMK PC Card for those networks, but the card, drivers, API software, and network cable are separate selection items.
Can Allen-Bradley 1747-OCPCM2 be used for DeviceNet configuration?
Rockwell documents a 1784-PCD Card in a PCMCIA module for configuring a DeviceNet link when Windows is running on the Open Controller.
Can Allen-Bradley 1747-OCPCM2 add Ethernet connectivity?
Yes, with a compatible Ethernet PC Card plus its card, socket, network, and protocol drivers; verify OS and application compatibility before purchase.
Why might Allen-Bradley 1747-OCPCM2 detect the interface module but not the inserted PC Card?
Check that the card conforms to the supported PCMCIA standard, is fully seated, and has compatible CardSoft, socket services, operating-system drivers, and available 5 V power; recognizing the interface alone does not confirm card support.
