  • Lifecycle status

    Active / Available from OEM
    Apter Power provides quotation, technical references, sourcing, and 11 mm component matching.

330701-00-10-10-02-00

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330701-00-10-10-02-00 is a stocked 1/2-20 unarmored 3300 XL 11 mm probe with a 1.0-inch case, 1.0 m standard cable and no approval option.
In Stock
Ships by Wednesday, September 30
Fast Shipping Available
Get a quick price for 330701-00-10-10-02-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330701-00-10-10-02-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330701-00-10-10-02-00
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Product Type:
    Proximity Probe
  • Stock:
    1
  • Thread:
    1/2-20 UNF
  • Armor:
    Without armor
  • Unthreaded length:
    0.0 in
  • Overall case length:
    1.0 in
  • Total probe length:
    1.0 m (3.3 ft)
  • Connector and cable:
    02 = ClickLoc connector, standard cable
  • Connector protector:
    Not included by option 02
  • Agency approval:
    00 = Not required
  • Stocked configuration:
    Listed by Baker Hughes as a commonly stocked probe
  • System linear range:
    4.0 mm (160 mils)
  • Nominal scale factor:
    2.0 V/mm (50 mV/mil)
  • Measurement frequency range:
    0 to 8 kHz
  • Reference target:
    AISI 4140 steel, 31 mm minimum diameter
  • System power:
    -17.5 to -26 VDC without barriers; 12 mA maximum
  • Output resistance:
    50 ohms
  • Extension-cable capacitance:
    69.9 pF/m typical
  • Maximum field-wire length:
    305 m (1000 ft)
  • Probe-to-cable pull strength:
    330 N (75 lb)
  • Connector family:
    Gold-plated brass ClickLoc
  • Standard calibration:
    AISI 4140 steel
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Integration Efficiency Temperature & Humidity

Features:

  • Uses a compact 1.0-inch case with 1/2-20 UNF mounting threads.
  • Includes a 1.0 m unarmored standard cable and ClickLoc connector.
  • Appears in the official commonly stocked 3300 XL 11 mm probe list.
The current ordering configuration is 330701-00-10-10-02-00, the 1/2-20 unarmored probe with zero unthreaded length, 1.0-inch case and 1.0 m standard cable.

It forms the sensing end of a 3300 XL 11 mm system used for radial vibration, axial position or timing-reference measurements.

Before fitting, confirm the short case reaches the target correctly, protect the unarmored lead, match the system length and avoid relying on approvals not selected by suffix 00.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Bently Nevada 330701-00-10-10-02-00:
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Fits shallow 1/2-20 probe ports where the one-inch case provides the required reach.
  • Acquires non-contact displacement for shaft position and vibration monitoring.
  • Generates timing-reference information from an appropriate rotating target.
  • Use only matching 3300 XL 11 mm extension-cable and Proximitor Sensor components.
  • The one-metre probe may connect directly or through the extension required by the selected system length.
  • Configure the connected monitor for the 3300 XL 11 mm transducer type and scale factor.
  • The commonly stocked ordering code can simplify exact replacement planning for the standard configuration.
  • The short one-inch case minimizes unused insertion length in compact bearing housings.
  • ClickLoc engagement provides a repeatable coaxial connection without threaded coupling hardware.
  • The applicable probe temperature limit depends on the selected cable and the 11 mm datasheet conditions.
  • Protected connectors support 100% condensing humidity while the assembly remains non-submersible.
  • Keep the junction sealed because option 02 does not include a connector protector.
Description
330701-00-10-10-02-00 is a compact 1/2-20 UNF probe in the Bently Nevada 3300 XL 11 mm transducer system. The configuration has no unthreaded tip section and uses a one-inch overall case for short mounting depths.

A one-metre unarmored standard lead terminates in the miniature coaxial ClickLoc connector. The ordering table lists this exact configuration among the commonly stocked 11 mm probes and assigns no agency approval option.

The probe supports non-contact position, vibration and phase-reference measurements when combined with the matching sensor and extension arrangement. Mechanical fit, target material and complete electrical length must be maintained during replacement.
Alternative Names
330701-00-10-10-02-00 3307010010100200 330701 00 10 10 02 00 330701-00-10-10-02-00 3300 XL 11 mm Proximity Probe 330701-00-10-10-02-00 1/2-20 UNF Proximity Probe 330701-00-10-10-02-00 1.0 m Unarmored Probe 330701-00-10-10-02-00 ClickLoc Proximity Probe Bently Nevada 3300 XL 11 mm Proximity Transducer System
Technical notes
330701-00-10-10-02-00 has an unarmored lead and no connector protector; secure and seal the cable junction before returning the machine to service.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why is 330701-00-10-10-02-00 classed as a compact probe?
Its code selects zero unthreaded length and a 1.0-inch overall case, the minimum threaded-case length in this family.
Is 330701-00-10-10-02-00 one of the listed stocked configurations?
Yes. Datasheet 146256 lists this complete part number among the commonly stocked 3300 XL 11 mm probes.
Which thread must a 330701-00-10-10-02-00 mounting port provide?
The port must accept the specified 1/2-20 UNF probe thread and allow the required sensing gap.
Can the 00 approval suffix on 330701-00-10-10-02-00 be treated as hazardous-area certified?
No. The ordering table defines 00 as approval not required, so no other variant's approval should be borrowed.
What cable risk is specific to 330701-00-10-10-02-00?
Its one-metre lead is unarmored and option 02 omits a protector, so routing and junction sealing need deliberate protection.
What information should be submitted for a 330701-00-10-10-02-00 quote?
Provide the complete part number, required quantity, installed Proximitor number, extension length and destination.
