    For 330190-080-00-05, Apter Power provides quotations, datasheets, and 3300 XL 8 mm system matching.

330190-080-00-05

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330190-080-00-05 is an 8.0 m 3300 XL extended-temperature extension cable that links a proximity probe to the matching Proximitor Sensor.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for 330190-080-00-05
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330190-080-00-05

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330190-080-00-05
  • Product Family:
    3300 XL 8mm Proximity Transducer System
  • Product Type:
    3300 XL 8 mm Extended-Temperature Extension Cable
  • Stock:
    1
  • Cable Length:
    8.0 m (26.2 ft)
  • Cable Option:
    Standard cable
  • Insulation:
    PFA
  • Conductor Geometry:
    Triaxial
  • Characteristic Impedance:
    75 Ω
  • Maximum Cable Temperature:
    260°C (500°F)
  • Connector System:
    Miniature coaxial ClickLoc
  • Agency Approvals:
    CSA, ATEX, and IECEx
  • System Length Rule:
    Probe length + extension cable length = Proximitor total length
  • Tariff Code:
    9031809090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Cable Construction Temperature Limits System Matching Certifications

Features:

  • The 080 code provides an 8.0 m extended-temperature cable length.
  • PFA-insulated 75 Ω triaxial construction carries the transducer signal.
  • The 05 suffix combines CSA, ATEX, and IECEx approvals.
The full ordering number separates this ETR extension cable from standard-temperature and differently sized 3300 XL cable assemblies.

Its position between the probe lead and Proximitor Sensor extends the electrical path without changing the required system-length match.

System configuration must coordinate cable length, probe length, sensor calibration, and the accuracy class introduced by ETR components.

The Bently Nevada 330190-080-00-05 Extended-Temperature Extension Cable may be available with quotation and technical support from Apter Power.
Bently Nevada 330190-080-00-05 Extended-Temperature Extension Cable Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Electrical assembly

  • Insulation: PFA surrounds the conductors in the extended-temperature cable.
  • Geometry: The signal path uses triaxial cable construction.
  • Impedance: Characteristic cable impedance is 75 Ω.
  • Termination: Miniature coaxial ends support the 3300 XL ClickLoc connection system.

Extended-temperature limits

  • Cable maximum: The extension cable is rated to 260°C.
  • Insulation system: PFA supports the ETR cable construction.
  • Accuracy class: Any ETR component sets the assembled system to ETR accuracy.
  • Mixed components: ETR cable can be combined with standard-temperature 3300 XL components within the documented matching rules.

Length coordination

  • Extension section: The 080 code assigns an 8.0 m cable length.
  • Length equation: Probe length plus extension-cable length must equal the system total.
  • Sensor selection: The Proximitor Sensor length must match that combined value.
  • System family: Component selection remains within the 3300 XL 8 mm transducer system.

Approval option details

  • Ordering code: The final 05 suffix selects the approved cable option.
  • CSA: Canadian Standards Association approval is included.
  • ATEX: The cable carries the corresponding European hazardous-area approval.
  • IECEx: International electrotechnical hazardous-area certification is included.
Description
Bently Nevada 330190-080-00-05 is an extended-temperature-range extension cable for the 3300 XL 8 mm Proximity Transducer System. It completes the signal connection between the probe lead and the matching Proximitor Sensor.

The 080 length code gives 330190-080-00-05 an 8.0 m cable length, while the 00 option selects standard cable construction. The assembly uses PFA insulation around 75 Ω triaxial cable, preserving the electrical path specified for the transducer system.

At each end, 330190-080-00-05 uses miniature coaxial connectors designed for the 3300 XL ClickLoc connection system. During configuration, the extension-cable length and the probe length must add up to the total length selected for the Proximitor Sensor.

The extended-temperature construction allows 330190-080-00-05 to operate at cable temperatures up to 260°C. ETR cable and standard-temperature 3300 XL components can be combined within the documented system rules, while any ETR component sets the system accuracy to the ETR accuracy specification. The final 05 code identifies CSA, ATEX, and IECEx approvals.
Alternative Names
330190-080-00-05 330190 080 00 05 3301900800005 Bently Nevada 330190-080-00-05 Baker Hughes 330190-080-00-05 BN 330190-080-00-05 3300 XL ETR 330190-080-00-05 33O190-080-00-05
Technical notes
Bently Nevada 330190-080-00-05 is an 8.0 m standard 3300 XL ETR extension cable with PFA insulation, 75 Ω triaxial construction, and CSA, ATEX, and IECEx approvals.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Does 330190-080-00-05 provide an 8.0 m extension length?
The 080 segment specifies that Bently Nevada 330190-080-00-05 is 8.0 m (26.2 ft) long. Use that value when calculating the complete probe-and-extension-cable length.
Which cable construction is represented by 00 in 330190-080-00-05?
For 330190-080-00-05, the 00 option identifies standard cable construction rather than an armored or FluidLoc cable option.
What total-length check is required before installing 330190-080-00-05?
Select 330190-080-00-05 only when its 8.0 m length plus the chosen probe length equals the total length marked for the 3300 XL Proximitor Sensor. The system length must match as a complete set.
Can 330190-080-00-05 remain in a 260°C cable zone?
Bently Nevada 330190-080-00-05 is an ETR extension cable rated for cable temperatures up to 260°C (500°F). If an ETR component is used, apply the ETR accuracy limits to the complete system.
How are the connectors on 330190-080-00-05 locked?
The miniature coaxial connectors on 330190-080-00-05 use the 3300 XL ClickLoc locking arrangement. Join the clean mating connectors finger-tight and engage the locking sleeve without applying tool torque to the connector body.
Does 330190-080-00-05 include hazardous-area approvals?
The final 05 segment of 330190-080-00-05 identifies the CSA, ATEX, and IECEx approval option. Confirm that the approval drawing matches the hazardous-area installation.
