IS200STCIH1A

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IS200STCIH1A is a Mark VIe simplex contact input terminal board that connects 24 fixed-terminal dry-contact channels to a PDIA I/O pack.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS200STCIH1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS200STCIH1A

  • Manufacturer:
    General Electric
  • Part Number:
    IS200STCIH1A
  • Product Family:
    GE Mark VIe Distributed I/O
  • Product Type:
    Simplex Contact Input Terminal Board
  • Stock:
    1
  • Number of Channels:
    24 dry-contact voltage input channels
  • Excitation Voltage:
    H1: nominal 24 V DC floating, 18-32 V DC (fixed terminal block)
  • Input Current:
    Channels 1-21: 2.5 mA each (50 kΩ); channels 22-24: 10 mA each (12.5 kΩ)
  • Input Filter:
    Hardware filter, 4 ms
  • Fault Detection:
    Loss of contact input excitation voltage; non-responding contact input in test mode
  • AC Voltage Rejection:
    12 V rms at 24 V DC excitation
  • Size / Technology:
    15.9 × 10.2 cm (6.25 × 4.0 in.); surface-mount
  • Temperature:
    -30 to +65 °C (-22 to 149 °F)
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Fixed Terminal Wiring Wetting Supply PDIA Interface Noise Rejection

Features:

  • Terminates 24 dry-contact channels on a fixed 52-position block.
  • Connects one PDIA I/O pack to the Mark VIe Ethernet controller.
  • Suppresses field-side surge and high-frequency input noise.
STCIH1A brings field contacts, excitation, grounding, and pack connectivity together on a compact simplex assembly.

The fixed terminal style suits installations where field wiring remains landed while the PDIA pack is handled at its D-type connector.

Input wiring is organized around a floating 24 V DC source, with shield and SCOM grounding kept on their designated chassis points.

The General Electric IS200STCIH1A Simplex Contact Input Terminal Board may be available for purchase and support from Apter Power.
General Electric IS200STCIH1A Simplex Contact Input Terminal Board Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

H1A Field Connections

  • Terminal style: A permanent 52-position block receives the contact wiring.
  • Channel count: Twenty-four field contacts terminate on the assembly.
  • Conductor size: Typical installation wiring uses #18 AWG conductors.
  • Shield landing: Cable shields terminate on a separate bracket.

Floating Excitation Circuit

  • Nominal source: The contact network is excited at 24 V DC.
  • Allowed range: The floating supply operates from 18 to 32 V DC.
  • SCOM bonding: E1 and E2 connect the circuit common to chassis.
  • Field boundary: Excitation and returns remain organized at the terminal board.

Pack-to-Controller Path

  • Pack connection: The PDIA plugs into the board through a D-type connector.
  • Input conversion: The I/O pack digitizes the 24 contact states.
  • Network path: Processed inputs travel from the PDIA to the controller over Ethernet.
  • Architecture: One terminal board and one pack form a simplex input node.

Field Signal Conditioning

  • Surge control: Input suppression limits transient energy at the contact channels.
  • High-frequency filtering: The same network attenuates fast electrical noise.
  • Ground discipline: Separate shield and SCOM bonds reduce shared return paths.
  • Configuration: No jumper changes the suppression or channel behavior.
Description
As a compact Mark VIe field-wiring interface, General Electric IS200STCIH1A is the STCI simplex contact input terminal board. It terminates 24 contact circuits and connects them to one PDIA I/O pack for conversion and controller communication.

The PDIA plugs into the D-type connector on IS200STCIH1A and exchanges input data with the Mark VIe controller over Ethernet. This board-and-pack combination supports simplex operation rather than redundant terminal-board architectures.

A fixed 52-position terminal block distinguishes IS200STCIH1A from the pluggable STCI versions. Its 24 inputs use a nominal 24 V DC floating excitation with an 18-32 V DC range, and input suppression limits surge and high-frequency noise at the field boundary.

DIN-rail or flat mounting is available for IS200STCIH1A. Typical field conductors are #18 AWG, cable shields terminate on a separate bracket, and E1/E2 bond SCOM to chassis; no jumpers or other hardware settings are required.
Alternative Names
IS200STCIH1A IS200-STCI-H1A GE IS200STCIH1A IS200 STCI H1A General Electric IS200STCIH1A Mark VIe STCI H1A IS200STCI H1A Contact Input Board IS2OOSTCIH1A
Technical notes
General Electric IS200STCIH1A combines 24 fixed-terminal contact inputs, 24 VDC floating excitation, and a simplex PDIA interface for Mark VIe.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What distinguishes IS200STCIH1A from an STCIH2A during terminal-board selection?
IS200STCIH1A uses a fixed 52-position terminal block, whereas the H2A version uses a pluggable terminal arrangement.
Can IS200STCIH1A be installed in a redundant contact-input architecture?
No. IS200STCIH1A is the simplex STCI interface and operates with one PDIA I/O pack.
Contact states fluctuate on IS200STCIH1A even though field switches are stable. What boundaries should be checked?
For IS200STCIH1A, verify the 18-32 VDC floating excitation, field returns, shield bracket, and E1/E2 chassis bond before tracing the PDIA network path.
How does IS200STCIH1A handle surge and high-frequency noise from field wiring?
Each input path on IS200STCIH1A includes suppression intended to reduce both surge transients and high-frequency interference.
Where should cable shields and SCOM be landed around IS200STCIH1A?
Terminate cable shields on the separate bracket for IS200STCIH1A, while E1 and E2 provide the SCOM-to-chassis grounding points.
Is a jumper setup required after mounting IS200STCIH1A on DIN rail or a flat surface?
No. IS200STCIH1A has no jumpers; installation checks focus on the fixed terminals, PDIA connection, excitation, and grounding.
