    Apter Power provides documentation, procurement support and system-matching guidance for General Electric DS200FCRRG1A.

DS200FCRRG1A

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric DS200FCRRG1A is a Group 1 FCRR firing circuit control board with terminal, two-pin and ribbon-cable interfaces.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for DS200FCRRG1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS200FCRRG1A

  • Manufacturer:
    General Electric
  • Part Number:
    DS200FCRRG1A
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    Firing Circuit Control Board
  • Stock:
    1
  • Functional Acronym:
    FCRR
  • Board Function:
    Firing circuit control
  • Assembly Family:
    DS200
  • Board Group:
    Group 1
  • PCB Coating:
    Normal coating
  • Terminal Block Capacity:
    95 signal wires
  • Two-Pin Connectors:
    10
  • Ribbon Cables:
    2
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Circuit Interface Board Layout Version Match Applications

Features:

  • Uses the FCRR identity for firing-circuit control
  • Provides terminal, two-pin and ribbon-cable interfaces
  • Tracks KD as the version tied to the base board
The FCRR functional code identifies the board role within the Group 1 DS200 hardware arrangement.

A 95-wire terminal block, ten two-pin connectors and two ribbon cables form recognizable service connection points.

The KD reference links DS200FCRRG1AKD records back to the DS200FCRRG1A base catalog number.

The General Electric DS200FCRRG1A Firing Circuit Control Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS200FCRRG1A Firing Circuit Control Board Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Firing-Control Connection Points

  • Terminal block: Organizes connection positions for as many as 95 signal wires.
  • Two-pin plugs: Ten labeled connectors provide discrete board-level interfaces.
  • Ribbon links: Two ribbon cables connect the board to adjacent cabinet hardware.
  • FCRR identity: The functional acronym ties these interfaces to the firing-control role.

Hardware Landmarks

  • Group code: G1 identifies the board as a Group 1 configuration.
  • Coating code: The A position records the normal PCB coating.
  • Connector labels: Printed identifiers help technicians map the ten two-pin plugs.
  • Service comparison: Terminal and ribbon-cable locations provide visual checkpoints during exchange work.

KD Revision Tracking

  • Base catalog: DS200FCRRG1A is the product number used for this page.
  • Version suffix: KD is retained from the DS200FCRRG1AKD identifier.
  • Traceability: Maintenance records should store both the base model and KD version.
  • Label check: The complete installed code should be verified before board replacement.

Drive Cabinet Service Uses

  • Firing circuits: Supports board-level control connections in compatible GE drive cabinets.
  • Wiring restoration: Gives technicians labeled locations for returning terminal and plug connections.
  • Revision control: Preserves KD identification when the longer catalog number appears in plant records.
  • Fault isolation: Uses labeled connection zones to narrow a no-response condition before assigning the fault to the board.
Description
General Electric DS200FCRRG1A is a Group 1 FCRR firing circuit control board in the GE DS200 drive-board family. The FCRR functional acronym identifies the board’s firing-control role, while its normal coating corresponds to the standard DS200 assembly style.

Connections on General Electric DS200FCRRG1A are distributed across one terminal block for as many as 95 signal wires, ten two-pin connectors and two ribbon cables. Connector groups 1PL–6PL and 11PL–16PL provide labeled board-level interface points around the assembly.

Six EEPROM devices on General Electric DS200FCRRG1A are positioned near the two-pin connectors. The board also carries jumper switches, resistor-network arrays, fuses, transformers, heat sinks and LED indicators as part of its firing-circuit hardware.
Revisions

Revision Part #

Also known as

DS200FCRRG1AKD
DS200FCRRG1A-KD, Series KD, Rev KD
DS200FCRRG1ACA
DS200FCRRG1A-CA, Series CA, Rev CA
Alternative Names
GE DS200FCRRG1A General Electric DS200FCRRG1A DS200-FCRR-G1A DS 200 FCRR G1A DS200FCRR G1A DS200FCRRGIA GE FCRR Firing Circuit Control Board DS2OOFCRRG1A
Technical notes
General Electric DS200FCRRG1A is a Group 1 FCRR firing circuit control board with a 95-wire terminal block, ten two-pin connectors, two ribbon cables and six EEPROM devices.
