    Apter Power provides pricing, product manuals and Mark VI controller-matching support for General Electric IS215UCVEH2B.

IS215UCVEH2B

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IS215UCVEH2B is a single-slot Mark VI UCVE controller that runs turbine application code and exchanges rack data through the VME bus.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS215UCVEH2B
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS215UCVEH2B

  • Manufacturer:
    General Electric
  • Part Number:
    IS215UCVEH2B
  • Product Family:
    GE Mark VI Gas Turbine Control
  • Product Type:
    Mark VI UCVE Standard Controller
  • Stock:
    1
  • Form Factor:
    Single-slot, 6U VME module
  • Operating System:
    QNX real-time operating system
  • UDH Interface:
    10BaseT/100BaseTX Ethernet, RJ45
  • Diagnostic Port:
    COM1
  • Serial Modbus Port:
    COM2
  • Rack Data Interface:
    VCMI through VME
  • Front Indication:
    Controller, flash, power and Ethernet status
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals VME Transfer UDH Link Serial Access Runtime Status

Features:

  • Executes Mark VI turbine application code in a single VME slot.
  • Moves rack data through the VME and VCMI path.
  • Separates UDH Ethernet, diagnostics and serial Modbus access.
IS215UCVEH2B is the standard UCVE processor at the center of a Mark VI control module.

Application execution remains on the controller while VCMI transfers external I/O data across the VME rack.

Front-panel indicators provide independent evidence for controller, flash, power and network conditions.

The General Electric IS215UCVEH2B Mark VI UCVE Standard Controller may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IS215UCVEH2B Mark VI UCVE Standard Controller Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Rack Data Path

  • Processor side: IS215UCVEH2B executes the turbine application in the control rack.
  • Internal bus: The VME bus links the controller with other rack boards.
  • I/O bridge: VCMI transfers external data between the I/O network and the VME path.
  • Fault boundary: Processor execution and I/O transport can be checked as separate functions.

Plant Network Path

  • Network role: The Ethernet interface connects IS215UCVEH2B to the Unit Data Highway.
  • Physical medium: The front RJ45 port supports 10BaseT/100BaseTX.
  • Link evidence: Ethernet indicators show link and traffic state.
  • Separation: A UDH interruption does not by itself identify a VME or application failure.

Two Service Channels

  • COM1: Provides the diagnostic setup connection for IS215UCVEH2B.
  • COM2: Carries the serial Modbus interface.
  • DCS path: COM2 can connect the controller to a serial DCS endpoint.
  • Troubleshooting: Serial access remains available independently of UDH Ethernet.

Controller Evidence

  • System state: SYSFAIL identifies a controller-level fault condition.
  • Storage activity: Flash indication separates media access from network traffic.
  • Power state: Front indication confirms the controller supply condition.
  • Network state: Link and activity indicators show the UDH interface condition.
Description
General Electric IS215UCVEH2B is a UCVE standard controller for the Mark VI turbine control platform. The single-slot VME module executes turbine application code and coordinates controller data with the I/O boards installed in the rack.

Inside the rack, IS215UCVEH2B exchanges control information across the VME bus and works with the VCMI communication interface. This arrangement keeps the processor-side application execution separate from the I/O communication path used to move external data into and out of the control module.

The external network connection on IS215UCVEH2B is a 10BaseT/100BaseTX Ethernet port for the Unit Data Highway. COM1 provides the diagnostic setup channel, while COM2 supplies the serial Modbus path used for a connected DCS or other serial device.

General Electric IS215UCVEH2B runs the QNX real-time operating system and reports controller, flash, power and Ethernet states through the front-panel indicators. These independent indications allow a loss of UDH traffic to be separated from a controller or VME-rack condition.
Alternative Names
GE IS215UCVEH2B IS215-UCVE-H2B General Electric UCVE H2B IS215 UCVE H2B IS215UCVEH2-B Mark VI UCVE Controller H2B UCVE Standard Controller H2B IS215UCVEH28
Technical notes
General Electric IS215UCVEH2B is a Mark VI UCVE standard controller for VME-rack application execution and communication.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why can the HMI lose data while IS215UCVEH2B continues to execute control code?
IS215UCVEH2B can continue local application execution while the UDH Ethernet path is interrupted, so the RJ45 link and activity indications should be checked separately.
What should be separated when SYSFAIL appears on IS215UCVEH2B?
With IS215UCVEH2B, compare controller power and flash behavior with VME and VCMI communication before assigning SYSFAIL to a network-only problem.
Which access route remains available when IS215UCVEH2B is unreachable on the UDH?
IS215UCVEH2B provides COM1 as the diagnostic setup channel, allowing local checks without relying on the UDH Ethernet connection.
Why can a VME communication problem make healthy field devices disappear from IS215UCVEH2B?
IS215UCVEH2B receives external I/O data through the VCMI and VME path, so a rack-transfer fault can interrupt data even when field wiring is unchanged.
What must be matched before application code is loaded into IS215UCVEH2B?
The IS215UCVEH2B hardware revision, rack configuration and intended Mark VI application set should be confirmed before loading controller software.
Why can serial Modbus data stop while the UDH connection on IS215UCVEH2B remains normal?
IS215UCVEH2B carries serial Modbus through COM2 and UDH traffic through the RJ45 Ethernet interface, so the two communication paths can fail independently.
Why should COM1 and COM2 cables not be exchanged on IS215UCVEH2B?
IS215UCVEH2B assigns diagnostic setup to COM1 and serial Modbus communication to COM2, so swapping them changes the intended service path.
