IS200TTURH1C

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IS200TTURH1C is a Mark VIe turbine terminal board that connects PTUR packs to turbine speed, voltage, shaft, flame-sensor, and main-breaker circuits.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS200TTURH1C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS200TTURH1C

  • Manufacturer:
    General Electric
  • Part Number:
    IS200TTURH1C
  • Product Family:
    GE Mark VI Gas Turbine Control
  • Product Type:
    Mark VIe Turbine Terminal Board
  • Stock:
    1
  • Simplex Pack Count:
    1 PTUR pack
  • TMR Pack Count:
    3 PTUR packs
  • Processor Connection Type:
    DC-62
  • I/O Pack Power:
    28 VDC
  • Compatible I/O Pack:
    IS220PTURH1A
  • Control Modes:
    Simplex or TMR
  • I/O Pack Connections:
    Three DC-62 connectors
  • Speed Sensor Inputs:
    Four per PTUR pack
  • Flame Sensor Circuits:
    Eight
  • Voltage Inputs:
    Bus and generator
  • Shaft Signals:
    Voltage and current
  • Main Breaker Outputs:
    K25 and K25P
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Compatibility Sensor Inputs Voltage & Flame Breaker Outputs

Features:

  • Connects speed, voltage, shaft, flame, and breaker signals to the PTUR protection processor.
  • Supports one PTUR path in simplex service or three PTUR paths in TMR service.
  • Uses three DC-62 processor connectors for the board-to-processor interfaces.
IS200TTURH1C terminates four speed-sensor channels for each connected PTUR path.

Voltage interfaces on IS200TTURH1C include generator and bus potential signals plus shaft voltage and current inputs.

IS200TTURH1C also provides eight flame-detector inputs and main-breaker relay output circuits K25 and K25P.

The General Electric IS200TTURH1C Turbine Terminal Board may be available for purchase and support from Apter Power for installed Mark VI or Mark VIe systems.
General Electric IS200TTURH1C Turbine Terminal Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Processor and Board Compatibility

  • Processor board: IS200TTURH1C connects to PTURH1A through the DC-62 interfaces.
  • Simplex layout: One PTUR path uses the terminal-board signal set.
  • TMR layout: Three PTUR paths receive the replicated protection signals.
  • Board boundary: PTURH1A works with IS200TTURH1C or STUR rather than DTUR configurations.

Speed and Shaft Channels

  • Speed inputs: Four speed-sensor channels are provided for each PTUR path.
  • Shaft voltage: IS200TTURH1C carries the shaft-voltage measurement circuit.
  • Shaft current: A separate input path brings shaft-current information to PTUR.
  • Signal routing: The terminal board fans the protection signals to its processor connectors.

Protection Input Groups

  • Generator potential: Generator-voltage signals enter through IS200TTURH1C.
  • Bus potential: A separate bus-voltage path supports synchronization-related measurements.
  • Flame inputs: Eight flame-detector circuits terminate on the board.
  • Processor delivery: Each group is routed through the TTUR-to-PTUR connection set.

Main-Breaker Relay Paths

  • K25 output: IS200TTURH1C provides the primary main-breaker relay output path.
  • K25P output: A companion relay circuit is available for the protection path.
  • Trip integration: The output circuits form part of the PTUR turbine-protection interface.
  • Terminal role: Field breaker wiring is separated from processor-side cabling on the board.
Description
Built as the field-termination layer for the PTUR primary turbine-protection path, General Electric IS200TTURH1C is a Mark VIe turbine terminal board. It carries turbine-specific signals between the installed PTUR pack or packs and the connected field circuits.

One connector arrangement allows IS200TTURH1C to serve two architectures: a single PTUR pack in simplex operation or three PTUR packs in a TMR arrangement. Three DC-62 interfaces connect the packs, while each PTUR receives one or two Ethernet network connections and separate 28 VDC power.

Protection-related field inputs on IS200TTURH1C include four speed-sensor channels per PTUR, generator and bus voltage inputs, shaft voltage and current signals, and eight flame-sensor circuits. K25 and K25P main-breaker output functions are routed through the TTUR/PTUR assembly.

The documented pack boundary for IS200TTURH1C is PTURH1A. This pack supports one-pack simplex or three-pack TMR operation on TTURH1C and is not compatible with DIN-rail DTUR boards or other TTUR versions.
Alternative Names
GE IS200TTURH1C General Electric IS200TTURH1C IS200TTURH1C TTUR Board IS200TTURH1C Turbine Terminal Board GE Mark VIe TTURH1C Mark VIe Turbine Control Terminal Board TTURH1C Primary Turbine Protection Terminal Board IS200TTURH1C PTUR Terminal Board
Technical notes
IS200TTURH1C serves as the Primary Turbine Protection (PTUR) terminal board in the GE Mark VI Speedtronic system, linking field speed sensors to the main protection processor for overspeed trip functions.
