IC200ALG321

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC200ALG321 is a four-channel VersaMax 0 to 10 VDC analog output module with 12-bit resolution and selectable loss-state behavior.
In Stock
Ships by Thursday, October 1
Fast Shipping Available
Get a quick price for IC200ALG321
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC200ALG321

  • Manufacturer:
    General Electric
  • Part Number:
    IC200ALG321
  • Product Family:
    GE VersaMax
  • Product Type:
    Analog Output Module
  • Stock:
    1
  • Output Channels:
    4 single-ended voltage outputs, one group
  • Nominal Output Range:
    0 to +10 VDC
  • Full Output Span:
    0 to 10.24 VDC
  • Resolution:
    12-bit; 2.5 mV per step
  • Module Update:
    0.3 ms maximum
  • External Supply:
    +18 to +30 VDC, or 9.6 to 15 VDC for 12 V operation
  • Load:
    5 kΩ minimum resistive; 1.0 µF maximum capacitive
  • Output Default:
    Hold last state or 0 V by carrier jumper
  • Diagnostics:
    Loss of user-side power
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Power States Fallback Jumper Voltage Mapping Applications

Features:

  • Four single-ended 0 to +10 V analog outputs
  • 12-bit conversion with a 0.3 ms maximum module update
  • Jumper selection for hold-last or 0 V interruption response
The General Electric IC200ALG321 part number denotes the four-channel unipolar-voltage member of the VersaMax analog output range.

Each controller word drives one field channel, while separate LEDs identify backplane availability and the external power needed by the output circuits.

The commissioning plan must match the load, supply range, carrier terminals and B13–B14 fallback jumper to the intended equipment behavior.

The General Electric IC200ALG321 Voltage Output Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IC200ALG321 Voltage Output Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Separating Rack and Field Supply

  • Backplane indication: The green OK lamp confirms that rack power reaches the module electronics.
  • Field indication: FLD PWR reports the user-side source that energizes the analog output circuits.
  • Supply choices: The field input can use either the standard +18 to +30 VDC span or the documented 12 V operating band.
  • Fault reporting: Loss of user-side power is sent to the controller as a module diagnostic.
  • State retention: The selected fallback remains effective only while external field power is uninterrupted.

Choosing the Interruption Output

  • Open B13–B14: Each channel retains its last commanded voltage by default.
  • Linked B13–B14: The four outputs change to 0 V after the documented interruption events.
  • Safe change: Both field and backplane sources are removed before the carrier jumper is moved.

Commands, Loads and Terminal Voltage

  • Word assignment: Four CPU or NIU words correspond in order to the four output terminals.
  • Count step: Accepted commands resolve in multiples of eight; intermediate values round downward.
  • Transfer equation: The manual relates commanded counts to the 10.25 V conversion span.
  • Load boundary: Field devices remain above the minimum resistance and below the maximum capacitance rating.

Fast Unipolar Voltage Control

  • Drive references: Four 0–10 V commands can set speed or torque references on compatible equipment.
  • Position demands: Actuator and valve interfaces can receive rapidly updated unipolar control levels.
  • Panel signals: Recorders, indicators or other high-impedance devices can follow individual controller values.
Description
Four single-ended 0 to +10 V outputs occupy one group in the General Electric IC200ALG321. The CPU or NIU writes four analog data words, and the module converts them at a maximum 0.3 ms update rate for fast voltage-command applications.

Field circuits on General Electric IC200ALG321 need a separate DC source even though the module electronics use backplane power. The manual permits either +18 to +30 VDC or a 9.6 to 15 VDC operating range; FLD PWR and OK indicators distinguish field-side supply from rack power.

A carrier jumper sets the interruption response of General Electric IC200ALG321. Leaving B13–B14 open holds the most recent command, while installing the link selects 0 V after backplane loss, communications interruption or a stopped PLC, provided field power remains present.
Revisions

Revision Part #

Also known as

IC200ALG321F
IC200ALG321-F, Series F, Rev F
IC200ALG321G
IC200ALG321-G, Series G, Rev G
IC200ALG321H
IC200ALG321-H, Series H, Rev H
IC200ALG321J
IC200ALG321-J, Series J, Rev J
IC200ALG321K
IC200ALG321-K, Series K, Rev K
Alternative Names
IC200-ALG321 IC200 ALG321 IC 200 ALG 321 GE IC200ALG321 GE Fanuc IC200ALG321 Emerson IC200ALG321 VersaMax IC200ALG321 0-10 V Output IC200ALG32I
Technical notes
General Electric IC200ALG321 provides four 0 to +10 VDC outputs with 12-bit conversion and a 0.3 ms maximum module update. The outputs require uninterrupted external field power.
