    Apter Power supports DS200TBQEG1A quotations, official technical data and Mark V LM system matching.

DS200TBQEG1A

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric DS200TBQEG1A is an LM6000 analog termination module for the Mark V LM system, linking field transducers and TCQE milliamp outputs through the R1 core.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for DS200TBQEG1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS200TBQEG1A

  • Manufacturer:
    General Electric
  • Part Number:
    DS200TBQEG1A
  • Product Family:
    SPEEDTRONIC Mark V
  • Product Type:
    LM6000 Analog Termination Module
  • Stock:
    1
  • Board Designation:
    TBQE
  • Core Location:
    R1 core, location 7
  • Companion Board:
    TCQE
  • Input Signals:
    Proximity, vibration, LVDT/R, RTD and pulse-rate
  • Output Signals:
    Two milliamp outputs from TCQE
  • Output Range Selection:
    20 mA or 200 mA maximum
  • Connectors:
    JLLR, JQQR, JLLS/T and JQQS/T
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Signal Routing Sensor Inputs Output Setup Applications

Features:

  • Installed in location seven of the R1 core for Mark V LM LM6000 control.
  • Routes proximity, vibration, position, RTD and pulse-rate inputs to the TCQE board.
  • Returns two configurable milliamp output signals from TCQE to the terminal interface.
As the dedicated TBQE interface in the R1 core, DS200TBQEG1A concentrates the analog connections used by the TCQE processor into one terminal-board location.

JLLR handles position, temperature, pulse-rate and milliamp-output traffic, while JQQR carries proximity and vibration channels.

BJ1 and BJ2 provide the board-level selection for the two milliamp output limits; JLLS/T and JQQS/T are normally left unused.

The General Electric DS200TBQEG1A LM6000 Analog Termination Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS200TBQEG1A LM6000 Analog Termination Module Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Connection Paths

  • JLLR Inputs: Carries LVDT/R position, RTD and pulse-rate signals toward TCQE.
  • JLLR Return: Receives the milliamp output signals sent back from TCQE.
  • JQQR Route: Transfers proximity and vibration signals to the TCQE board.
  • Unused Paths: JLLS/T and JQQS/T are normally not used.

Field Feedback Channels

  • Proximity: Accepts proximity-transducer signals for shaft-related feedback.
  • Vibration: Receives accelerometer and proximitor channels used by TCQE.
  • Position: Routes LVDT/R position-feedback inputs through the terminal board.
  • Temperature: Provides the landing path for RTD input signals.
  • Pulse Rate: Passes LP-shaft speed and shear-protection signals for processing.

Milliamp Channel Settings

  • Signal Source: Two 4-20 mA outputs originate at the TCQE board.
  • Termination Path: Both output signals return to the TBQE terminal interface.
  • Range Selection: BJ1 and BJ2 select a 20 mA or 200 mA maximum output range.

LM Engine Functions

  • LM Controls: The TBQE board is used across LM engine applications.
  • Feedback Collection: Field transducer channels are gathered for the Mark V LM control path.
  • Shaft Protection: Pulse-rate inputs support LP-shaft speed monitoring and shear protection.
Description
General Electric DS200TBQEG1A is the TBQE analog termination module installed in location seven of the Mark V LM R1 core. It provides the terminal-board interface for the inputs and outputs used by the TCQE board in LM engine control systems.

Within the feedback path, General Electric DS200TBQEG1A accepts proximity-transducer, accelerometer, LVDT/R position, RTD and pulse-rate signals. The pulse-rate channels support LP-shaft speed monitoring and shear-protection functions before the TCQE board processes the incoming data.

Signal traffic is separated across dedicated connections on General Electric DS200TBQEG1A. JLLR carries position, temperature and pulse-rate inputs toward TCQE and returns the milliamp output signals, while JQQR transfers proximitor and vibration channels; JLLS/T and JQQS/T are normally unused.

For the output path, General Electric DS200TBQEG1A receives two 4-20 mA signals from the TCQE board and presents them at the terminal board. Hardware jumpers BJ1 and BJ2 select a maximum current range of either 20 mA or 200 mA for those two channels.
Alternative Names
GE DS200TBQEG1A DS200 TBQE G1A TBQE G1A Analog Termination Module DS200TBQE-G1A Mark V LM DS200TBQEG1A General Electric DS200TBQE G1A DS 200 TBQE G1A DS2O0TBQEG1A
Technical notes
General Electric DS200TBQEG1A is the TBQE analog termination module for the Mark V LM R1 core, connecting TCQE sensor inputs and milliamp outputs.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Where should technicians look when vibration or proximity feedback is missing through General Electric DS200TBQEG1A?
For General Electric DS200TBQEG1A, proximity and vibration traffic uses JQQR; technicians should inspect that path and its field termination before checking JLLR, which carries different signal groups.
How can a customer confirm that General Electric DS200TBQEG1A matches an LM6000 control rack?
A suitable General Electric DS200TBQEG1A installation is the TBQE position at location seven of the Mark V LM R1 core, linked to TCQE for LM engine analog I/O.
Why can a milliamp output from General Electric DS200TBQEG1A appear to be on the wrong range?
BJ1 and BJ2 on General Electric DS200TBQEG1A select a 20 mA or 200 mA maximum output range. A setting that does not match the TCQE output requirement can make the channel appear incorrectly ranged.
If position or temperature feedback is lost, which General Electric DS200TBQEG1A path should be checked?
On General Electric DS200TBQEG1A, LVDT/R, RTD and pulse-rate inputs travel over JLLR to TCQE, so the terminal assignment and JLLR connection are the relevant points to check.
Which General Electric DS200TBQEG1A connectors should remain unused during normal LM wiring?
General Electric DS200TBQEG1A normally leaves JLLS/T and JQQS/T unused; the active signal routes identified for this board are JLLR and JQQR.
Can General Electric DS200TBQEG1A support LP-shaft speed and shear-protection feedback?
Yes. General Electric DS200TBQEG1A passes pulse-rate inputs used for LP-shaft speed monitoring and shear protection to TCQE through the JLLR connection.
