Honeywell 10307/1/1 is an FSC vertical bus terminator spare used at the specified termination position in a Fail Safe Controller cabinet.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 10307/1/1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 10307/1/1

  • Manufacturer:
    Honeywell
  • Part Number:
    10307/1/1
  • Product Family:
    Honeywell FSC Series
  • Product Type:
    FSC Vertical Bus Terminator
  • Stock:
    1
  • Platform:
    Honeywell Fail Safe Controller
  • Part Type:
    Vertical bus terminator
  • Official Item Description:
    VERTICAL BUS TERMINATOR CC
  • Supply Classification:
    Spare part
  • Installation Role:
    Documented vertical-bus termination position
  • System Lifecycle:
    FSC platform discontinued; exact spare remains listed
  • Weight:
    0.22 kg
  • Estimated shipping dimensions:
    37 x 6.2 x 6 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Bus Position Changeout Control Acceptance Checks Product Applications

Features:

  • Exact cabinet spare: Restores the Honeywell-designated vertical-bus termination component.
  • Position-dependent function: Correct location and orientation are essential to the bus arrangement.
  • Legacy service value: Supports controlled maintenance of an installed FSC system while modernization is planned.
10307/1/1 is a Honeywell FSC spare whose identity is tied to vertical-bus termination rather than to a general-purpose I/O function.

A successful changeout preserves the original slot, orientation and cabinet topology before any assembly is disturbed.

If several modules show communication symptoms together, the termination path and interconnections should be verified before multiple healthy cards are replaced.

Apter Power can help confirm the Honeywell 10307/1/1 FSC Vertical Bus Terminator, cabinet position and legacy spare requirement before quotation.
Honeywell 10307/1/1 FSC Vertical Bus Terminator Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Drawing reference: Use the approved cabinet documentation to identify the required termination location.
  • End-position proof: Confirm the assembly is at the intended end of the vertical bus.
  • Orientation record: Photograph keying and labels before removal so the replacement cannot be reversed.
  • Single-terminator rule: Stop if the cabinet appears open-ended or terminated at more than one unapproved point.
  • Safe state: Follow the site FSC shutdown and permit procedure before disturbing the bus.
  • Connector inspection: Check mating contacts and adjacent interconnections instead of assuming the terminator alone failed.
  • Exact identity: Match all three numeric sections in the part number before installation.
  • Configuration restraint: Do not alter unrelated safety-system logic during a hardware replacement.
  • Communication recovery: Verify that affected chassis and modules return without new bus diagnostics.
  • Fault history: Compare events before and after the change to distinguish a corrected link from an intermittent condition.
  • Cabinet inspection: Recheck seating, retention and nearby cables before restoring normal operation.
  • Evidence package: Retain photos, exact part identity and approved test results with the maintenance record.
  • FSC cabinet termination: Completes the documented vertical-bus arrangement in a Honeywell Fail Safe Controller cabinet.
  • Installed-spare maintenance: Replaces an exact legacy terminator during controlled service work.
  • Grouped fault diagnosis: Supports recovery where bus termination is confirmed as the shared communication issue.
  • Legacy system support: Maintains an existing FSC installation while migration planning proceeds.
Description
10307/1/1 is the exact Honeywell spare identity for a vertical bus terminator used within the legacy Fail Safe Controller hardware platform.

The role of 10307/1/1 is installation-specific: it belongs at the documented end position of the cabinet bus, where an omitted, misplaced or duplicated terminator can disturb communication across otherwise healthy assemblies.

Although the wider FSC platform is discontinued, Honeywell lists 10307/1/1 as a spare part, so service work should preserve the exact part number, cabinet position and changeout evidence rather than substituting a visually similar board.
Alternative Names
1030711 10307 1 1 10307/1
Technical notes
10307/1/1 must be installed only in the documented vertical-bus termination position. An open bus, misplaced terminator or double termination can resemble multiple module faults. De-energize by the approved FSC procedure, photograph the original slot and orientation, and stop if the cabinet drawing does not confirm the required terminator location.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Several FSC modules report communication faults near 10307/1/1. Should all affected modules be replaced?
No. Verify the vertical-bus path, terminator position, seating and adjacent interconnections before treating several modules as simultaneous failures.
Can the shorter marking 10307/1 be used when ordering 10307/1/1?
Use the complete three-section part number. The shortened form does not preserve the exact spare identity confirmed for this page.
A cabinet appears to contain two assemblies resembling 10307/1/1. What should maintenance do?
Stop and compare the cabinet drawing, bus topology and exact labels. Do not energize an arrangement that may be terminated twice.
May 10307/1/1 be changed while the FSC cabinet remains energized?
Follow the approved Honeywell and site maintenance procedure. Do not assume this bus component is hot-swappable from appearance or location alone.
The replacement 10307/1/1 is installed but diagnostics remain. What evidence should be checked next?
Check orientation, connector condition, adjacent bus links, power and the fault chronology before disturbing safety logic or replacing additional cards.
What should an RFQ for 10307/1/1 include?
Provide the complete part number, clear label and cabinet-position photos, system context, condition, quantity and required delivery date.
