Features:
- Terminates up to sixteen RTD channels for one Honeywell LLMux unit.
- Routes low-level resistance signals to a single I/O processor path.
- Uses compression terminals in the documented CE execution.
The assembly terminates low-level resistance-temperature detector wiring for the Honeywell LLMux measurement subsystem.
RTD lead resistances are presented through the FTA to the LLMux electronics, which applies the configured excitation and calculates temperature from the measured resistance. The FTA itself provides termination and routing rather than performing control calculations.
Confirm RTD type, lead configuration, single-IOP execution, compression-terminal wiring and unit address. Shielding and cabinet routing must protect low-level signals from power-cable interference.
Availability is reviewed against the exact MU-TAMR03 51309218-125 order identity and requested supply condition; manufacturer lifecycle status: Discontinued / Obsolete by OEM.
Verified resources for Honeywell MU-TAMR03 51309218-125:
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
- A complete LLMux path combines the I/O processor, power adapter and field termination assembly. One unit serves channels 1-16; a second documented unit extends the arrangement to channels 17-32.
- The assembly is used for plant temperature inputs where multiple low-level RTD circuits must be concentrated near the control-system cabinet while preserving their channel identity.
- Requires exact sensor wiring, unit address and low-level shielding practices.
- Routes RTD lead resistance through the FTA to LLMux electronics.
- Supports up to 16 RTD channels per LLMux unit.
- Excitation and resistance conversion occur within the LLMux processor.
- Unit 0 serves channels 1–16; Unit 1 serves channels 17–32.
- Uses compression terminals for low-level RTD field wiring.
- Part-number identity must match the documented CE-designated hardware execution.
- Terminates resistance-temperature detector wiring for the Honeywell LLMux subsystem.
- Connects through a single IOP interface.
- Applies to the documented CE LLmux installation arrangement.
