T9402

/ 4.9
1001 reviews | Need a Specific Revision?
The T9402 is a 16-channel digital input module (DIM) for ICS-Triplex AADvance systems, supporting high-density channels (16 channels).
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for T9402
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for T9402

  • Manufacturer:
    ICS Triplex
  • Part Number:
    T9402
  • Product Family:
    AADvance Controller
  • Product Type:
    Digital Input Module
  • Stock:
    5
  • Input Channels:
    16
  • Rated Input Voltage:
    24 V DC (Typical)
  • Backplane Supply Voltage:
    18–32 V DC
  • Maximum Backplane Current:
    260 mA
  • Power Dissipation:
    4 W
  • Heat Dissipation:
    Approximately 13.6 BTU/hour
  • Weight:
    0.36 kg
  • Estimated shipping dimensions:
    4.2x12x16.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Product Applications Operating Environment Performance & Efficiency

Features:

  • High-Density Digital Input Acquisition for Industrial Control Systems
  • Combines 16-Channel Capacity with 24 Vdc Signal Compatibility
  • Operates in Conjunction with the ICS Triplex Control Architecture
The T9402 operates as the Digital Input Module in a Triplex control system, providing reliable digital signal acquisition from field devices to all processors within the system. It continuously monitors 16 discrete input channels (24 Vdc) and transmits this status data through the rack backplane to support real-time processing and decision-making by all controllers and modules. High signal integrity is standard with the T9402, however using proper shielding and grounding practices will ensure optimal noise immunity in electrically noisy industrial environments. The T9402 has made improvements in several areas over previous input module designs in addition to incorporating enhanced channel density within the Triplex rack.

The T9402 provides essential input functions common to the entire control strategy, and is a critical component of the data acquisition path, directly affecting the accurate, reliable operation of the overall control system. One or multiple T9402 modules are required per rack depending on the desired I/O point count. The T9402 occupies a standard module slot in the rack and can be located in any available I/O slot position.

For High Channel Count applications, the Triplex System requires additional T9402 Digital Input Modules installed in available slots. In addition to standard single module operation, the multi-module configuration also performs seamless integration. The Triplex multi-module configuration executes data exchange using the internal communication bus specified in the system architecture. Using this method, the distributed input system continually monitors the status of all channels. If the system detects that any T9402 module is no longer providing valid input data (outside configured signal/tolerance levels), it will automatically flag the channel status and place an event in the System Event List.

The T9402 ICS Triplex Digital Input Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ICS Triplex T9402 Digital input module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ICS Triplex T9402 Digital input module Specs

General

  • Manufacturer ICS Triplex
  • Model T9402
  • Condition New Original ready stock
  • Product Family T9401,T9451 ,T9482
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Emergency Shutdown (ESD) Systems: Protecting industrial plants during hazardous events.
  • Fire and Gas (F&G) Protection: Monitoring critical sensors for early threat detection.
  • Burner Management Systems (BMS): Safe control of boilers and furnaces.
  • Critical Process Control: Managing high-risk operations in petrochemical, power, and rail industries.
  • Field Device Monitoring: Reading signals from limit switches, proximity sensors, and push buttons.
  • Operating Temperature: Wide range from -40°C to +70°C (-40°F to 158°F).
  • Humidity: 5% to 95% relative humidity, non-condensing.
  • Electrical Robustness: Features a 120dB common-mode rejection ratio and 1500 Vrms channel-to-channel isolation to handle electrical noise.
  • Certification: Certified for use in hazardous environments (UL certified) and SIL 3 safety compliance.
  • Fast Response: Boasts a scanning speed as fast as 0.924ms in simplex configurations and a response time under 250 microseconds.
  • Low Power Consumption: Consumes approximately 2.2W to 3.5W at 24VDC, contributing to overall system thermal efficiency.
  • Comprehensive Diagnostics: Real-time monitoring of channel health and power supply status allows for rapid maintenance and fault isolation.
  • Hot-Swappable: Faulty modules can be replaced in redundant configurations without interrupting the data flow to the processor.
Description
The T9402 is a 16-channel digital input module (DIM) for the ICS-Triplex AADvance system, designed for critical control systems. It receives digital signals from field switches, pushbuttons, and sensors (24V DC).

ICS Triplex T9402 is engineered for seamless integration into the AADvance distributed control architecture, supporting simplex, dual, and triple modular redundant (TMR) configurations to meet SIL 2 and SIL 3 application requirements. The module draws its operating power directly from the T9300 I/O backplane, eliminating the need for a separate module power supply and simplifying cabinet wiring.

ICS Triplex T9402 supports high-density channels (16 channels), fault tolerance and redundancy (suitable for TMR architectures), and flexible configuration with three different scan times (0.924 ms / 1.676 ms / 2.453 ms). The T9402 features built-in line fault detection, detecting open/short circuits and other faults, and displays alarms/alarm status via front panel LEDs and the workbench.
Alternative Names
T9300 T9432 T9432 T9451 T9401 T9431 T9481 T9482
Technical notes
ICS Triplex T9402 is a 16-channel, 24 Vdc digital input module for the AADvance controller platform. It supports simplex, dual, and triple (TMR) architectures with respective scan times of 0.924 ms, 1.676 ms, and 2.453 ms, and includes built-in line fault detection (open/short circuit) and hazardous location certification (Class I, Division 2 / ATEX Zone 2).
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the ICS Triplex T9402 used for?
The ICS Triplex T9402 is used to acquire 24 Vdc digital signals from field devices such as switches, pushbuttons, and proximity sensors in safety-critical and high-availability control systems.
What software and firmware compatibility does the ICS Triplex T9402 require?
The ICS Triplex T9402 is configured via the AADvance Workbench software. Always verify firmware revisions with product release notes from Rockwell Automation’s PCDC (rok.auto/pcdc) to ensure compatibility with the T9110 processor module.
How is the ICS Triplex T9402 wired, and what termination assemblies are supported?
The ICS Triplex T9402 connects to field wiring via termination assemblies: T9801 (simplex), T9802 (dual), or T9803 (TMR). Shielded cable is recommended for noisy industrial environments.
What diagnostic capabilities does the ICS Triplex T9402 provide?
The ICS Triplex T9402 provides per-channel line fault detection (open/short circuit), status LEDs, and system event logging through the backplane. Invalid input data is automatically flagged in the System Event List.
