MVI56-DFCM

/ 4.9
1001 reviews | Need a Specific Revision?
ProSoft MVI56-DFCM is a DF1 Master/Slave Communication Module. It adds DF1 Master and Slave serial communication to legacy ControlLogix systems.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for MVI56-DFCM
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MVI56-DFCM

  • Manufacturer:
    ProSoft
  • Part Number:
    MVI56-DFCM
  • Product Family:
    ProSoft
  • Product Type:
    DF1 Master/Slave Communication Module
  • Stock:
    1
  • Baud rate:
    110–115,200 baud
  • Backplane current load:
    Typical 800mA @ 5V
  • Operating temperature:
    0–60°C
  • Storage temperature:
    –40–85°C
  • Shock:
    30g (running)
  • Vibration:
    5g (10–150Hz)
  • Weight:
    0.25 kg
  • Estimated shipping dimensions:
    3.1x14x14.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications DF1 Protocol Serial Links Legacy Support

Features:

  • Two configurable DF1 serial application ports
  • DF1 full- and half-duplex operation
  • Master and Slave communication modes
MVI56-DFCM adds two DF1 channels to a ControlLogix rack for communication with Allen-Bradley serial devices and compatible DF1 nodes.

Its ports support full-duplex and half-duplex networks, with Master or Slave behavior selected to suit the polling and response architecture.

When maintaining an MVI56-DFCM installation, document the duplex mode, station addresses, serial timing, cable pinout, message commands, and controller data map.

The ProSoft MVI56-DFCM DF1 Master/Slave Communication Module is listed as Discontinued / Obsolete by OEM. Apter Power provides legacy sourcing and DF1 application review.

ProSoft MVI56-DFCM DF1 Master/Slave Communication Module Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ProSoft MVI56-DFCM DF1 Master/Slave Communication Module Specs

General

  • ManufacturerProSoft Technology
  • ModelMVI56-DFCM
  • ConditionNew Original ready stock
  • Product FamilyControlLogix Communication Module

Duplex and station roles

  • Full duplex: Point-to-point or switched DF1 links can use full-duplex messaging.
  • Half duplex: Multidrop networks can use half-duplex Master or Slave operation.
  • Master functions: Configured commands allow the module to initiate supported DF1 data transfers.
  • Slave access: Slave mode responds to requests addressed to the configured DF1 station.

Port-level engineering

  • Two channels: MVI56-DFCM supplies two separately configurable serial application ports.
  • Communication rate: The documented baud range is 110 to 115200 baud.
  • Physical connection: Verify the required cable, electrical interface, handshaking, and termination for each DF1 link.
  • Timing values: Response timeout, retries, polling, and station addressing must match the network design.

Migration preparation

  • Official status: MVI56-DFCM is retained in the ProSoft legacy download area.
  • Configuration archive: Save the module configuration, ladder logic, command list, firmware details, and serial drawings.
  • Migration note: ProSoft provides a technical note for moving MVI56-DFCM or DFCMR applications to PLX51-DF1-ENI.
  • Engineering check: A migration still requires review of DF1 roles, message paths, data addresses, cabling, and controller logic.
Description
The MVI56-DFCM is a high-performance DF1 communication module designed by ProSoft Technology for Allen-Bradley ControlLogix® systems. It supports both half-duplex and full-duplex operation and can be configured as a master or slave device. This module allows ControlLogix controllers to reliably communicate with a variety of DF1-compatible devices, including PLCs, RTUs, SCADA system terminals, and various industrial automation equipment, via RS-232, RS-422, or RS-485 serial interfaces.

The MVI56-DFCM is rack-mounted within ControlLogix enclosures, requiring no additional power supply or complex wiring, facilitating rapid deployment in existing systems. It supports configurable communication parameters, including baud rate, data bits, stop bits, and parity, adapting to the communication needs of various industrial environments.

The MVI56-DFCM is particularly suitable for retrofitting legacy equipment, expanding serial buses, and upgrading mixed new and legacy systems. By providing clear master/slave switching and flexible port configuration, the module easily enables networking of multiple devices while ensuring communication stability and data integrity. In addition, the module has industrial-grade tolerance, including a wide temperature range and resistance to shock and vibration, enabling it to operate reliably for extended periods in harsh industrial environments.
Alternative Names
MVI56 DFCM MVI56DFCM ProSoft MVI56-DFCM PST MVI56-DFCM MVI56-DFCM ControlLogix Communication Module MVI56-DFCM Communication Module MVI56-DFCM Datasheet MVI56-DFCM Manual
Technical notes
MVI56-DFCM DF1 Master/Slave Communication Module adds DF1 Master and Slave serial communication to legacy ControlLogix systems. Verify DF1 Protocol, Serial Links, Legacy Support settings against the official ProSoft documentation.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What communication protocol does MVI56-DFCM add to ControlLogix?
MVI56-DFCM adds DF1 Master and Slave serial communications to a ControlLogix controller.
How many serial ports are available on MVI56-DFCM?
MVI56-DFCM provides two configurable DF1 application ports.
Does MVI56-DFCM support both DF1 duplex modes?
MVI56-DFCM supports DF1 full-duplex and half-duplex operation.
What should be checked when MVI56-DFCM stops responding?
For MVI56-DFCM, inspect backplane status, cable pinout, duplex mode, station address, baud rate, retries, and command errors.
Is a migration document available for MVI56-DFCM?
ProSoft publishes an MVI56-DFCM migration note, but the target hardware and application changes must be reviewed before conversion.
What is the official lifecycle position of MVI56-DFCM?
ProSoft places MVI56-DFCM in its legacy product area, so MVI56-DFCM is Discontinued / Obsolete by OEM.
Where can MVI56-DFCM files and legacy procurement support be found?
The MVI56-DFCM Manuals tab includes the official datasheet, and Apter Power can assist with sourcing and migration review.
