PLX82-EIP-61850

/ 4.9
1001 reviews | Need a Specific Revision?
ProSoft PLX82-EIP-61850 is a dual-port EtherNet/IP Server to IEC 61850 Client gateway for substation device integration.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for PLX82-EIP-61850
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PLX82-EIP-61850

  • Manufacturer:
    ProSoft
  • Part Number:
    PLX82-EIP-61850
  • Product Family:
    ProSoft
  • Product Type:
    EtherNet/IP™ Server to IEC 61850 Dual Port Client Gateway
  • Stock:
    1
  • Power Supply:
    24 VDC nominal, 10 to 36 VDC power input allowed, Positive, Negative, GND Terminals, 2.5 mm screwdriver blade.
  • Current Load:
    200 mA max @ 24 VDC, 150 mA max @ 32 VDC, 450 mA max @ 10 VDC
  • Operating Temperature:
    -25°C to 70°C (-13°F to 158°F)
  • Storage Temperature:
    -40°C to 85°C (-40°F to 185°F)
  • Relative Humidity:
    5% to 95%, with no condensation
  • Shock:
    IEC 60068-2-27; 15G @ 11ms (Operational), IEC 60068-2-27; 30G @ 18ms (Non-Operational)
  • Vibration:
    IEC 60068-2-6; 5G, 10 to 150 Hz
  • LED Indicators:
    ERR, CFG, FLT, PWR
  • Shipped with Each Unit:
    One - J180 screw terminal plug, One - HRD250 screwdriver
  • Weight:
    1.4 kg
  • Estimated shipping dimensions:
    5.52 × 2.06 × 4.37 in (14.02 × 5.23 × 11.1 cm)
  • Tariff Code:
    8517.62.00
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications IEC 61850 EtherNet/IP Configuration

Features:

  • EtherNet/IP Server to IEC 61850 Client gateway
  • Dual Ethernet ports for separate protocol subnets
  • IED tag import and Studio 5000 integration
The ProSoft PLX82-EIP-61850 connects EtherNet/IP controllers with IEC 61850 intelligent electronic devices through a dual-port client gateway intended for power and process integration.

IEC 61850 device files are imported so selected data objects can be mapped into the EtherNet/IP interface. The architecture separates controller communication from the IEC 61850 network while maintaining a shared data exchange.

Confirm IED configuration files, logical nodes, report behavior, controller assemblies, Add-On Instruction mapping, dual-network addressing, time settings, and cybersecurity requirements before system startup.
The ProSoft PLX82-EIP-61850 EtherNet/IP™ Server to IEC 61850 Dual Port Client Gateway is listed as Active / Available from OEM. ProSoft lists this dual-port IEC 61850 gateway as active. Apter Power provides pricing, documentation, and IED-to-controller matching assistance.
ProSoft PLX82-EIP-61850 EtherNet/IP™ Server to IEC 61850 Dual Port Client Gateway Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ProSoft PLX82-EIP-61850 EtherNet/IP Server to IEC 61850 Dual Port Client Gateway Specs

General

  • Manufacturer ProSoft Technology
  • Model PLX82-EIP-61850
  • Condition New Original ready stock
  • Product Family PLX8x Gateways
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

PLX82-EIP-61850 IEC details

  • Function: IEC 61850 Client operation
  • Protocol: Polling of substation IEDs
  • Capacity: Standards-based device identification
  • Operation: Controller integration uses the documented EtherNet/IP mapping resources.

PLX82-EIP-61850 EtherNet/IP details

  • Integration: EtherNet/IP Server communication
  • Interface: Multiple real-time I/O connections
  • Configuration: Rockwell Automation PAC integration
  • Application: Controller integration uses the documented EtherNet/IP mapping resources.

PLX82-EIP-61850 Configuration details

  • Diagnostics: IED tag import workflow
  • Setup: Automatic Add-On Instruction creation
  • Verification: Separate protocol-subnet configuration
  • Maintenance: Controller integration uses the documented EtherNet/IP mapping resources.
Description
The PLX82-EIP-61850 connects Rockwell Automation PACs with IEC 61850 Intelligent Electronic Devices such as substation monitors and protection relays.

The PLX82-EIP-61850 acts as an IEC 61850 Client and transfers polled device data to the EtherNet/IP network, with two ports supporting separate protocol subnets.

The PLX82-EIP-61850 uses dedicated configuration software to import IED tags and create the Add-On Instruction required for Studio 5000 integration.
Revisions

Revision Part #

Also known as

PLX82-EIP-61850 Ser A
PLX82-EIP-61850 Series A, PLX82-EIP-61850 Rev A
PLX82-EIP-61850 Ser B
PLX82-EIP-61850 Series B, PLX82-EIP-61850 Rev B
Alternative Names
PLX82 EIP 61850 PLX82EIP61850 ProSoft PLX82-EIP-61850 PST PLX82-EIP-61850 PLX82-EIP-61850 IEC Gateway PLX82-EIP-61850 Substation Gateway PLX82-EIP-61850 Datasheet PLX82-EIP-61850 Manual
Technical notes
PLX82-EIP-61850 is an EtherNet/IP Server to IEC 61850 dual-port Client gateway. Verify IED data models, subnet separation, controller integration, power, and firmware.
