MVI69-ADM

/ 4.9
1001 reviews | Need a Specific Revision?
The MVI69-ADM is a programmable application development module designed by ProSoft specifically for the Allen-Bradley CompactLogix/MicroLogix platform.
Get a quick price for MVI69-ADM
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MVI69-ADM

  • Manufacturer:
    ProSoft
  • Part Number:
    MVI69-ADM
  • Product Family:
    ProSoft
  • Mounting Slot:
    Single Slot
  • Backplane Current Load:
    Maximum 800mA @ 5VDC
  • Operating Temperature:
    0°C to 60°C
  • Storage Temperature:
    –40°C to 85°C
  • Operating Humidity:
    Supports up to 95%RH (non-condensing)
  • Weight:
    0.18 kg
  • Estimated shipping dimensions:
    4x8.8x13.2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
The MVI69-ADM is a programmable application development module designed by ProSoft specifically for the Allen-Bradley CompactLogix/MicroLogix platform. It allows users to run custom C language applications within a controller backplane slot, providing flexible support for serial devices, proprietary protocols, data conversion, and custom logic.

Key features include:

Single-slot mounting within the 1769/CompactLogix rack backplane, eliminating the need for additional communication module space.Provides two fully isolated application serial ports (PRT1, PRT2) configurable in RS-232, RS-422, or RS-485 modes for communication with various serial devices.Exchanges data with the controller via ladder logic, while the module can access processor memory to implement custom algorithms and interact with field data.Supports tailored serial/ASCII communication, proprietary protocol integration, and encapsulated communication logic, making it ideal for systems requiring custom embedded logic or proprietary data processing.

Alternative Names
MVI69-ADMNET MVI69-MCM
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What communication interfaces does the MVI69-ADM support?
It provides two application serial ports (P1/P2), supporting RS-232, RS-422, and RS-485, allowing connection to various serial devices.
How does the MVI69-ADM run custom applications?
Users can run C language applications internally within the module, implementing custom logic by accessing the controller's memory and serial ports.
How does the MVI69-ADM integrate with the CompactLogix system?
It is directly installed in the 1769/CompactLogix backplane, exchanging data with the controller via ladder logic or AOI.
What application scenarios is the MVI69-ADM suitable for?
It is suitable for proprietary protocol communication, data conversion, serial device integration, custom control logic, and legacy device upgrade projects.
