MVI69-ADMNET

/ 4.9
1001 reviews | Need a Specific Revision?
The MVI69-ADMNET Application Development Ethernet Communication Module allows CompactLogix / MicroLogix processors to interface easily with Ethernet protocol compatible devices and hosts.
Get a quick price for MVI69-ADMNET
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for MVI69-ADMNET

  • Manufacturer:
    ProSoft
  • Part Number:
    MVI69-ADMNET
  • Product Family:
    ProSoft
  • Power supply current:
    800mA max @ 5VDC
  • Storage/Memory:
    896KB Flash, 640KB RAM
  • Operating temperature:
    0°C to +60°C
  • Storage temperature:
    -40°C to +85°C
  • Relative humidity:
    5% to 95% (non-condensing)
  • Weight:
    0.18 kg
  • Estimated shipping dimensions:
    4x8.8x13.2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description

The MVI69-ADMNET Application Development Ethernet Communication Module allows CompactLogix / MicroLogix processors to interface easily with Ethernet protocol compatible devices and hosts.


The ADMNET solution is a powerful module designed with both Client and server support. This broad support enables the module to function as a data collection submaster, or to be a powerful slave as a remote off an HMI host. Applications for the module are found in most industries, especially Manufacturing, Oil and Gas, Electrical Power and Food Processing.


The MVI69-ADMNET module is a single-slot, backplane compatible solution for the CompactLogix / MicroLogix platform. It supports two fully isolated serial ports and one Ethernet port, allowing the many field devices to be integrated into the CompactLogix / MicroLogix platform with custom user-written 'C' code and various APIs supplied for Ethernet, serial and backplane communication.
Alternative Names
MVI69-ADMENT MVI69-MCM MVI69-DFNT MVI69E-MBS MVI69E-MBTCP
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can the MVI69-ADMNET be configured using standard Ladder Logic?
Not entirely. This module is not a traditional I/O module. It primarily uses C language to develop user applications (via ProSoft's API), which are then downloaded into the module. The communication logic mainly executes internally within the module.
Can I use this module to implement Modbus/TCP/UDP protocols?
Yes, you can, as long as you implement the protocol logic in C language (using the API provided by ProSoft). The module itself does not have a fixed protocol, but rather provides developers with flexibility.
How do I download my C program into the module?
The ProSoft SDK provides image file creation and image download tools to burn compiled programs into the module.
Does the MVI69-ADMNET provide isolation during Ethernet communication?
According to ProSoft's developer guidelines, the module's Ethernet port supports isolation to improve communication security.
