    For 6ES7677-2AA40-0AA0, Apter Power provides quotations, manuals, and system-matching support.

6ES7677-2AA40-0AA0

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6ES7677-2AA40-0AA0 is CPU 1515SP PC spare hardware that provides the ET 200SP Open Controller platform without a CFast card or installed software.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7677-2AA40-0AA0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7677-2AA40-0AA0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7677-2AA40-0AA0
  • Product Family:
    Siemens Simatic ET 200SP
  • Product Type:
    CPU 1515SP PC 4 GB Spare Controller Hardware
  • Stock:
    1
  • Processor:
    Dual-Core 1 GHz AMD G-Series APU T40E
  • Main Memory:
    4 GB DDR3-SDRAM
  • CFast Card:
    Not included
  • Installed Controller Software:
    Not included
  • Engineering Software:
    STEP 7 V14 or higher
  • Rated Supply:
    24 V DC
  • Permitted Supply Range:
    19.2 to 28.8 V DC
  • Rated Current Consumption:
    1.5 A with modules and USB load
  • Typical No-Load Current:
    0.6 A
  • Maximum Power Consumption:
    36 W
  • Maximum ET 200SP Modules:
    64
  • Industrial Ethernet Interfaces:
    2
  • PROFINET Interface:
    X1 through BusAdapter
  • X1 Data Rate:
    100 Mbit/s
  • X2 Data Rate:
    1000 Mbit/s
  • USB Interfaces:
    3 x USB 2.0
  • Video Interface:
    1 x DVI-I
  • SD Card Slots:
    1
  • Operating Temperature:
    0 to 60 °C depending on configuration
  • Storage and Transport Temperature:
    -40 to 70 °C
  • Weight:
    2.218 lbs (1.006 kg)
  • Estimated shipping dimensions:
    18.9x14.2x9.2cm
  • Tariff Code:
    85371091
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Spare Scope Network Interfaces Storage & I/O Rack & Climate

Features:

  • The 4 GB CPU 1515SP PC spare provides controller hardware without a CFast card, operating system, or control software.
  • BusAdapter PROFINET and integrated gigabit Ethernet separate the automation network from the additional industrial Ethernet path.
  • The head module feeds a one-row ET 200SP station and works with the supplied server module at the end of the rail.
Siemens 6ES7677-2AA40-0AA0 is the hardware base on which the approved CFast image and controller software must be restored.

The X1 and X2 connections of 6ES7677-2AA40-0AA0 serve different physical network roles and data rates.

Station length, USB loading, and mounting orientation determine the thermal operating boundary of 6ES7677-2AA40-0AA0.

The Siemens 6ES7677-2AA40-0AA0 CPU 1515SP PC 4 GB Spare Controller Hardware may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6ES7677-2AA40-0AA0 CPU 1515SP PC 4 GB Spare Controller Hardware Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Included Hardware and Missing Image

  • Included unit: The spare order includes the CPU hardware, strain relief with screws, and server module.
  • Missing CFast: No CFast card is supplied with the spare article.
  • Missing software: The operating system, software controller, visualization runtime, and licenses are outside this order.
  • Restoration boundary: The approved storage image and licenses must be prepared before controller functions can run.

PROFINET and Industrial Ethernet Paths

  • X1 interface: A BusAdapter supplies two 100 Mbit/s PROFINET ports at the station head.
  • X2 interface: The integrated RJ45 connection provides a separate 1000 Mbit/s Industrial Ethernet path.
  • Optional PROFIBUS: A CM DP module adds the documented RS485/PROFIBUS connection.
  • Service mapping: Device names, IP settings, and project assignments must match the restored software image.

Local Media and Service Connections

  • Main memory: The dual-core PC hardware uses 4 GB of DDR3-SDRAM.
  • SD slot: One SD card slot is available for optional mass storage.
  • USB group: Three front USB 2.0 ports share the documented current-loading boundary.
  • Display output: The DVI-I interface connects the supported local display path.

Station Length and Thermal Limits

  • Module chain: One rail contains the CPU, up to 64 ET 200SP modules, and the server module.
  • Backplane power: The integrated supply feeds the central module chain from the 24 V DC input.
  • Horizontal limit: Up to 60 °C is allowed only with the stated 32-module and USB-load condition.
  • Vertical limit: Vertical mounting is limited to 50 °C with the stated 32-module and USB-load condition.
Description
Siemens 6ES7677-2AA40-0AA0 is a 4 GB CPU 1515SP PC spare hardware unit for the ET 200SP Open Controller platform. It provides the industrial PC, ET 200SP backplane supply, network interfaces, and local service connections, but it does not include a CFast card, operating system, or controller software.

Within an ET 200SP station, 6ES7677-2AA40-0AA0 mounts at the head of one rail and feeds the backplane for as many as 64 I/O modules before the supplied server module closes the assembly. The BusAdapter on X1 selects the two-port PROFINET medium, while the integrated X2 RJ45 path remains a separate gigabit Industrial Ethernet connection.

A dual-core processor and 4 GB DDR3 memory form the computing base of 6ES7677-2AA40-0AA0. One SD slot can add mass storage, but the missing CFast card means the replacement hardware must receive the correct approved storage image and licensed software before controller or HMI functions exist.

The 24 V DC input of 6ES7677-2AA40-0AA0 supplies the PC electronics, connected ET 200SP modules, and the permitted USB load. Operating-temperature limits change with station length, USB current, and mounting orientation, so the assembled rail rather than the spare CPU alone determines the valid thermal configuration.
Alternative Names
6ES76772AA400AA0 6ES7677 2AA40 0AA0 6ES7 677 2AA40 0AA0 Siemens 6ES7677-2AA40-0AA0 6ES7677-2AA40-0AA0 CPU 1515SP PC 4 GB Spare 6E57677-2AA40-0AA0 6ES7677-2AA4O-0AA0 6ES7677-2AA40-OAAO
Technical notes
Siemens 6ES7677-2AA40-0AA0 supplies CPU 1515SP PC hardware, ET 200SP backplane integration, dual Ethernet paths, and local I/O without CFast or software.
