          Quotations, product manuals, and LOGO!Power input/output verification for 6EP1322-1SH03 are available from Apter Power.

        6EP1322-1SH03

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Siemens 6EP1322-1SH03 is a LOGO!Power stabilized supply that accepts wide-range AC or DC input and delivers an adjustable 12 V DC output rated at 4.5 A.
        In Stock
        Ships by Wednesday, October 28
        Fast Shipping Available
        Get a quick price for 6EP1322-1SH03
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 6EP1322-1SH03

        • Manufacturer:
          Siemens
        • Part Number:
          6EP1322-1SH03
        • Product Family:
          Siemens SITOP
        • Product Type:
          LOGO!Power 12 V DC 4.5 A Stabilized Power Supply
        • Stock:
          1
        • Input Type:
          Single-phase AC or DC
        • Rated AC Input:
          100–240 V AC
        • Permissible AC Range:
          85–264 V AC
        • Permissible DC Range:
          110–300 V DC
        • Line Frequency:
          47–63 Hz
        • Minimum Mains Buffering:
          40 ms at 187 V
        • Rated Output:
          12 V DC, 4.5 A
        • Output Adjustment:
          10.5–16.1 V DC
        • Rated Output Power:
          50 W
        • Operating Indicator:
          Green output-OK LED
        • Current Limiting:
          5.8 A
        • Continuous Short-Circuit Current:
          Maximum 7 A
        • Parallel Operation:
          Maximum two units
        • Efficiency:
          Approximately 84%
        • Mounting:
          TH35 rail to EN 60715
        • Degree of Protection:
          IP20
        • Operating Temperature:
          -20 to +70 °C; derating above +55 °C
        • Weight:
          0.551 lbs (0.25 kg)
        • Estimated shipping dimensions:
          9×7.2×5.31cm
        • Tariff Code:
          85044090
        • Country of origin:
          Germany
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Input Selection Output Adjustment Overload Response Rail Integration

        Features:

        • Wide-range AC and DC inputs feed one stabilized secondary output.
        • The 12 V DC output can be adjusted from 10.5 to 16.1 V.
        • Current limiting, short-circuit protection and an output-OK LED are built in.
        Siemens 6EP1322-1SH03 occupies a 72 mm DIN-rail width and supplies up to 4.5 A for the connected 12 V control circuit.

        Two positive and two negative screw terminals provide duplicated landing points on the same regulated output potential.

        Natural convection governs enclosure placement, with full rated output available through +55 °C before derating begins.

        The Siemens 6EP1322-1SH03 LOGO!Power 12 V DC 4.5 A Stabilized Power Supply may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Siemens 6EP1322-1SH03 LOGO!Power 12 V 4.5 A Supply Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        AC and DC Source Path

        • AC entry: A single-phase source connects within the documented 85 to 264 V AC range.
        • DC entry: The same input section accepts 110 to 300 V DC when a DC source is used.
        • Frequency boundary: AC operation remains within the 47 to 63 Hz line-frequency window.
        • Buffer interval: At 187 V input, stored energy maintains rated output for at least 40 ms during a line interruption.

        Voltage Setting and Terminal Relationship

        • Rated point: The nominal secondary condition is 12 V DC at 4.5 A.
        • Adjustment control: The front potentiometer moves the regulated value between 10.5 and 16.1 V.
        • Terminal pairing: Two positive screws share one output potential and two negative screws share the return.
        • Local indication: The green LED confirms that the regulated output remains present.

        Current Boundary Behavior

        • Normal region: The supply holds the selected voltage until load demand reaches the current limit.
        • Limiting point: Output current is limited at 5.8 A rather than increasing without control.
        • Short circuit: The secondary remains protected with no more than 7 A continuous short-circuit current.
        • Parallel limit: Only two identical units are permitted in a parallel power arrangement.

        Mounting and Cooling Boundary

        • Carrier: The enclosure snaps onto a TH35 mounting rail to EN 60715.
        • Cooling method: Heat is removed by natural convection without a fan.
        • Rated-temperature point: Full output is available through +55 °C.
        • Upper range: Operation may continue to +70 °C when the documented derating is applied.
        Description
        The compact Siemens 6EP1322-1SH03 belongs to the LOGO!Power family and converts a single-phase AC or DC source into a stabilized 12 V DC supply. Its input stage accepts 85 to 264 V AC or 110 to 300 V DC, allowing the same unit to operate from either documented source type without changing the output function.

        A front potentiometer sets the output of 6EP1322-1SH03 between 10.5 and 16.1 V. The regulated output is rated at 4.5 A and 50 W, while two positive and two negative screw terminals divide the outgoing conductors without altering their common electrical potential.

        When loading reaches the current boundary, 6EP1322-1SH03 limits output current at 5.8 A and remains short-circuit proof with a continuous short-circuit value of no more than 7 A. The green output-OK indicator follows the secondary voltage, and a minimum 40 ms buffering interval at 187 V carries the output through a brief input interruption.

        For enclosure integration, 6EP1322-1SH03 snaps onto a TH35 rail and relies on natural convection. It can deliver rated output through +55 °C before temperature derating applies, with operation extending from -20 to +70 °C; no more than two identical units may be connected in parallel when additional output capacity is required.
        Alternative Names
        Siemens 6EP1322-1SH03 LOGO!Power LOGO!Power 12 V 4.5 A 6EP1322-1SH03 6EP13221SH03 Stabilized Supply 6EP 1322-1SH03 DIN-Rail Power Unit Siemens 12 VDC Supply 6EP1322-1SH03 6EP1322-1SH03 50 W Power Supply LOGO Power Module 6EP1322-1SH03 Siemens 6EP1322-1SH03 AC/DC Input Supply
        Technical notes
        Siemens 6EP1322-1SH03 uses one common electrical potential across its paired positive and paired negative output terminals; the additional terminals do not create isolated output channels.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Can 6EP1322-1SH03 be powered from a DC control bus instead of AC mains?
        Yes. 6EP1322-1SH03 accepts 110 to 300 V DC as well as 85 to 264 V AC, provided the input connection follows the documented polarity and protection requirements.
        Why does the output of 6EP1322-1SH03 measure above 12 V after installation?
        The output potentiometer on 6EP1322-1SH03 permits adjustment from 10.5 to 16.1 V, so verify its setting before treating a value above 12 V as a fault.
        Do the two positive terminals on 6EP1322-1SH03 provide separate isolated channels?
        No. Both positive terminals on 6EP1322-1SH03 share the same regulated output potential, and the two negative terminals share the common return.
        What happens when a connected load exceeds the rating of 6EP1322-1SH03?
        6EP1322-1SH03 enters current limiting at 5.8 A and is short-circuit proof, with continuous short-circuit current limited to a maximum of 7 A.
        At what cabinet temperature must 6EP1322-1SH03 be derated?
        The rated output of 6EP1322-1SH03 is available through +55 °C; above that point, apply the documented derating up to the +70 °C operating limit.
        How many 6EP1322-1SH03 units may be connected in parallel?
        Siemens permits a maximum of two 6EP1322-1SH03 supplies in the documented parallel arrangement; verify matched voltage settings before joining their outputs.
