Siemens 6ES7314-6CH04-0AB0 is a SIMATIC S7-300 CPU 314C-2 DP with integrated I/O, MPI and PROFIBUS DP connectivity.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for 6ES7314-6CH04-0AB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7314-6CH04-0AB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7314-6CH04-0AB0
  • Product Family:
    Siemens Simatic S7-300
  • Product Type:
    SIMATIC S7-300 CPU 314C-2 DP Compact Controller
  • Stock:
    1
  • Work Memory:
    192 KB
  • Integrated Digital I/O:
    24 DI / 16 DO
  • Integrated Analog I/O:
    4 AI / 2 AO / 1 Pt100
  • High-Speed Counters:
    4, up to 60 kHz
  • Communication:
    MPI and PROFIBUS DP
  • Power Supply:
    24 VDC
  • Weight:
    0.726 kg
  • Estimated shipping dimensions:
    13.4 x 15.4 x 12.9 cm
  • Tariff Code:
    85371091
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals CPU Identity Integrated I/O Recovery Scope Applications

Features:

  • Compact CPU and I/O: Processing, mixed integrated signals and high-speed counters share one S7-300 module.
  • PROFIBUS DP identity: The second communication role is DP, not the PROFINET interface used by a different CPU variant.
  • Memory-card dependency: The required Micro Memory Card remains part of the controller recovery path.
6ES7314-6CH04-0AB0 is the S7-300 CPU 314C-2 DP with 192 KB work memory.

Its integrated I/O and counters reduce separate module count, but they also make wiring and program recovery part of the same replacement event.

The DP suffix, memory card and two front connectors are the fastest ways to separate this CPU from similar 314C variants.

Apter Power can help confirm the Siemens 6ES7314-6CH04-0AB0 SIMATIC S7-300 CPU 314C-2 DP, memory card and connector scope before quotation.
Siemens 6ES7314-6CH04-0AB0 SIMATIC S7-300 CPU 314C-2 DP Compact Controller Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • 314C-2 DP platform: The CPU combines compact control with integrated PROFIBUS DP communication.
  • MPI engineering path: The MPI interface remains available for the documented S7-300 communication and service tasks.
  • No PROFINET port: PN/DP functions belong to another order code and must not be inferred here.
  • 192 KB work memory: Program fit is checked against the exact project rather than a family name alone.
  • Digital channels: Twenty-four inputs and sixteen outputs are part of the CPU hardware.
  • Analog channels: Four inputs, two outputs and one Pt100 path require preserved terminal assignments.
  • High-speed counters: Four channels support pulse tasks up to the documented frequency.
  • Single replacement boundary: A CPU exchange can affect logic, communications and integrated field circuits together.
  • Micro Memory Card: The required card and its valid project content are confirmed before power-up.
  • Front connectors: Two 40-pole connectors must be available, reusable and correctly labeled.
  • STEP 7 project: Hardware configuration and network addresses are recovered from the controlled backup.
  • Commissioning order: CPU state, DP network and each integrated-I/O group are tested separately.
  • Compact machine control: Combines logic and mixed I/O where a small S7-300 footprint is valuable.
  • PROFIBUS cells: Acts as the CPU in systems that retain a DP network rather than PROFINET.
  • Counter applications: Supports suitable pulse and speed measurement tasks through integrated high-speed counters.
  • Legacy S7-300 maintenance: Restores an exact controller while a phased migration is planned independently.
Description
6ES7314-6CH04-0AB0 is a compact S7-300 CPU that combines 192 KB of work memory with integrated digital and analog I/O, a Pt100 channel and high-speed counters. Its communication identity is CPU 314C-2 DP, using MPI and an integrated PROFIBUS DP interface rather than PROFINET.

A replacement 6ES7314-6CH04-0AB0 still requires the two 40-pole front connectors and a Micro Memory Card. Siemens has placed the product in phase-out, so program backup, memory-card condition and connector scope should be resolved before the installed controller is disturbed.
Alternative Names
6ES73146CH040AB0
Technical notes
6ES7314-6CH04-0AB0 is the CPU 314C-2 DP version with MPI and integrated PROFIBUS DP; it is not the PN/DP model. The two 40-pole front connectors and Micro Memory Card are required separately. Preserve the STEP 7 project, hardware configuration, memory card and I/O wiring before exchanging the phased-out CPU.
