6ES7432-1HF00-0AB0

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6ES7432-1HF00-0AB0 is an eight-channel SM 432 analog output module for SIMATIC S7-400 systems. It delivers isolated voltage or current commands with 13-bit resolution for continuous process control.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7432-1HF00-0AB0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7432-1HF00-0AB0

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7432-1HF00-0AB0
  • Product Family:
    Siemens Simatic S7-400
  • Product Type:
    SIMATIC S7-400 SM 432 Analog Output Module
  • Stock:
    1
  • Analog outputs:
    8
  • Signal types:
    Voltage or current
  • Resolution:
    13 bit
  • Channel isolation:
    Isolated
  • Module family:
    SM 432
  • Platform:
    SIMATIC S7-400
  • Configuration tool:
    STEP 7 hardware configuration
  • Packaging width:
    23.30 cm
  • Packaging height:
    29.90 cm
  • Packaging depth:
    4.10 cm
  • Country of origin:
    Germany
  • Commodity code:
    85389091
  • Lifecycle note:
    Product phase-out announced
  • Weight:
    1.724 lbs (0.782 kg)
  • Estimated shipping dimensions:
    29.90 x 23.30 x 4.10 cm
  • Tariff Code:
    85389091
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Configuration Diagnostics Integration

Features:

  • Combines eight analog command channels in one SM 432 module.
  • Supports configured voltage and current output ranges.
  • Provides 13-bit conversion with channel-to-system isolation.
The complete order number denotes this specific eight-channel S7-400 execution. Similar SM 432 articles may use different channel counts, ranges or resolution and cannot be selected by the family name alone.

It converts numeric process commands into real field signals, allowing the controller to position or regulate equipment rather than merely switch it. The module therefore sits in the final command path of closed-loop automation.

Preserve the original front-connector schedule and archive the STEP 7 configuration before removal. A controlled loop test should compare commanded and measured response after the hardware exchange.

Phase-out status makes exact-order-number verification essential before sourcing 6ES7432-1HF00-0AB0.
Verified resources for Siemens 6ES7432-1HF00-0AB0:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Issue analog speed references to variable-speed drive systems.
  • Position modulating valves from an S7-400 process controller.
  • Generate laboratory or production setpoints through isolated standard signals.
  • Select the voltage or current range independently for every used output channel.
  • Keep engineering-unit scaling aligned with the raw value expected by the control program.
  • Define substitute outputs deliberately so a CPU transition does not create an unsafe command.
  • Controller diagnostics separate module faults from open or overloaded field loops.
  • Measured signal checks should be performed with the associated actuator secured.
  • Store the commissioning result for each channel as part of the maintenance baseline.
  • The station hardware catalog entry must match this exact SM 432 article number.
  • Front-connector keying and reference-potential wiring must agree with the installed rack design.
  • Download only the approved S7-400 hardware configuration after replacement.
Description
6ES7432-1HF00-0AB0 belongs to the SM 432 analog-output range used in SIMATIC S7-400 stations. Eight isolated channels translate controller values into selectable voltage or current signals, and the documented 13-bit conversion supports applications that require finer command steps than simple on/off control.

The module is typically positioned between the S7-400 process image and continuously controlled equipment such as valve positioners, drive references or laboratory actuators. Because the channels share one hardware module but remain individually engineered, each loop can be assigned the range and scaling required by its connected device.

A replacement must reproduce the STEP 7 hardware entry, channel addresses, output ranges, diagnostic settings and substitute-value behavior already validated for the plant. Front-connector wiring and field load limits also require a point-by-point check, especially when an older S7-400 station is being maintained during a phased migration.
Alternative Names
6ES7432-1HF00-0AB0 6ES7432 1HF00 0AB0 6ES74321HF000AB0 Siemens 6ES7432-1HF00-0AB0 6ES7432-1HF00-0AB0 SIMATIC S7-400 SM 432 Siemens SIMATIC S7-400 SM 432 Analog Output Module 6ES7432-1HF00-0AB0 SIMATIC S7-400 SM 432 Analog Output Module
Technical notes
6ES7432-1HF00-0AB0 outputs can move connected actuators as soon as the CPU resumes control; isolate the process, confirm substitute values and test each loop under an approved safe-state procedure.
