ABB 07KT92 GJR5250500R0202 is the 24 V DC Procontic CS31 central unit revision R202 without ARCnet.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 07KT92 GJR5250500R0202
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 07KT92 GJR5250500R0202

  • Manufacturer:
    ABB
  • Part Number:
    07KT92 GJR5250500R0202
  • Product Family:
    ABB Procontic
  • Product Type:
    Procontic CS31 Central Unit R202
  • Stock:
    1
  • ABB Order Number:
    GJR5250500R0202
  • Revision:
    R202 without ARCnet
  • Related Configuration:
    R262 GJR5250500R0262 with ARCnet
  • Supply:
    24 V DC
  • Digital I/O:
    12 inputs; 8 transistor outputs
  • Analog I/O:
    4 inputs; 2 outputs
  • Program and Data Memory:
    128 kB flash; 256 kB RAM
  • Serial Interfaces:
    2
  • CS31 System Bus:
    RS-485
  • High-Speed Counter:
    50 kHz
  • Remote Modules:
    Up to 31
  • Weight:
    1.6 kg
  • Estimated shipping dimensions:
    24x14x8.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Revision Check CS31 Integration Maintenance

Features:

  • Integrated local I/O: Digital and analog channels support compact machine and process-control tasks.
  • CS31 expansion: The controller can coordinate up to 31 remote modules through the RS-485 system bus.
  • Revision-specific networking: R202 is the official non-ARCnet configuration and must not be confused with the other revision.
07KT92 GJR5250500R0202 R202 combines controller, local I/O, serial communication, and CS31 remote expansion in one central unit.

Its retained RAM and real-time data depend on the approved 07LE90 lithium battery when the supply is removed; battery handling must follow the ABB manual.

Before reuse or replacement, identify the complete order number, archive the program, verify the engineering software, compare I/O and communication wiring, and test every safe-state response.

Availability is subject to Apter Power's current inventory and sourcing confirmation.
ABB 07KT92 GJR5250500R0202 Manuals, Datasheets, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB 07KT92 GJR5250500R0202 Specs

General

  • ManufacturerABB
  • Model07KT92 GJR5250500R0202
  • ConditionNew Original ready stock
  • Product FamilyABB Procontic CS31
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

R202 and R262 distinction

  • Complete order number: Use GJR5250500R0202 to identify the requested R202 configuration.
  • ARCnet: R202 does not include the documented ARCnet interface.
  • Related configuration: R262 GJR5250500R0262 adds ARCnet.
  • Replacement: Do not assume a slot-in replacement without reviewing networking, wiring, software, and the validated application.

Remote-bus planning

  • Addressing: Record every remote module and CS31 station address.
  • Termination: Verify RS-485 cable, shielding, reference potential, and end termination.
  • Capacity: Keep the installed remote-module count within the documented architecture.
  • Acceptance: Test bus diagnostics and I/O updates under the final scan load.

Program and data protection

  • Engineering tools: Confirm both 907 PC 33 and 907 PC 331 are available for the project.
  • Program backup: Retrieve and verify the application before disturbing the installed unit.
  • Battery: Use only the approved 07LE90 module and replace it with supply applied as instructed.
  • Wiring record: Preserve terminal maps, analog scaling, communication settings, and startup values.
Description
07KT92 GJR5250500R0202 is the R202 configuration of ABB’s 07KT92 GJR5250500R0202 central unit for Procontic CS31 programmable control systems, combining local digital and analog I/O with controller and remote-bus functions.

07KT92 GJR5250500R0202 provides 12 digital inputs, 8 transistor outputs, 4 analog inputs, 2 analog outputs, two serial interfaces, a 50 kHz high-speed counter, 128 kB flash, 256 kB RAM, and support for up to 31 remote modules.

07KT92 GJR5250500R0202 requires the exact revision to be matched before replacement: R202 GJR5250500R0202 has no ARCnet, while R262 GJR5250500R0262 adds ARCnet; engineering also depends on 907 PC 33/331, CS31 addressing, power, I/O wiring, and the optional 07LE90 battery.
Alternative Names
07KT92 07 KT 92 R202 07KT92 R202 GJR5250500R0202 GJR5 2505 00 R0202 ABB 07KT92 GJR5250500R0202
Technical notes
07KT92 GJR5250500R0202 (R202) has no ARCnet; R262 GJR5250500R0262 adds that interface. Before replacement, verify the full nameplate, 24 V DC supply, CS31 addressing and termination, 907 PC 33/331 project access, I/O mapping, retained program backup, and whether the optional 07LE90 battery is installed and serviceable before controlled commissioning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How can engineers distinguish 07KT92 GJR5250500R0202 R202 from the other 07KT92 GJR5250500R0202 revision?
Read the complete order number: GJR5250500R0202 identifies R202. R202 GJR5250500R0202 has no ARCnet, while R262 GJR5250500R0262 adds the ARCnet interface.
Can 07KT92 GJR5250500R0202 R202 replace the other revision without program or wiring changes?
No complete interchangeability is documented. Compare ARCnet, CS31, serial interfaces, I/O mapping, engineering project, battery-backed data, cables, and the validated startup sequence.
What software is required to maintain 07KT92 GJR5250500R0202 R202?
ABB’s scope lists both 907 PC 33 programming/test software and 907 PC 331 for the 07KT92 GJR5250500R0202-specific description; preserve compatible media, interfaces, and project backups.
Why can 07KT92 GJR5250500R0202 R202 lose retained data after power-off?
Check whether the approved 07LE90 lithium battery is installed, healthy, correctly connected, and replaced with supply applied; also verify that the retained data was actually configured.
What should be checked when 07KT92 GJR5250500R0202 R202 remote I/O remains offline?
Inspect CS31 addressing, RS-485 polarity, shield and reference potential, termination, cable continuity, remote power, module configuration, and controller diagnostics.
What belongs in an RFQ for 07KT92 GJR5250500R0202 R202?
Provide the complete order number, revision, ARCnet requirement, quantity, condition, software and cable scope, nameplate photos, destination, and required delivery date.
