          Apter Power supplies 330704-000-078-10-01-05 quotations, datasheets, and 3300 XL 11 mm configuration matching.

        330704-000-078-10-01-05

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 330704-000-078-10-01-05 is an armored M14 × 1.5 3300 XL 11 mm proximity probe that forms the sensing interface for non-contacting vibration and displacement measurements.
        In Stock
        Ships by Tuesday, September 29
        Fast Shipping Available
        Get a quick price for 330704-000-078-10-01-05
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330704-000-078-10-01-05

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330704-000-078-10-01-05
        • Product Family:
          3300 XL 11mm Proximity Transducer System
        • Product Type:
          3300 XL 11 mm Armored Metric Proximity Probe
        • Stock:
          1
        • Thread:
          M14 × 1.5
        • Probe Armor:
          Armored
        • Unthreaded Length:
          0 mm
        • Overall Case Length:
          78 mm
        • Total Probe Length:
          1.0 m
        • Connector Option:
          Miniature coaxial ClickLoc with connector protector
        • Cable Option:
          Standard cable
        • Agency Approval:
          Multiple Approvals
        • System Linear Range:
          4.0 mm
        • Tariff Code:
          9031809090
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Probe Geometry Signal Path Gap & Range Applications

        Features:

        • Armored M14 × 1.5 construction defines the probe mounting thread.
        • The 000 and 078 codes specify its insertion geometry.
        • A protected ClickLoc termination completes the integral probe lead.
        The complete ordering number distinguishes this exact armored metric assembly within the 3300 XL 11 mm probe family.

        Mechanical codes define the probe body independently from the electrical characteristics of the matched transducer system.

        The probe, extension cable, and Proximitor Sensor operate together as one calibrated non-contacting measurement chain.

        The Bently Nevada 330704-000-078-10-01-05 Armored Metric Proximity Probe may be available with quotation and technical support from Apter Power.
        Bently Nevada 330704-000-078-10-01-05 Armored Metric Proximity Probe Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Mounting dimensions

        • Thread: The probe case uses an M14 × 1.5 metric mounting thread.
        • Armor: Cable armor is included in the 330704 construction.
        • Unthreaded length: The 000 code specifies 0 mm.
        • Case length: The 078 code specifies a 78 mm overall case.

        Transducer chain

        • Probe stage: The tip senses distance to the conductive target without mechanical contact.
        • Integral lead: A 1.0 m standard cable carries the probe signal.
        • Connection: A protected miniature coaxial ClickLoc connector joins the next cable section.
        • Sensor stage: The matching extension cable completes the path to the 3300 XL 11 mm Proximitor Sensor.

        Matched system behavior

        • Linear span: The matched 3300 XL 11 mm system provides a 4.0 mm range.
        • Operating gap: The recommended probe gap is 2.5 mm.
        • Scale factor: Nominal system sensitivity is 3.94 V/mm.
        • Measurement: Output voltage changes with probe-to-target distance for displacement and vibration measurement.

        Documented measurement uses

        • Axial position: The 3300 XL 11 mm system supports thrust-position measurement.
        • Expansion: Ramp differential expansion on steam turbines is a documented use.
        • Rod movement: The system supports rod-position and rod-drop measurement on reciprocating compressors.
        • Speed reference: Supported functions include tachometer, zero-speed, and Keyphasor measurements.
        Description
        Bently Nevada 330704-000-078-10-01-05 is an armored metric probe in the 3300 XL 11 mm Proximity Transducer System. The probe observes shaft position without contact and forms the sensing element used for vibration and displacement measurement.

        The mechanical configuration of 330704-000-078-10-01-05 combines an M14 × 1.5 threaded case with cable armor. Its ordering code specifies 0 mm of unthreaded length and a 78 mm overall case length, defining the insertion and mounting geometry for this exact probe.

        Signal routing from 330704-000-078-10-01-05 uses a 1.0 m standard integral cable and a miniature coaxial ClickLoc connector with a connector protector. The probe connects through the matching extension cable to the 3300 XL 11 mm Proximitor Sensor, completing the transducer signal path.

        When incorporated into a matched 3300 XL 11 mm system, 330704-000-078-10-01-05 supports the 4.0 mm linear measurement range, 2.5 mm recommended gap, and 3.94 V/mm scale factor specified for the system. The final 05 code denotes the Multiple Approvals option.
        Alternative Names
        330704-000-078-10-01-05 330704 000 078 10 01 05 330704000078100105 Bently Nevada 330704-000-078-10-01-05 Baker Hughes 330704-000-078-10-01-05 BN 330704-000-078-10-01-05 3300 XL 11 mm 330704-000-078-10-01-05 33O704-000-078-10-01-05
        Technical notes
        Bently Nevada 330704-000-078-10-01-05 is an armored M14 × 1.5 probe with a 78 mm case, a 1.0 m standard cable, and the Multiple Approvals option.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What does the 078 case-length code mean for 330704-000-078-10-01-05?
        For 330704-000-078-10-01-05, the 078 code specifies a 78 mm overall case length. This is the probe-body dimension to compare with the mounting arrangement.
        Why does 330704-000-078-10-01-05 use the 000 unthreaded-length code?
        The 000 segment in 330704-000-078-10-01-05 specifies 0 mm of unthreaded length. The threaded M14 × 1.5 case therefore begins without an added unthreaded section.
        Which connector is supplied on 330704-000-078-10-01-05?
        330704-000-078-10-01-05 uses a miniature coaxial ClickLoc connector with a connector protector and standard cable. Match the mating extension cable to the same 3300 XL 11 mm system.
        How should an extension cable be selected for 330704-000-078-10-01-05?
        330704-000-078-10-01-05 has a 1.0 m total probe length. Choose the extension cable so the probe length plus extension-cable length equals the total length specified for the connected 3300 XL 11 mm Proximitor Sensor.
        What gap and measuring span apply to 330704-000-078-10-01-05 in the matched system?
        In a correctly matched 3300 XL 11 mm system, 330704-000-078-10-01-05 is set around the 2.5 mm recommended gap and supports the system’s 4.0 mm linear range.
        Which approval option is encoded in 330704-000-078-10-01-05?
        The final 05 segment identifies 330704-000-078-10-01-05 as the Multiple Approvals configuration. Verify the applicable approval documentation for the installation location.
