IS210DTAIH1A

/ 4.9
1001 reviews | Need a Specific Revision?
As a Mark VI simplex analog I/O terminal board, General Electric IS210DTAIH1A terminates ten field inputs and two current-output channels for a VAIC processor.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for IS210DTAIH1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IS210DTAIH1A

  • Manufacturer:
    General Electric
  • Part Number:
    IS210DTAIH1A
  • Product Family:
    GE Mark VI Gas Turbine Control
  • Product Type:
    Simplex Analog Input/Output Terminal Board
  • Stock:
    1
  • Analog Inputs:
    10
  • Analog Outputs:
    2
  • Input Wiring:
    2-, 3-, or 4-wire transmitters
  • Voltage Inputs:
    ±5 VDC or ±10 VDC
  • Current Outputs:
    0–20 mA; output 1 selectable to 0–200 mA
  • Processor Board:
    VAIC
  • Processor Connector:
    One 37-pin cable
  • Field Terminals:
    48-position Euroblock
  • Maximum Cable Length:
    300 m with 15 ohms two-way resistance
  • Operating Temperature:
    0 to 60 °C
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Input Modes Output Setup Field Wiring Fault Checks

Features:

  • Ten field channels accept supported current and bipolar voltage input arrangements.
  • Two output channels provide 0–20 mA, with a 200 mA option on output 1.
  • Two compact terminal boards can populate the full VAIC analog I/O capacity.
IS210DTAIH1A brings mixed analog input and output termination to a single simplex connector rather than separating the two signal directions across different assemblies.

Per-channel input jumpers make the electrical termination agree with the transmitter wiring, while J0 changes only the first output range.

SCOM, cable resistance, and load boundaries define how the field loop and processor-side current feedback remain referenced across the installation.

The General Electric IS210DTAIH1A Simplex Analog I/O Terminal Board may be sourced with supporting product information through Apter Power.
General Electric IS210DTAIH1A Simplex Analog Input/Output Terminal Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Input Modes

  • Current Signals: The ten channels accept the stated current-input circuits.
  • Voltage Ranges: Bipolar ±5 VDC and ±10 VDC inputs are supported.
  • Transmitter Wiring: Two-, three-, four-wire, and externally powered arrangements are accommodated.
  • Channel Selection: Each input uses its associated jumper pair for current or voltage mode.

Output Setup

  • Standard Range: Both analog outputs operate over 0–20 mA.
  • Extended Range: Output 1 can be selected for 0–200 mA.
  • Selector: J0 changes the range of output 1.
  • Load Boundary: The 20 mA and 200 mA ranges use 500-ohm and 50-ohm maximum loads respectively.

Field Wiring

  • Terminal Block: A 48-position Euroblock accepts field conductors.
  • SCOM: Terminals 43 and 44 provide the SCOM connection.
  • Cable Limit: Cable length can reach 300 m within the 15-ohm two-way resistance limit.
  • Shielding: The compact board has no separate shield strip.

Fault Checks

  • Output Health: Current feedback is compared with the output command.
  • ID Data: The connector path returns terminal-board identification.
  • Mismatch Alarm: An unexpected board identity is reported by VAIC.
  • Simplex Scope: The compact DTAI interface is used on the simplex VAIC path.
Description
General Electric IS210DTAIH1A is a compact analog input/output terminal board for a simplex Mark VI VAIC path. Ten analog inputs and two analog outputs are collected on one DIN-rail assembly and transferred to the processor through a single 37-pin connector.

Field transmitters connected to IS210DTAIH1A may use two-, three-, or four-wire arrangements, including externally powered circuits. The input channels accept current signals and the specified bipolar voltage ranges, while channel jumpers establish the required current or voltage termination.

The two output circuits on IS210DTAIH1A normally provide 0–20 mA signals. Output 1 can instead be set for a 0–200 mA range by J0, aligning the channel with either a 500-ohm or 50-ohm maximum load.

A 48-position Euroblock carries the field connections for IS210DTAIH1A, with SCOM provided at terminals 43 and 44. Up to 300 m of shielded cable is supported within the stated 15-ohm two-way resistance boundary, and the board has no separate shield strip.

Output-current feedback and electronic identification are checked through the IS210DTAIH1A processor link. An unhealthy output condition or an unexpected board identity is reported through VAIC diagnostics rather than concealed at the terminal board.
Alternative Names
General Electric IS210DTAIH1A IS210-DTAI-H1A IS210 DTAI H1A IS 210 DTAI H1A GE IS210DTAIH1A GE Energy IS210DTAIH1A IS210DTAIH1A Analog I/O Terminal Board IS21ODTAIH1A
Technical notes
General Electric IS210DTAIH1A combines ten configurable analog inputs with two current outputs on one simplex VAIC terminal interface.
