General Electric IC610CHS101 is a non-expandable five-slot Series One rack that powers a CPU and local I/O modules from 115 or 230 VAC.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IC610CHS101
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC610CHS101

  • Manufacturer:
    General Electric
  • Part Number:
    IC610CHS101
  • Product Family:
    GE Intelligent Platforms
  • Product Type:
    Series One 5-Slot AC-Powered Rack
  • Stock:
    1
  • Rack capacity:
    5 module positions
  • Input voltage:
    115/230 VAC, ±15%
  • Input frequency:
    47 to 63 Hz
  • Maximum input load:
    30 VA
  • Internal 5 VDC output:
    0.4 A
  • Internal 9 VDC output:
    0.6 A
  • Internal 24 VDC output:
    0.2 A
  • Expansion port:
    Not provided
  • External 24 VDC terminals:
    Not provided
  • RUN relay:
    Not provided
  • Rack dimensions:
    29 x 12 x 14 cm
  • Operating temperature:
    0 to 60 °C
  • Humidity:
    5 to 95%, non-condensing
  • Cooling method:
    Natural convection
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Rack Layout AC Power Load Budget Installation

Features:

  • Five module positions combine a Series One CPU location with up to four local I/O slots.
  • The integrated supply accepts 115 or 230 VAC at 47 to 63 Hz.
  • The low-cost rack omits the expansion connector, external 24 VDC terminals and RUN relay.
Internal power is available at 5 VDC, 9 VDC and 24 VDC, with separate current ceilings that must be respected when modules are selected.

The rack is designed for horizontal mounting and natural convection, so clear space above and below the chassis supports heat removal.

Its fixed local architecture suits a compact Series One station that does not need downstream expansion hardware.

The General Electric IC610CHS101 Series One 5-Slot AC-Powered Rack may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric IC610CHS101 Series One Rack Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Module Positioning

  • Supply Section: The rack power supply occupies the right side of the chassis.
  • CPU Position: The processor installs directly beside the power-supply section.
  • I/O Capacity: Four remaining positions accept the required input and output mix.
  • Address Basis: Each module's I/O references follow its physical slot.

Supply Characteristics

  • Input Selection: The internal supply accepts 115 or 230 VAC within ±15%.
  • Line Frequency: Permitted AC input is 47 to 63 Hz.
  • Input Demand: Maximum rack supply load is 30 VA.
  • Internal Rails: Installed modules receive regulated 5 VDC, 9 VDC and 24 VDC power.

Backplane Capacity

  • 5 VDC Limit: Available internal current is 0.4 A.
  • 9 VDC Limit: The rack supplies up to 0.6 A on this rail.
  • 24 VDC Limit: Installed modules may draw a combined 0.2 A.
  • Planning Method: Total every module's units of load separately for each rail.

Mounting Conditions

  • Orientation: Install the rack horizontally rather than inverted or rotated.
  • Cooling: Natural convection requires unobstructed airflow above and below the chassis.
  • Clearance: Allow working room at both sides for module removal and service loops.
  • Environment: Operation is specified from 0 to 60 °C at 5 to 95% non-condensing humidity.
Description
General Electric IC610CHS101 is the low-cost five-slot rack for a compact Series One control station. It combines the module backplane with an internal AC power supply so the CPU and local I/O can operate from one chassis assembly.

In the first rack, General Electric IC610CHS101 places the CPU beside the power-supply section and leaves four positions for the required mix of input and output modules. Slot location establishes each module's I/O references, making physical placement part of the control configuration.

The supply in General Electric IC610CHS101 accepts 115 or 230 VAC at 47 to 63 Hz and distributes regulated internal voltages to installed modules. A rack load calculation is necessary because the 5 VDC, 9 VDC and 24 VDC outputs have separate current limits.

Unlike expandable Series One bases, General Electric IC610CHS101 has no expansion connector, external 24 VDC terminals or RUN relay. It is intended for a self-contained local station, with horizontal mounting and unobstructed convection paths around the rack.
Alternative Names
GE IC610CHS101 IC610-CHS101 Series One rack IC610CHS101 IC 610 CHS 101 GE Fanuc IC610CHS101 IC610 CHS101 IC610CHS101 5-slot rack IC610CHS1O1
Technical notes
For General Electric IC610CHS101, keep module demand within 0.4 A at 5 VDC, 0.6 A at 9 VDC and 0.2 A at 24 VDC. Maintain horizontal mounting and clear convection paths around the chassis.
