    Obtain quotation support, technical records and controller-matching help for General Electric DS200SLCCG3A.

DS200SLCCG3A

/ 4.9
1001 reviews | Need a Specific Revision?
The General Electric DS200SLCCG3A LAN Communications Card organizes LCP-to-SDCC data exchange and local operator access for drive and exciter controllers.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for DS200SLCCG3A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS200SLCCG3A

  • Manufacturer:
    General Electric
  • Part Number:
    DS200SLCCG3A
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    LAN Communications Card
  • Stock:
    1
  • Communication Role:
    LAN-side processing and SDCC exchange
  • System Role:
    Drive and exciter communication processing
  • LAN Processor:
    LCP at U1
  • Operating Program:
    EPROM U6 and U7
  • Processor RAM:
    U8 and U9
  • Shared Memory:
    Dual-ported RAM U5
  • Control Card Link:
    3PL to SDCC
  • Power and Data Link:
    2PL to DCFB or SDCI
  • Programmer Link:
    KPPL
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Processor Flow Memory Roles Card Links Display Access

Features:

  • Coordinates LAN-side data handling around the U1 control processor.
  • Separates program, working and shared-memory functions.
  • Provides alphanumeric status and local programmer access.
Communication execution on DS200SLCCG3A begins at the LCP rather than the SDCC regulation processor. That allocation keeps message handling in the LAN layer.

Three memory roles coexist on DS200SLCCG3A: nonvolatile program devices, local working RAM and a dual-access exchange area. Their assignments clarify whether a symptom originates in startup code, temporary data or controller transfer.

The operator surface on DS200SLCCG3A combines the status display with a dedicated keypad/programmer route. These local functions can be evaluated independently from the external board connections.

The General Electric DS200SLCCG3A LAN Communications Card may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS200SLCCG3A LAN Communications Card Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

LAN Computation

  • LCP: U1 performs the communication-processing workload.
  • Controller Peer: The SDCC Drive Control Processor retains drive-control execution.
  • Exchange Point: U5 provides a controlled two-processor data window.
  • Result: LAN messages reach the controller as organized shared data.

Storage Allocation

  • U6 and U7: The paired EPROM devices hold operating code.
  • U8 and U9: Dedicated RAM supports active LCP calculations.
  • U5: Dual-ported memory is accessible from both processors.
  • Identity Check: The installed program pair must match the G3 hardware context.

Inter-card Routing

  • Upstream Side: 2PL joins the DCFB or SDCI power-and-data route.
  • Controller Side: 3PL continues communication toward the SDCC.
  • Division: The two links isolate upstream loss from controller-side loss.
  • Topology: Connector roles define the board position inside the cabinet.

Local Interaction

  • Status Display: Alphanumeric output reports card operating information.
  • KPPL: The keypad/programmer uses a dedicated connection.
  • Diagnostic Value: Local activity does not by itself prove SDCC data exchange.
  • Access Chain: Display behavior depends on LCP execution and the program memory pair.
Description
Within supported GE drive and exciter cabinets, DS200SLCCG3A performs LAN-side computation and passes organized data to the SDCC. The processor, memories, and local interface on this card form the communication layer rather than the drive-regulation loop.

At the center of DS200SLCCG3A is the U1 LAN Control Processor. U6 and U7 retain the operating program, U8 and U9 provide processor working memory, and U5 supplies the dual-access memory area shared with the SDCC Drive Control Processor.

Power and upstream data enter DS200SLCCG3A through 2PL from the DCFB or SDCI side, whereas 3PL carries the inter-card connection to the SDCC. This division identifies which link to follow when external and controller traffic behave differently.

Local interaction with DS200SLCCG3A is handled through the alphanumeric display circuitry and the KPPL keypad/programmer link. The displayed operating state and programmer response therefore depend on both the LCP memory set and the dedicated local-interface connection.
Revisions

Revision Part #

Also known as

DS200SLCCG3AFG
DS200SLCCG3A-FG, Series FG, Rev FG
Alternative Names
GE DS200SLCCG3A DS200-SLCC-G3A DS 200 SLCC G3A General Electric G3 LAN card GE drive communication card G3A SLCC Group 3 interface board DS200 SLCC G3 A DS2OOSLCCG3A
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What does a working display but missing control data indicate on DS200SLCCG3A?
A live display confirms only part of DS200SLCCG3A operation. Check the 3PL path and U5 shared-memory exchange with the SDCC when controller data is absent.
Why would DS200SLCCG3A show an unexpected startup identity?
The operating program for DS200SLCCG3A resides in U6 and U7. Verify that the EPROM pair belongs together and matches the intended drive or exciter configuration.
Where should signal tracing begin when DS200SLCCG3A has no external communication?
Begin at the DS200SLCCG3A 2PL power-and-data route, then follow 3PL toward the SDCC. This separates an upstream interface loss from an interprocessor communication fault.
What can prevent local programmer access on DS200SLCCG3A even when the card is energized?
An open or misaligned KPPL path can leave DS200SLCCG3A powered while the keypad/programmer remains unavailable. Check that dedicated connection before investigating processor memory.
Can DS200SLCCG3A configuration be copied directly from another SLCC group?
Do not assume that for DS200SLCCG3A. Keep the G3 hardware identity, installed memory set, and host wiring together because other SLCC groups can implement different network provisions.
