PS69-DPS

/ 4.9
1001 reviews | Need a Specific Revision?
The ProSoft PS69-DPS is a PROFIBUS DP V0/V1 slave module designed specifically for Allen-Bradley CompactLogix and MicroLogix controllers.
Get a quick price for PS69-DPS
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PS69-DPS

  • Manufacturer:
    ProSoft
  • Part Number:
    PS69-DPS
  • Product Family:
    ProSoft
  • Data Capacity:
    Input 408 bytes / Output 480 bytes
  • Diagnostic Interface:
    RS-232, 9600 Baud
  • Power Supply:
    Approx. 260mA @ 5V DC
  • Operating Temperature:
    0°C to +60°C
  • Relative Humidity:
    5–95% (Non-condensing)
  • Weight:
    0.16 kg
  • Estimated shipping dimensions:
    3.8x9x13cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description

The ProSoft PS69-DPS is a PROFIBUS DP V0/V1 slave module designed for Allen-Bradley CompactLogix and MicroLogix controllers.

It supports RS-485 communication up to 12Mbps, provides 408 bytes of input data and 480 bytes of output data, supports DPV0/DPV1 periodic and acyclic message communication, features a rotary switch for slave address setting, LED status indicators, and an RS-232 diagnostic interface. The module is powered by the backplane 1769 I/O bus (approximately 260mA @ 5V DC), operates at temperatures from 0°C to +60°C, and at non-condensing humidity levels of 5–95%.

It complies with EN 61000-4-4/4-5 electromagnetic compatibility standards and is C-UL, UL-508, CE, and PROFIBUS PNO certified. It is a high-reliability communication module for integrating CompactLogix/MicroLogix controllers into PROFIBUS networks.

Alternative Names
PS69-DPM MVI56E-GSC MVI56-DFCM MVI56-DFCMR MVI69-ADM MVI56-MCM MVI56-CSC MVI46-MBP
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which PROFIBUS protocols does the PS69-DPS support?
It supports PROFIBUS DP V0 and V1, enabling periodic I/O read/write and non-periodic message communication.
How do I set the PROFIBUS slave address?
Set the PROFIBUS slave address using the rotary switch on the front of the module.
Can configuration be sent from the PROFIBUS master station?
Yes, the module supports sending configurations from the master station, and it can also be manually configured via GSD files.
Are there any special slot requirements for the PS69-DPS?
It is recommended to install it in a CompactLogix I/O backplane compatible slot. Some controllers may have compatibility limitations in slot 1.
