330903-00-07-10-01-00

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 330903-00-07-10-01-00 is a 3300 XL NSv proximity probe with M8 x 1 threads, without armor, 0 mm unthreaded length, 70 mm case length and a 1.0 m (39 in) lead.
In Stock
Ships by Wednesday, September 30
Fast Shipping Available
Get a quick price for 330903-00-07-10-01-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330903-00-07-10-01-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330903-00-07-10-01-00
  • Product Family:
    3300 XL NSV Proximity Transducer System
  • Product Type:
    Proximity Probe
  • Stock:
    1
  • Thread:
    M8 x 1
  • Armor:
    Without armor
  • Unthreaded length:
    0 mm
  • Overall case length:
    70 mm
  • Total probe length:
    1.0 m (39 in)
  • Connector and cable:
    01 = ClickLoc with connector protector, standard cable
  • Agency approval:
    00 = Not required
  • System linear range:
    1.5 mm (60 mils)
  • Nominal scale factor:
    7.87 V/mm (200 mV/mil)
  • Reference target:
    AISI 4140 steel, 31 mm minimum diameter
  • System power:
    -17.5 to -26 VDC without barriers; 12 mA maximum
  • Output resistance:
    50 ohms
  • Extension-cable capacitance:
    69.9 pF/m typical
  • Maximum field-wire length:
    305 m (1000 ft)
  • Probe-to-cable pull strength:
    220 N (50 lb)
  • Connector family:
    Gold-plated brass ClickLoc
  • Relative humidity:
    100% condensing, non-submersible with protected connectors
  • Proximitor operating temperature:
    -52 to +100 C
  • Recommended field wiring:
    Three-conductor shielded triad
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Diagnostics Monitoring Connectivity

Features:

  • Uses M8 x 1 probe mounting with without armor construction.
  • Combines 0 mm unthreaded length, 70 mm case length and a 1.0 m (39 in) probe lead.
  • Terminates through 01 = clickloc with connector protector, standard cable.
The current ordering configuration is 330903-00-07-10-01-00, combining M8 x 1 mounting, without armor, 0 mm unthreaded length, 70 mm overall case and a 1.0 m (39 in) probe cable.

It senses close-clearance shaft motion for compressor vibration, axial-position, timing-reference or speed measurements through a matched 3300 XL NSv transducer system.

Before installation, verify thread engagement, insertion depth, cable type, connector protection, electrical system length, target material and the approval marked on the delivered probe.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Bently Nevada 330903-00-07-10-01-00:
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Measures radial shaft vibration in compact compressor or rotating-machine installations.
  • Tracks axial shaft position where restricted target size favors the narrow-side-view NSv system.
  • Provides Keyphasor, tachometer or zero-speed input from an appropriate rotating target.
  • Check static gap voltage before treating a channel fault as probe failure.
  • Inspect the ClickLoc junction for contamination when output becomes intermittent.
  • Compare cable resistance with the documented value for the selected probe length.
  • The matched NSv system provides a nominal 7.87 V/mm scale factor.
  • The documented linear range is 1.5 mm when tested with the stated target and supply.
  • Long field wiring can reduce high-frequency response and must remain within the published limit.
  • Gold-plated brass ClickLoc hardware locks the coaxial connection in place.
  • The cable option must match the selected NSv extension and Proximitor system length.
  • Three-conductor shielded triad is recommended between the Proximitor Sensor and monitor.
Description
330903-00-07-10-01-00 is a M8 x 1 without armor probe in the Bently Nevada 3300 XL NSv proximity transducer family. The 0 mm unthreaded section and 70 mm overall case define its fit and sensing reach.

The probe carries a 1.0 m (39 in) lead with 01 = clickloc with connector protector, standard cable. Its narrow-side-view eddy-current geometry is intended for small targets and close-clearance measurements where a standard 5 mm or 8 mm system may not fit.

When paired with the correct NSv extension cable and Proximitor Sensor, the configuration supports vibration, position and timing measurements on rotating machinery. The full ordering code must be retained because thread, armor, length, cable and approval fields are not interchangeable.
Alternative Names
330903-00-07-10-01-00 3309030007100100 330903 00 07 10 01 00 330903-00-07-10-01-00 3300 XL NSv Proximity Probe 330903-00-07-10-01-00 M8 x 1 Proximity Probe 330903-00-07-10-01-00 70 mm Unarmored Probe 330903-00-07-10-01-00 1.0 m ClickLoc Probe Bently Nevada 3300 XL NSv Proximity Transducer System
Technical notes
330903-00-07-10-01-00 requires the documented NSv system length and clean ClickLoc engagement; isolate the machine before gap or reverse-mount work.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which mounting thread is specified by 330903-00-07-10-01-00?
This configuration uses M8 x 1 mounting and must be fitted only to the matching machine port.
What case geometry does 330903-00-07-10-01-00 provide?
It combines 0 mm unthreaded length with a 70 mm overall case length.
Which cable junction belongs to 330903-00-07-10-01-00?
The official code specifies 01 = clickloc with connector protector, standard cable.
What measurements can use 330903-00-07-10-01-00?
It can serve vibration, position, speed, zero-speed or Keyphasor duties within a correctly configured NSv system.
What must be checked before replacing 330903-00-07-10-01-00?
Verify the complete code, port thread, insertion depth, system length, connector sealing and target setup.
Which record should be used to request 330903-00-07-10-01-00?
Submit the complete part number and reference Datasheet 147385 together with the installed Proximitor and quantity.
