DS200ADGIH1A
DS200ADGIH1A
DS200ADGIH1A
DS200ADGIH1A
DS200ADGIH1A
DS200ADGIH1A
Ask our team:
  • Phone: +86 181 0690 9650
  • E-Mail info@apterpower.com
  • Lifecycle status

    Discontinued / Obsolete by OEM
    Apter Power provides documentation, procurement support and system-matching guidance for General Electric DS200ADGIH1A.

DS200ADGIH1A

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric DS200ADGIH1A is an Auxiliary Genius Interface Board that connects GE drive-control communications hardware to a Genius I/O network.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for DS200ADGIH1A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DS200ADGIH1A

  • Manufacturer:
    General Electric
  • Part Number:
    DS200ADGIH1A
  • Product Family:
    GE Mark V/VI Driver Board
  • Product Type:
    Auxiliary Genius Interface Board
  • Stock:
    1
  • Functional Acronym:
    ADGI
  • Network Role:
    Genius I/O interface
  • Required Network Adapter:
    IC660ELB912 µGENI
  • Compatible Drive Control Board:
    DS200LDCC
  • Compatibility Limitation:
    Not compatible with DS200SDCC
  • Communications Context:
    Drive LAN and Genius bus integration
  • Catalog Group:
    H1
  • Board Dimensions:
    8 x 6 in (W x L)
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Genius Interface Host Matching Revision Control Applications

Features:

  • Provides the auxiliary interface path used for Genius I/O
  • Works with DS200LDCC drive control communications
  • Identifies AA as the tracked version of the base board
The ADGI interface supplies the connection point between compatible drive control hardware and the external Genius I/O arrangement.

Pairing with DS200LDCC keeps network processing with the drive communications hardware while the auxiliary board supports the Genius path.

The AA version reference distinguishes DS200ADGIH1AAA records while DS200ADGIH1A remains the published base catalog number.

The General Electric DS200ADGIH1A Auxiliary Genius Interface Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
General Electric DS200ADGIH1A Auxiliary Genius Interface Board Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Genius Network Role

  • Auxiliary path: Connects the compatible drive arrangement to a Genius I/O network.
  • µGENI board: Uses the IC660ELB912 network interface as the Genius adapter.
  • Processing boundary: Leaves communications handling with the drive control and communications hardware.
  • Interface identity: The ADGI acronym distinguishes this board from unrelated DS200 interfaces.

Required Hardware Pairing

  • Host board: Match the interface with a DS200LDCC drive control board.
  • Compatibility limit: Do not treat the board as the corresponding interface for DS200SDCC.
  • Adapter check: Confirm the IC660ELB912 µGENI board is present in the network path.
  • Cable record: Preserve connector positions before moving wiring from the installed assembly.

AA Version Identification

  • Base number: DS200ADGIH1A identifies the published board model.
  • Version code: AA maps the tracked variant to DS200ADGIH1AAA.
  • Record match: Keep both the base model and AA version in maintenance documentation.
  • Replacement check: Compare the complete installed label before transferring cables.

Drive Integration Uses

  • Genius-connected drives: Adds the auxiliary Genius interface path to compatible LDCC-based systems.
  • Cabinet restoration: Provides an exact base number for returning an existing ADGI position to service.
  • Version-controlled maintenance: Separates the AA record from other board revisions.
  • Network troubleshooting: Helps teams check the interface, µGENI adapter and host board as distinct elements.
Description
General Electric DS200ADGIH1A is an ADGI auxiliary interface board that provides the Genius bus connection used with GE drive-control communications hardware. Through this interface, the LDCC LAN Control Processor can process I/O from a connected Genius network.

The General Electric DS200ADGIH1A assembly includes one 40-pin connector, one 6-pin connector, 60 jumpers and multiple test points. These components provide the board’s signal connection, configuration and circuit-checking points.

Measuring approximately 8 inches wide by 6 inches long, General Electric DS200ADGIH1A mounts in the drive board cabinet with four aligned screws. The board operates alongside the DS200LDCC control/LAN communications board within the GE DS200 drive architecture.
Revisions

Revision Part #

Also known as

DS200ADGIH1AAA
DS200ADGIH1A-AA, Series AA, Rev AA
DS200ADGIH1AAB
DS200ADGIH1A-AB, Series AB, Rev AB
DS200ADGIH1AAC
DS200ADGIH1A-AC, Series AC, Rev AC
Alternative Names
GE DS200ADGIH1A General Electric DS200ADGIH1A DS200-ADGI-H1A DS 200 ADGI H1A DS200ADGI H1A DS200ADGIHIA GE ADGI Auxiliary Genius Interface Board DS2OOADGIH1A
Technical notes
General Electric DS200ADGIH1A is an ADGI auxiliary Genius interface board with one 40-pin connector, one 6-pin connector, 60 jumpers and multiple test points.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How can a technician confirm the correct AA-version board when the cabinet record lists General Electric DS200ADGIH1A?
Match General Electric DS200ADGIH1A to the longer DS200ADGIH1AAA identifier and record AA as the installed version before moving any cables.
Which surrounding boards must be checked before fitting General Electric DS200ADGIH1A?
General Electric DS200ADGIH1A requires the DS200LDCC drive control board and the IC660ELB912 µGENI network interface board for the documented Genius I/O arrangement.
Why might Genius I/O remain unavailable after replacing General Electric DS200ADGIH1A?
With General Electric DS200ADGIH1A installed, verify the µGENI adapter, cable placement and drive configuration because the auxiliary board does not perform all network communications by itself.
Can General Electric DS200ADGIH1A be installed with a DS200SDCC drive control board?
No. General Electric DS200ADGIH1A is matched to DS200LDCC hardware and is not the corresponding Auxiliary Genius interface for a DS200SDCC host.
What should maintenance records capture during a General Electric DS200ADGIH1A exchange?
For General Electric DS200ADGIH1A, record the AA version, DS200LDCC host, IC660ELB912 adapter and every cable position before removing the installed board.
How can teams avoid confusing General Electric DS200ADGIH1A with a generic interface card?
Use the complete General Electric DS200ADGIH1A base number, the ADGI functional acronym and the AA version reference instead of matching only the words interface board.

Product Browsing History
