          Apter Power handles IS200DRTDH1A quotations, product manuals, and Mark VI RTD terminal-board selection support.

        IS200DRTDH1A

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IS200DRTDH1A is a compact Mark VI simplex RTD terminal board that terminates eight temperature-sensor inputs and routes them to a VRTD processor through one cable.
        In Stock
        Ships by Tuesday, September 29
        Fast Shipping Available
        Get a quick price for IS200DRTDH1A
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IS200DRTDH1A

        • Manufacturer:
          General Electric
        • Part Number:
          IS200DRTDH1A
        • Product Family:
          GE Mark VI Gas Turbine Control
        • Product Type:
          Mark VI Simplex RTD Terminal Board
        • Stock:
          1
        • Input Wiring:
          Three-wire RTD circuits
        • Platinum RTD Types:
          10, 100, and 200 ohm
        • Copper RTD Type:
          10 ohm
        • Nickel RTD Type:
          120 ohm
        • Input Channels:
          8 RTD inputs
        • Processor Interface:
          One cable to VRTD
        • Maximum per VRTD:
          Two boards, 16 RTD inputs
        • Terminal Block:
          Fixed 36-position Euro-style block
        • Spare Terminals:
          25 through 34
        • Ground Terminals:
          35 and 36, SCOM
        • Mounting:
          DIN rail
        • Operating Architecture:
          Simplex
        • Compatible Processor:
          VRTD
        • PRTD Compatibility:
          Not supported
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals VRTD Compatibility RTD Channel Layout Terminal Assignments Mounting & Wiring

        Features:

        • Terminates eight three-wire RTD channels for a simplex VRTD input path.
        • Uses a fixed 36-position Euro-style terminal block in a compact DIN-rail format.
        • Connects the field terminals to the VRTD processor through one cable.
        IS200DRTDH1A provides eight RTD input circuits without the larger standard terminal-board footprint.

        Two IS200DRTDH1A boards can connect to one VRTD processor for sixteen total temperature channels.

        IS200DRTDH1A reserves terminals 25 through 34 as spares and assigns terminals 35 and 36 to SCOM ground.

        The General Electric IS200DRTDH1A Simplex RTD Terminal Board may be available for purchase and support from Apter Power for installed Mark VI systems.
        General Electric IS200DRTDH1A Simplex RTD Terminal Board Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Processor-Board Boundary

        • Processor link: One cable joins IS200DRTDH1A to a VRTD input board.
        • Board count: A VRTD can accept two DRTD boards for sixteen RTD inputs.
        • Architecture: The DRTD-to-VRTD arrangement is simplex.
        • I/O-pack limit: IS200DRTDH1A is not used with the PRTD I/O pack.

        Sensor Input Organization

        • Channel count: Eight RTD circuits terminate on each IS200DRTDH1A.
        • Field circuit: Each channel accepts a three-wire resistance-temperature sensor connection.
        • Platinum types: The connected VRTD path supports 10, 100, and 200 ohm platinum elements.
        • Other elements: The VRTD path also supports 10 ohm copper and 120 ohm nickel RTDs.

        Euro-Block Connections

        • Field block: IS200DRTDH1A uses one fixed 36-position Euro-style terminal block.
        • Active positions: The first twenty-four terminals accommodate the eight three-wire channels.
        • Spare positions: Terminals 25 through 34 are reserved.
        • Ground positions: Terminals 35 and 36 provide SCOM grounding points.

        Compact Field-Termination Format

        • Mounting: IS200DRTDH1A attaches to a DIN rail near the field wiring.
        • Terminal style: The permanent Euro block keeps the RTD conductors on the compact board.
        • Processor cable: One board-to-board cable transfers all eight channels to VRTD.
        • Shield arrangement: The compact DRTD format does not include a separate shield terminal strip.
        Description
        Eight three-wire resistance-temperature circuits terminate at General Electric IS200DRTDH1A, a compact DIN-rail terminal board for the simplex VRTD path in a Mark VI control system. One cable carries the eight field channels from the board to the VRTD processor.

        A fixed 36-position Euro-style block organizes the wiring on IS200DRTDH1A. The first twenty-four positions accommodate the eight three-wire sensor circuits, terminals 25 through 34 are spare, and terminals 35 and 36 provide the SCOM ground connection.

        Two IS200DRTDH1A boards can share one VRTD processor, increasing the terminal-board path to sixteen RTD inputs. Through VRTD, the supported sensor families include 10, 100, and 200 ohm platinum elements, 10 ohm copper elements, and 120 ohm nickel elements.

        Compatibility for IS200DRTDH1A is limited to simplex operation with VRTD. Its compact DIN-rail format differs from the standard-size TRTD assembly, and it is not the terminal board used with a PRTD I/O pack.
        Alternative Names
        GE IS200DRTDH1A RTD Terminal Board General Electric IS200DRTDH1A Simplex RTD Board IS200DRTDH1A Mark VI RTD Terminal Board IS200DRTDH1A Eight-Channel RTD Board IS200DRTDH1A DIN-Rail RTD Terminal Board IS200DRTDH1A VRTD Interface Board IS200DRTDH1A 36-Point Terminal Board IS200DRTDH1A Temperature Input Terminal Board
        Technical notes
        Designed for DIN-rail mounting, IS200DRTDH1A is a compact Simplex RTD Input terminal board that supports up to eight temperature inputs through a single cable connection to the VRTD processor.
