General Electric IC694MDL645 is a PACSystems RX3i 16-point 24 V DC positive/negative-logic input module.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for IC694MDL645
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC694MDL645

  • Manufacturer:
    General Electric
  • Part Number:
    IC694MDL645
  • Product Family:
    GE PACSystems RX3i
  • Product Type:
    24 V DC 16-Point Positive/Negative Logic Input Module
  • Stock:
    1
  • Rated voltage:
    24 V DC
  • Input voltage range:
    0 to +30 V DC
  • Input points:
    16 in one group with a single common
  • Typical input current:
    7 mA at rated voltage
  • On-state voltage:
    11.5 to 30 V DC
  • Off-state voltage:
    0 to +5 V DC
  • Minimum on-state current:
    3.2 mA
  • Maximum off-state current:
    1.1 mA
  • Typical response time:
    7 ms on; 7 ms off
  • Field-to-backplane isolation:
    250 V AC continuous; 1500 V AC for 1 minute
  • 5 V backplane consumption:
    80 mA with all inputs on
  • 24 V power consumption:
    125 mA from the isolated backplane bus or user supply
  • Point indication:
    16 green LEDs for input points 1 through 16
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Wiring Indicators Installation Application
  • Sixteen 24 V DC inputs share one commoned field group
  • Positive-logic or negative-logic wiring can be selected for the field circuit
  • Seven-millisecond typical on and off response supports general discrete sensing

IC694MDL645 is a General Electric PACSystems RX3i digital input module designed for 24 V DC field-state acquisition.

The module maps current at any of its sixteen inputs to the controller input table and provides one green status indicator for each point.

Before installation or replacement, verify the commoned-group polarity, field-device voltage and current, terminal assignments, power source, isolation requirement, and saved RX3i configuration.

Availability, condition, price, and shipping time for IC694MDL645 are confirmed during quotation.

General Electric IC694MDL645 24 V DC 16-Point Positive/Negative Logic Input Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Terminals 2 through 17 connect input points 1 through 16
  • Terminal 1 is the documented common connection for the sixteen-point group
  • Terminals 18 and 19 provide the documented 24 V OUT and 0 V OUT connections
  • Sixteen green LEDs show the on or off state of input points 1 through 16
  • Current entering an input point produces a logic 1 in the controller input-status table
  • The blue label band identifies IC694MDL645 as a low-voltage module
  • IC694MDL645 can be installed in any I/O slot of a PACSystems RX3i system
  • Remove the field-side terminal block before hot extraction and reinstall it after insertion
  • Using 24 V OUT for field devices reduces the documented isolation rating to 50 V AC continuous and 500 V AC for 1 minute
  • Pushbutton status acquisition in PACSystems RX3i machine-control systems
  • Limit-switch position feedback for discrete automation sequences
  • Electronic proximity-switch monitoring with compatible 24 V DC field circuits
Description
IC694MDL645 is a General Electric PACSystems RX3i 24 V DC positive/negative-logic input module for rack-based control systems.

The unit provides sixteen inputs in one commoned group, 0 to +30 V DC input capability, and 7 ms typical on and off response.

Before installation or replacement, confirm the complete catalog number, field polarity, single-common wiring, input-device characteristics, terminal block, power source, isolation, and saved configuration.
Revisions

Revision Part #

Also known as

IC694MDL645A
IC694MDL645-A, Series A, Rev A
IC694MDL645B
IC694MDL645-B, Series B, Rev B
IC694MDL645C
IC694MDL645-C, Series C, Rev C
IC694MDL645D
IC694MDL645-D, Series D, Rev D
IC694MDL645E
IC694MDL645-E, Series E, Rev E
Alternative Names
IC694MDL645 IC694 MDL645 IC694 MDL 645 GE IC694MDL645 General Electric IC694MDL645 GE Fanuc IC694MDL645 PACSystems RX3i IC694MDL645
Technical notes
IC694MDL645 requires one-common group polarity, terminal assignments, input-device current, field-power source, and the reduced isolation rating when 24 V OUT powers field devices to be checked before commissioning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can General Electric IC694MDL645 be wired for either positive or negative logic?
Yes. The official manual documents positive- or negative-logic wiring. Preserve the single common group and follow the applicable manufacturer field-wiring diagram.
Which field devices are documented for General Electric IC694MDL645?
The manufacturer identifies pushbuttons, limit switches, and electronic proximity switches as compatible device examples when their voltage and current characteristics match the module.
What input levels does General Electric IC694MDL645 recognize?
The documented on-state range is 11.5 to 30 V DC with at least 3.2 mA; the off-state range is 0 to +5 V DC with no more than 1.1 mA.
What changes when General Electric IC694MDL645 powers field devices from 24 V OUT?
The field-to-backplane and frame-ground isolation rating changes to 50 V AC continuous and 500 V AC for 1 minute, so the wiring and safety review must account for that reduction.
Can General Electric IC694MDL645 be removed while the RX3i backplane is energized?
Hot insertion and removal are documented only with the field-side terminal block removed before extraction and reinstalled after the module is seated.
What should be checked if one General Electric IC694MDL645 point remains off?
Compare the point LED and input table, then check the terminal assignment, common, field polarity, device output, voltage, current, and wiring continuity.
What information should accompany an inquiry for General Electric IC694MDL645?
Provide the complete catalog number, required hardware revision if applicable, field logic, input-device type, terminal-block details, power source, quantity, and clear label photographs.
