IC695RMX228

/ 4.9
1001 reviews | Need a Specific Revision?
General Electric IC695RMX228 is a PACSystems RX3i 128 MB Single-Mode Redundant Memory Xchange Module for high-availability reflective-memory links.
In Stock
Ships by Saturday, October 17
Fast Shipping Available
Get a quick price for IC695RMX228
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC695RMX228

  • Manufacturer:
    General Electric
  • Part Number:
    IC695RMX228
  • Product Family:
    GE PACSystems RX3i
  • Product Type:
    PACSystems RX3i 128 MB Single-Mode Redundant Memory Xchange Module
  • Stock:
    1
  • User Memory:
    128 MB SDRAM
  • Fiber Type:
    Single-mode
  • Connector:
    LC fiber-optic, IEC 61754-20
  • Packet Size:
    Dynamic, automatically controlled
  • Network Nodes:
    Up to 256
  • Network Interrupts:
    4 general-purpose, 32 data bits each
  • Module Interrupt:
    Programmable output
  • Memory Offset:
    Configurable by 16 MB network segments
  • Transfer Mode:
    Optional redundant transfer
  • Backplane Power:
    580 mA at 3.3 VDC; 220 mA at 5 VDC
  • Rack Location:
    Main RX3i Universal Backplane
  • Hot Insertion:
    Supported with qualified system maintenance controls
  • Tariff Code:
    8537101190
  • Country of origin:
    United States
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Single-Mode Link HA Operation Replicated Data PCI Setup

Features:

  • Extends single-mode reflective-memory links to the supported 10 km distance.
  • Creates a direct two-node optical path for RX3i CPU redundancy.
  • Replicates configured network address regions without CPU-managed copying.
The single-mode transceiver distinguishes IC695RMX228 from the multimode RMX128 when plant distance or installed fiber determines the selection.

In a dedicated redundancy path, the primary and secondary units form a closed LC fiber ring with no hub or extra reflective-memory node.

A general reflective-memory network may contain many compatible nodes, but mixed optical media requires a compatible hub that preserves the required optical conversion and ring path.

General Electric IC695RMX228 PACSystems RX3i 128 MB Single-Mode Redundant Memory Xchange Module is available for Apter Power quotation and official-documentation support.
General Electric IC695RMX228 PACSystems RX3i 128 MB Single-Mode Redundant Memory Xchange Module Manuals, Datasheets, Links
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

IC695RMX228 Single-Mode Optical Path

  • Reach: Use the specified single-mode fiber for links up to 10 km.
  • Polarity: Connect each LC transmitter to the receiver of the next node in the ring.
  • Mixed media: A compatible hub is required only when a general reflective-memory ring combines single-mode and multimode nodes.
  • Connector care: Keep LC end faces capped, clean, and within the permitted bend radius.

IC695RMX228 Redundancy Link Rules

  • Pairing: A CPU redundancy path uses one RMX228 in the primary unit and one in the secondary unit.
  • Topology: The redundancy path is a direct two-node ring with no hub or additional reflective-memory node.
  • Link count: Emerson recommends two independent redundancy links when the system architecture permits four RMX modules.
  • Transfer mode: Optional redundant transfer sends protected network traffic to reduce the chance of a dropped packet.

IC695RMX228 Replicated Memory Operation

  • Propagation: A write at one compatible node updates the corresponding address at every node in the reflective-memory ring.
  • Packet sizing: The module selects transfer packets dynamically from 4 to 64 bytes.
  • Address segmentation: Configurable offsets assign nodes to 16 MB regions of the network address space.
  • Events: Four network interrupts carry 32 data bits each, in addition to the programmable module interrupt.

IC695RMX228 Main-Rack Integration

  • Bus location: The module requires a PCI position in an RX3i Universal Backplane main rack.
  • Rack population: A main rack accepts up to six CMX/RMX modules in total, with no more than two configured as redundancy links.
  • Power calculation: Include 580 mA at 3.3 VDC and 220 mA at 5 VDC in the rail-by-rail load check.
  • Powered service: Follow the RX3i hot-insertion sequence and grounded ESD procedure before handling the optical housing.
Description
IC695RMX228 uses single-mode LC optics to carry deterministic reflective-memory traffic over an RX3i redundancy network.

Its 128 MB SDRAM exchanges automatically sized packets across a configured ring of as many as 256 reflective-memory nodes.

Four general-purpose interrupts, programmable module events, memory offsets, and network-error monitoring let the single-mode module coordinate high-availability controller data.

Install IC695RMX228 only in the main RX3i Universal Backplane PCI bus; budget 580 mA at 3.3 VDC and 220 mA at 5 VDC and use grounded ESD protection around the LC optical assembly.
Revisions

Revision Part #

Also known as

IC695RMX228AFAC
IC695RMX228-AFAC, Series AFAC, Rev AFAC
IC695RMX228AFAB
IC695RMX228-AFAB, Series AFAB, Rev AFAB
IC695RMX228AEAB
IC695RMX228-AEAB, Series AEAB, Rev AEAB
IC695RMX228ADAB
IC695RMX228-ADAB, Series ADAB, Rev ADAB
IC695RMX228ACAB
IC695RMX228-ACAB, Series ACAB, Rev ACAB
IC695RMX228ABAA
IC695RMX228-ABAA, Series ABAA, Rev ABAA
IC695RMX228AAAA
IC695RMX228-AAAA, Series AAAA, Rev AAAA
Alternative Names
IC695 RMX228 IC695-RMX228 IC695RMX-228 GE IC695RMX228 GE Fanuc IC695RMX228 General Electric IC695RMX228 PACSystems RX3i IC695RMX228 Redundant Memory Xchange Module IC695RMX228
Technical notes
The single-mode IC695RMX228 optical network must use compatible LC fiber components; its installed hardware and firmware release must remain within the compatibility table for the selected RX3i CPU.
