  • Lifecycle status

    Discontinued / Obsolete by OEM
    For C98043-A7010-L2, Apter Power supports quotations, manuals, and SIMOREG configuration matching.

C98043-A7010-L2

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens C98043-A7010-L2 is a SIMOREG DC-MASTER field-supply power section for 30 A converters, providing a 5 A rated DC field path.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for C98043-A7010-L2
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for C98043-A7010-L2

  • Manufacturer:
    Siemens
  • Part Number:
    C98043-A7010-L2
  • Product Family:
    Siemens SIMOREG DC-MASTER
  • Product Type:
    Field Supply Power Section
  • Stock:
    1
  • Converter Armature Rating:
    30 A DC
  • Field Current Rating:
    5 A DC
  • Field Input Terminals:
    3U1, 3W1
  • Field Output Terminals:
    3D, 3C
  • Thyristor Positions:
    V7, V8
  • Connector Groups:
    XF1, XF2
  • R1:
    0R1
  • R2:
    0R05
  • Gating Lead Type:
    Betatherm 145
  • Gating Lead Cross-Section:
    1 mm²
  • Tariff Code:
    8537101190
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Field Circuit Converter Wiring Quadrant Layout Replacement Checks

Features:

  • Supports the 30 A SIMOREG DC-MASTER converter class.
  • Provides a 5 A rated DC field-current path.
  • Connects the field bridge through 3U1/3W1 and 3D/3C terminals.
C98043-A7010-L2 separates the field-supply function from the converter control electronics while remaining part of the low-current power section.

The L2 coding defines the 30 A armature class, 5 A field rating, and the lower R2 resistance used by this arrangement.

Both single-quadrant and four-quadrant connection drawings place the module in the field and power-section wiring path.

The Siemens C98043-A7010-L2 Field Supply Power Section may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens C98043-A7010-L2 Field Supply Power Section Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Bridge Components and Sensing

  • Bridge Devices: V7 and V8 form the controlled field bridge.
  • Sensing Network: R1 is 0R1 and R2 is 0R05.
  • Field Rating: The DC field-current rating is 5 A.
  • Gate Leads: Betatherm 145 conductors are specified at 1 mm².

From AC Supply to DC Field

  • AC Entry: Field supply enters through 3U1 and 3W1.
  • DC Exit: Field output is presented at 3D and 3C.
  • Connector Set: XF1 and XF2 group the field-bridge connections.
  • Current Class: The L2 path is assigned to 30 A converters.

Operating-Quadrant Context

  • 1Q Drawing: The module appears in the 30 A single-quadrant connection plan.
  • 4Q Drawing: The same field section is shown for 15–30 A four-quadrant converters.
  • Primary Route: The L2 primary conductor is fed through once.
  • Power Context: Armature and field paths remain separately identified in the converter wiring.

Safe Board Change Sequence

  • Isolation: Remove power before the PCB is inserted or removed.
  • Personnel: Replacement is restricted to qualified personnel.
  • ESD: Discharge static electricity before touching the board.
  • Offset: Run P051 = 22 after replacement to reset the field-current zero point.
Description
Siemens C98043-A7010-L2 is the field-supply power section used in 30 A SIMOREG DC-MASTER converter assemblies. It carries the controlled field-current path within the drive power section and is rated for 5 A DC field current.

The field bridge on Siemens C98043-A7010-L2 is built around thyristor positions V7 and V8. Input points 3U1 and 3W1 feed the bridge, while 3D and 3C form the DC field-side terminals after the switching network.

For current handling, Siemens C98043-A7010-L2 uses an R1 value of 0R1 and an R2 value of 0R05. The L2 arrangement serves the 30 A armature-current class with its primary conductor passed once in the connection diagrams.

When Siemens C98043-A7010-L2 is replaced, power must be removed before the PCB is handled and the internal offset adjustment is repeated with P051 = 22. The adjustment re-establishes the zero point of the field-current sensing path.
Alternative Names
C98O43-A7010-L2 C98043 A7010 L2 C98043A7010L2 Siemens C98043-A7010-L2 SIMOREG C98043-A7010-L2 C98043-A7010-L2 field supply A7010-L2 power section C98043-A70I0-L2
Technical notes
Siemens C98043-A7010-L2 uses 3U1/3W1 field inputs, 3D/3C field outputs, and 0R1/0R05 sensing resistors.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How can C98043-A7010-L2 be distinguished electrically from the L1 version?
C98043-A7010-L2 is the 30 A armature / 5 A field version and uses 0R1 for R1 with 0R05 for R2.
Where does the field supply enter and leave Siemens C98043-A7010-L2?
On Siemens C98043-A7010-L2, 3U1 and 3W1 are the field inputs, while 3D and 3C are the DC field outputs.
What conductor routing is specified for the 30 A C98043-A7010-L2 arrangement?
The connection diagrams show the C98043-A7010-L2 primary conductor passing through once for the 30 A converter class.
Which switching devices belong to the field bridge on C98043-A7010-L2?
The C98043-A7010-L2 field bridge identifies thyristor positions V7 and V8.
What adjustment follows replacement of Siemens C98043-A7010-L2?
After Siemens C98043-A7010-L2 is replaced, repeat the internal offset adjustment with P051 = 22.
May C98043-A7010-L2 be removed while the converter is energized?
No. All connected supplies must be de-energized before C98043-A7010-L2 is removed or inserted.
