Features:
- Matched to a 10 kW SINAMICS Smart Line Module.
- Accepts a three-phase 380–480 V line supply.
- Provides separate screw connections for line, load, and PE conductors.
6SL3000-0CE21-0AA0 forms the passive input stage ahead of the 10 kW Smart Line Module, with its rating selected around that module size.
The reactor keeps the incoming three-phase connection, outgoing load connection, and protective-earth termination physically distinct within one component.
Its open-type protection classification and fixed mechanical envelope make enclosure planning part of the installation boundary.
The Siemens 6SL3000-0CE21-0AA0 Line Reactor for 10 kW Smart Line Module is an active Siemens product supported by Apter Power for availability and documentation assistance.
Siemens 6SL3000-0CE21-0AA0 Line Reactor for 10 kW Smart Line Module Manuals,Datasheets,Link
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
SLM Placement Logic
- Sequence: Siemens 6SL3000-0CE21-0AA0 sits between the three-phase supply and the 10 kW Smart Line Module.
- Selection Boundary: The reactor is matched to the 10 kW module size, so the line-module rating defines the component choice.
- Power Separation: The incoming line path and outgoing load path use separate connection points.
- Protective Path: PE remains independent of the active line and load conductors.
From Line Entry to Module Output
- Source Boundary: The incoming three-phase conductors terminate on the line side before power reaches the reactor stage.
- Module Boundary: The load-side terminal continues the conditioned path toward the Smart Line Module.
- Conductor Limit: The 10.00 mm² capacity applies to planning the power conductors at both sides of Siemens 6SL3000-0CE21-0AA0.
- Earth Separation: The dedicated PE screw connection is wired independently from the line and load terminals.
Panel Space and Protection
- Open-Type Boundary: The IPXXB / UL open-type classification requires the surrounding installation to provide the enclosure conditions.
- Occupied Envelope: The 177 × 196 × 110 mm body defines the component space that must be reserved in the assembly.
- Terminal Access: Panel placement must preserve access to the separate line, load, and PE screw connections.
- Component Mass: The 7.5 kg reactor weight belongs to the complete 10 kW SLM-matched unit.
Part and Rating Verification
- Part Identity: Confirm the complete 6SL3000-0CE21-0AA0 marking before matching the reactor.
- Module Match: The associated Smart Line Module rating is 10 kW.
- Supply Match: The connected source remains three-phase AC within 380–480 V.
- Construction Marking: cURus compliance accompanies the IPXXB / UL open-type configuration.
