    Apter Power offers 6SL3055-0AA00-6AA1 quotations, manuals, and SINAMICS DRIVE-CLiQ matching support.

6SL3055-0AA00-6AA1

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6SL3055-0AA00-6AA1 is a SINAMICS DMC20 hub module that adds a star-distribution point for DRIVE-CLiQ nodes.
In Stock
Ships by Tuesday, September 29
Fast Shipping Available
Get a quick price for 6SL3055-0AA00-6AA1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6SL3055-0AA00-6AA1

  • Manufacturer:
    Siemens
  • Part Number:
    6SL3055-0AA00-6AA1
  • Product Family:
    Siemens SINAMICS
  • Product Type:
    SINAMICS DMC20 DRIVE-CLiQ Hub Module
  • Stock:
    1
  • DRIVE-CLiQ Interfaces:
    X500–X505; 6 sockets
  • Additional Branch Capacity:
    5 DRIVE-CLiQ sockets
  • Network Topology:
    Star
  • Electronics Supply:
    24 VDC (20.4–28.8 VDC)
  • Current Without Nodes:
    0.15 A
  • Maximum Connector Consumption:
    2.4 A
  • Connector Loop Current:
    20 A; 15 A per UL/CSA
  • Maximum Supply Cable:
    30 m
  • MOTION-CONNECT 500 Length:
    100 m maximum
  • MOTION-CONNECT 800PLUS Length:
    75 m maximum
  • Mounting Rail:
    EN 60715 standard rail
  • PE Connection:
    M4 screw, 1.8 Nm
  • Ventilation Clearance:
    50 mm above and below
  • Status Indicator:
    Multicolor READY LED
  • RoHS Compliance:
    Since 12 February 2016
  • Weight:
    0.79 lbs (0.36 kg)
  • Estimated shipping dimensions:
    18.2×3.6×35.2 cm
  • Tariff Code:
    85049090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Star Topology Port Wiring Status Checks Rail Installation

Features:

  • Creates a star-distribution point inside a SINAMICS DRIVE-CLiQ network.
  • Adds five branch positions through the six X500–X505 sockets.
  • Permits grouped nodes to be removed without stopping the continuing data path.
The DMC20 separates one incoming communication route into organized equipment branches on the cabinet rail.

Paired supply terminals keep 24 VDC available for loop-through wiring while connected nodes add to the hub current demand.

Visual states on the READY indicator give commissioning personnel a direct view of communication, fault, and firmware conditions.

The Siemens 6SL3055-0AA00-6AA1 SINAMICS DMC20 DRIVE-CLiQ Hub Module is listed as an active product and may be available for purchase and support from Apter Power.
Siemens 6SL3055-0AA00-6AA1 SINAMICS DMC20 DRIVE-CLiQ Hub Module Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Branching Rules

  • Distribution form: One DRIVE-CLiQ line is divided in a star arrangement.
  • Axis expansion: Five sockets are available for added node subgroups.
  • Group isolation: A subgroup can be removed without interrupting the remaining line.
  • Data continuity: Communication continues for nodes outside the disconnected branch.

X500–X505 and X524

  • Data pairs: TXP/TXN and RXP/RXN carry transmit and receive signals.
  • Node power: Each DRIVE-CLiQ socket includes 24 V and electronics ground.
  • Supply input: X524 accepts 20.4–28.8 VDC for the hub electronics.
  • Loop-through: The two positive and two M terminals are jumpered in the connector.

READY Indicator States

  • Green steady: Cyclic DRIVE-CLiQ communication is active.
  • Orange steady: The communication connection is being established.
  • Red steady: At least one component fault is present.
  • Flashing states: Firmware transfer, POWER ON waiting, or component recognition is active.

Mechanical and Shielding Boundaries

  • Rail standard: The enclosure snaps onto an EN 60715 mounting rail.
  • Air space: Maintain 50 mm clearance above and below the hub.
  • Protective earth: Tighten the M4 housing connection to 1.8 Nm.
  • Cable practice: Use shielded connections and remain within the stated cable lengths.
Description
Siemens 6SL3055-0AA00-6AA1 is a SINAMICS DMC20 DRIVE-CLiQ Hub Module for cabinet installation. Mounted on a standard rail, it distributes one DRIVE-CLiQ line in a star topology and adds five sockets for further node groups.

An axis grouping gains a controlled branching point through 6SL3055-0AA00-6AA1. The hub allows connected nodes to be removed as a group without interrupting the continuing DRIVE-CLiQ line or its data exchange.

Six X500–X505 sockets on Siemens 6SL3055-0AA00-6AA1 carry transmit, receive, 24 V, and electronics-ground connections. The separate X524 connector accepts 20.4–28.8 VDC and loops the supply through its paired positive and M terminals.

Installation of 6SL3055-0AA00-6AA1 uses an EN 60715 mounting rail, an M4 protective-earth point tightened to 1.8 Nm, and shielded cabling. A multicolor READY indicator distinguishes missing supply, communication setup, cyclic operation, faults, firmware transfer, and component-recognition states.
Alternative Names
Siemens 6SL3055-0AA00-6AA1 6SL3055 0AA00 6AA1 6SL30550AA006AA1 6SL 3055-0AA00-6AA1 6SL3055-0AA00-6AA1 DMC20 SINAMICS DMC20 6SL3055-0AA00-6AA1 6SL3055-0AA00-6AA1 DRIVE-CLiQ Hub 6SL3055-0AA00-6AAl
Technical notes
Siemens 6SL3055-0AA00-6AA1 provides six DRIVE-CLiQ sockets and five added branch positions in a rail-mounted star-distribution hub.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How many new DRIVE-CLiQ branches does 6SL3055-0AA00-6AA1 add?
An axis group gains five additional branch sockets through Siemens 6SL3055-0AA00-6AA1; the DMC20 has six X500–X505 sockets in total.
Can a node group be disconnected without opening the main DRIVE-CLiQ line on Siemens 6SL3055-0AA00-6AA1?
Yes. Siemens 6SL3055-0AA00-6AA1 is designed so a grouped set of nodes can be removed while the continuing DRIVE-CLiQ line and its data exchange remain active.
Which cable families and distance limits apply around 6SL3055-0AA00-6AA1?
Use MOTION-CONNECT DRIVE-CLiQ cable with 6SL3055-0AA00-6AA1: the stated maximum is 100 m for MOTION-CONNECT 500 and 75 m for MOTION-CONNECT 800PLUS.
What cabinet clearance prevents overheating around 6SL3055-0AA00-6AA1?
Reserve 50 mm above and below 6SL3055-0AA00-6AA1 so ventilation is not restricted inside the cabinet.
The READY indicator is flashing after a firmware transfer; what should be checked on 6SL3055-0AA00-6AA1?
On 6SL3055-0AA00-6AA1, 0.5 Hz green/red flashing means firmware is downloading, while 2 Hz indicates completion and a wait for POWER ON.
How should protective earth and shielding be arranged for the DMC20 6SL3055-0AA00-6AA1?
Connect the housing PE point of 6SL3055-0AA00-6AA1 with the M4 screw at 1.8 Nm and use shielded cables with the specified shield-support arrangement.
