DSAI145-57120001-HA

/ 4.9
1001 reviews | Need a Specific Revision?
The DSAI145-57120001-HA is an analog input module belonging to ABB's S100 I/O family. It is designed for use with 800xA, Advant OCS with Master SW (MasterPiece 200/200/1), and Compact Product Suite.
Get a quick price for DSAI145-57120001-HA
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSAI145-57120001-HA

  • Manufacturer:
    ABB
  • Part Number:
    DSAI145-57120001-HA
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product ID:
    57120001-HA
  • ABB Type Designation:
    DSAI145
  • Product Type:
    Analog Input Module / I/O Module
  • Compatible Systems:
    S100 I/O, 800xA, Advant OCS with Master SW (MasterPiece 200/200/1), Compact Product Suite
  • Pain Point Solved:
    Solves the need for a spare analog input module for legacy ABB S100 I/O systems – keeping 800xA, Advant OCS, MasterPiece 200, and Compact Product Suite installations operational without a full system upgrade. Allows direct replacement of failed analog input modules in existing racks.
  • Weight:
    0.45 kg
  • Estimated shipping dimensions:
    2x24.8x24.3cm
  • Tariff Code:
    8517795000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Diagnostic Functions Installation and Upgrades

Features:

  • Designed for ABB S100 I/O systems; works with MasterPiece 200/200/1, Advant OCS, and 800xA.
  • Provides analog input capability for legacy ABB control systems; accepts signals from field transmitters and sensors.
  • Compatible with 800xA, Advant OCS with Master SW, Advant OCS with MOD 300 SW, and Compact Product Suite.
The DSAI145-57120001-HA is specifically designed for ABB's S100 I/O system, a legacy platform that was widely used with MasterPiece 200 and 200/1 controllers, as well as Advant OCS with Master SW. S100 I/O systems are still operational in many industrial plants, particularly in power generation, marine, and process industries. The DSAI145-57120001-HA serves as an analog input module within this ecosystem, converting field signals (e.g., 4‑20 mA, 0‑10 V) into digital values for the controller.

The DSAI145-57120001-HA provides analog input capability for legacy ABB control systems. Analog inputs are essential for monitoring process variables such as pressure, temperature, flow, level, and speed. The module accepts standard analog signals from field transmitters (e.g., 4‑20 mA, 0‑20 mA, 0‑10 V) and converts them into digital values that the controller can process. This allows operators to view real‑time process data, generate alarms, and implement closed‑loop control. While the exact number of channels and input ranges are not specified in this document, typical ABB S100 analog input modules offer 4, 8, or 16 channels with configurable ranges.

The DSAI145-57120001-HA is compatible with multiple ABB control system platforms, making it a versatile spare part. It is listed under categories for 800xA I/Os, Advant OCS with Master SW (including MasterPiece 200 and 200/1 controllers), Advant OCS with MOD 300 SW, and Compact Product Suite. This wide compatibility means that a single spare module can serve different system generations within the same plant. For example, a facility might have an 800xA system in one area and an older Advant OCS system in another – the same DSAI145-57120001-HA module works for both.

The DSAI145-57120001-HA ABB Analog I/O Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL)by the manufacturer (OEM).

ABB DSAI145-57120001-HA Analog I/O Module Manuals, Datasheets,Drivers,Link Important Notice:Other accessories,manuals,cables,calibration data,software,etc.are not included with this equipment unless listed in the above stock item description.All prices are shown in USD.
ABB DSAI145-57120001-HA Analog I/O Module Specs

General

  • Manufacturer ABB
  • Model DSAI145-57120001-HA
  • Condition New Original ready stock
  • Product Family DSAI110,DSAI130,DSAI133,DSAI140
Important Notice:Other accessories,manuals,cables,calibration data,software,etc.are not included with this equipment unless listed in the above stock item description.All prices are shown in USD.
  • Power Industry: Monitoring the temperature of critical points in power plant turbine bearings, generator coils, and transformers to prevent equipment overheating.
  • Petroleum and Chemical Industry: Directly collecting temperature data of Pt100 or Pt1000 RTD in reactors or precision distillation towers.
  • Metallurgy and Process Control: Monitoring the operating status of high-temperature furnaces and cooling systems to ensure process stability.
  • Line Integrity Monitoring: Equipped with open circuit and short circuit detection capabilities, the module immediately sends an alarm to the system when a fault occurs in the RTD sensor or transmission line.
  • Signal Conditioning and Filtering: Features a built-in high-resolution A/D converter (ADC) and signal conditioning circuitry, providing strong EMI (electromagnetic interference) immunity and effectively filtering noise in industrial environments.
  • Self-Diagnostic LEDs: The panel is equipped with status indicators that display the module's Run, Fault, and Warning status, allowing maintenance personnel to quickly assess hardware health.
  • Physical Installation: Supports rack or panel mounting. The module has a robust construction and can withstand industrial-grade vibration and ambient temperatures ranging from -20°C to +60°C.
  • Hot Replacement: Within the Advant system framework, hot-swap modules are typically supported. The system automatically completes configuration and communication initialization in approximately 10 seconds.
  • Modernization replacement: If an existing system needs to be upgraded, the original S100 I/O chain is usually integrated into the 800xA control system through a communication bridge (such as CI856), or replaced with an intrinsically safe temperature module of the S800 I/O series (such as AI893).
Description
When using the DSAI145-57120001-HA, engineers can connect analog field devices such as transmitters, sensors, or actuators to legacy ABB controllers. The module is part of the S100 I/O platform, which was widely used in power generation, marine, and process industries. It is classified as an I/O Module within the ABB product hierarchy.

The DSAI145-57120001-HA is compatible with multiple ABB system versions. It appears under 800xA I/Os, Advant OCS with Master SW, and Compact Product Suite categories. The document shows corrupted technical data, but the module is clearly positioned as an analog input unit for S100 I/O systems.

For legacy ABB system expansions or repairs, the DSAI145-57120001-HA provides analog input capability. As a spare part, it is intended for maintaining existing installations. Always verify compatibility with your specific controller and I/O rack before ordering. The module is subject to change without notice.
Alternative Names
DSAI110 DSAI130 DSAI133 DSAI140
Technical notes
The DSAI145-57120001-HA is an analog input module for ABB's S100 I/O system, a legacy platform used with MasterPiece 200 controllers, Advant OCS, and 800xA. Detailed electrical specifications are not provided in this document.
