IC660BRD020

/ 4.9
1001 reviews | Need a Specific Revision?
GE Fanuc IC660BRD020 is a Genius distributed I/O block with sixteen 24/48 V DC source-style circuits. Field terminals, block electronics, Genius bus communication and diagnostics are integrated in one assembly.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for IC660BRD020
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for IC660BRD020

  • Manufacturer:
    General Electric
  • Part Number:
    IC660BRD020
  • Product Family:
    GE Genius I/O
  • Product Type:
    Genius 24/48 VDC 16-Circuit Source I/O Block
  • Stock:
    1
  • Discrete circuits:
    16
  • Field voltage:
    24/48 V DC
  • Circuit style:
    Source
  • I/O architecture:
    Genius distributed I/O
  • Network:
    Genius bus
  • Electronics:
    Integrated in terminal block
  • Configuration:
    Per-circuit discrete assignment
  • Diagnostics:
    Block and circuit reporting
  • Replacement controls:
    Address, baud rate and circuit map
  • Wiring focus:
    DC supply polarity and commons
  • Weight:
    2.998 lbs (1.36 kg)
  • Estimated shipping dimensions:
    8.7 x 10 x 22.4 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication Protection Interoperability

Features:

  • Integrates sixteen discrete circuits for 24/48 V DC field service.
  • Communicates directly on the GE Genius distributed I/O bus.
  • Combines terminal wiring, electronics and block diagnostics.
The complete IC660BRD020 number identifies the source-style electrical execution. Similar Genius blocks can use different voltage or circuit polarity and are not interchangeable by enclosure appearance.

The block places discrete I/O close to the machine while a Genius bus transfers states, configuration and diagnostic information to the controller.

Capture address, baud rate and every circuit assignment before removal. Verify DC polarity and common wiring before reconnecting the terminal assembly to a replacement block.

IC660BRD020 sourcing is checked against its source-circuit execution and Genius network settings.
Verified resources for General Electric IC660BRD020:Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Distribute sixteen DC control points near machine sensors and actuators.
  • Reduce long home-run wiring by connecting field circuits directly to the Genius bus.
  • Preserve diagnostic visibility in an established GE Fanuc distributed I/O network.
  • The block exchanges I/O and diagnostic data over the Genius bus.
  • Device address and network baud rate must match the controller configuration.
  • Bus continuity, shielding and termination should be checked after any block exchange.
  • Block-level reporting identifies loss of supply, communication or internal operation.
  • Circuit diagnostics help narrow a fault to field wiring rather than the shared bus.
  • Field protection must still be coordinated with conductor and connected-load ratings.
  • Use the source-circuit version only with devices wired for the corresponding current direction.
  • The controller database must contain the same sixteen-point circuit assignments.
  • A replacement block must support the installed Genius network revision and settings.
Description
IC660BRD020 is a sixteen-circuit Genius I/O block engineered for 24/48 V DC source operation. Instead of separating field terminals from a rack-mounted electronics card, the block combines termination, discrete processing, bus interface and local diagnostic capability at the distributed installation point.

Each circuit is assigned through the Genius configuration so the block can exchange discrete states with the bus controller while reporting block and circuit conditions. The source-style electrical arrangement is a defining characteristic: it must correspond to the polarity, commons and connected field devices used by the existing machine wiring.

Replacement work should begin with a record of the device address, baud rate, circuit map and terminal conductors before the old unit is disturbed. A network scan and controlled point test are then needed to confirm bus participation, input or output behavior and diagnostic reporting without introducing a polarity error into the field supply.
Revisions

Revision Part #

Also known as

IC660BRD020F1
IC660BRD020-F1, Series F1, Rev F1
Alternative Names
IC660BRD020 GE Fanuc IC660BRD020 IC660BRD020 Genius I/O GE Fanuc Genius 24/48 VDC 16-Circuit Source I/O Block IC660BRD020 Genius 24/48 VDC 16-Circuit Source I/O Block
Technical notes
IC660BRD020 is a source-type DC block; substituting a sink execution or reversing its field supply can damage circuits and invert the intended control logic.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which network settings identify GE Fanuc IC660BRD020 on a Genius bus?
The configured device address and baud rate locate the block and must agree with the bus-controller database.
What does source style mean for GE Fanuc IC660BRD020?
Its field circuits supply current in the documented polarity arrangement, so connected loads and commons must be wired for sourcing I/O.
Can all sixteen circuits on GE Fanuc IC660BRD020 be treated identically?
No. Their individual input or output assignments and diagnostic behavior are defined by the block configuration.
Why are the terminals significant on GE Fanuc IC660BRD020?
The assembly integrates field termination with the electronics, making terminal identification and supply polarity part of the block replacement.
What test reveals a Genius dropout after fitting GE Fanuc IC660BRD020?
Check the bus controller's device table, block status and live circuit reports while verifying continuity at the network connectors.
Could a sink Genius block replace GE Fanuc IC660BRD020?
Not without redesigning and validating every field circuit because the current direction and common arrangement would differ.
