    Honeywell documentation identifies FS-IOB-0001R as the redundant backplane assembly for IOCHAS-0001R.

FS-IOB-0001R

/ 4.9
1001 reviews | Need a Specific Revision?
FS-IOB-0001R is a non-conformal-coated redundant i/o backplane for Honeywell Safety Manager systems.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for FS-IOB-0001R
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for FS-IOB-0001R

  • Manufacturer:
    Honeywell
  • Part Number:
    FS-IOB-0001R
  • Product Family:
    Honeywell Safety Systems
  • Product Type:
    Redundant I/O backplane
  • Stock:
    1
  • Backplane type:
    Redundant Safety Manager I/O
  • Associated chassis:
    IOCHAS-0001R
  • I/O connectors:
    18 × 48-pin female, slots 1–18
  • Extender connectors:
    2 × 48-pin, slots 20 and 21
  • Control bus paths:
    Separate I/O bus 1 and I/O bus 2
  • System cable interfaces:
    Nine odd-slot CN connections
  • Power interfaces:
    IP1 plus EP1–EP3
  • Configuration points:
    CA0–CA3 and watchdog grouping
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Safety & Compliance Performance & Efficiency

Product overview:

  • Backplane for IOCHAS-0001R
  • Separate I/O bus paths for Control Processors 1 and 2
  • Two IO-0001 extender connections

FS-IOB-0001R provides the electrical foundation for paired redundant I/O modules in the Safety Manager R chassis.

Odd-slot and even-slot connections follow different processor paths, so the original labeling and cable separation must be maintained.

Verified resources for FS-IOB-0001R:

Verified specifications for FS-IOB-0001R:

  • Backplane type: Redundant Safety Manager I/O
  • Associated chassis: IOCHAS-0001R
  • I/O connectors: 18 × 48-pin female, slots 1–18
  • Extender connectors: 2 × 48-pin, slots 20 and 21
  • Control bus paths: Separate I/O bus 1 and I/O bus 2
  • System cable interfaces: Nine odd-slot CN connections
  • Power interfaces: IP1 plus EP1–EP3
  • Configuration points: CA0–CA3 and watchdog grouping

Typical applications:

  • Redundant Safety Manager I/O distribution
  • Paired I/O module chassis wiring
  • Dual-processor bus separation

The backplane is intended for redundant module pairs and should be serviced as part of the complete IOCHAS-0001R assembly.

Safety and compliance:

  • Separate communication paths for two control processors
  • Power and watchdog distribution to redundant module groups
  • Fixed odd/even slot architecture

Replacement work requires controlled documentation of both processor paths to prevent crossed or incorrectly paired safety I/O connections.

Performance and efficiency:

  • Eighteen I/O positions with two extender interfaces
  • Dual I/O bus routing on one chassis backplane
  • Grouped internal and external power connections

The backplane supports efficient redundant channel organization while keeping the two controller communication paths distinct.

Description

FS-IOB-0001R is a non-conformal-coated redundant i/o backplane for the Honeywell Safety Manager platform. FS-IOB-0001R supports eighteen I/O positions arranged as redundant pairs and provides two IO-0001 extender connections for slots 20 and 21.

The backplane separates I/O bus 1 and I/O bus 2 for their respective control processors while distributing system cables, converter connections, internal and external power, addressing and watchdog signals. Confirm the complete redundant chassis wiring before replacement.

Alternative Names
FS-IOB-0001R FS IOB 0001R Honeywell FS-IOB-0001R Honeywell FS IOB 0001R Safety Manager FS-IOB-0001R FS-IOB-0001R Redundant I/O backplane FSIOB0001R Redundant I/O backplane Honeywell Safety Manager FS-IOB-0001R
Technical notes
FS-IOB-0001R is the redundant Safety Manager backplane for IOCHAS-0001R. It provides separate I/O bus paths and extender connections for slots 20 and 21.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How is FS-IOB-0001R integrated into a Safety Manager configuration?
It is used in IOCHAS-0001R with paired redundant I/O modules, two IO-0001 extenders and the IOBUS-HBR horizontal bus.
Which technical interfaces or ratings define FS-IOB-0001R?
The key documented points are Backplane type: Redundant Safety Manager I/O; Associated chassis: IOCHAS-0001R; I/O connectors: 18 × 48-pin female, slots 1–18; Extender connectors: 2 × 48-pin, slots 20 and 21. Confirm these values against the installed chassis and project hardware list.
Which compatibility checks are required before installing FS-IOB-0001R?
Confirm redundant chassis type, processor-path mapping, paired slots, two extenders, horizontal bus, system cables, power groups and address jumpers.
Which slot, bus position or chassis location is specified for FS-IOB-0001R?
Mount it at the rear of the R chassis and preserve the odd/even cable mapping to the two processor paths and extender slots.
What diagnostic symptoms can indicate a FS-IOB-0001R connection or hardware problem?
A loose system cable, power connector, converter interface or jumper on FS-IOB-0001R can affect multiple chassis slots simultaneously. Compare CN, P, IP, EP, CA and watchdog connections with the recorded wiring map.
Can FS-IOB-0001R replace a related FS, FC, S or R version directly?
IOB-0001S cannot preserve the redundant dual-bus architecture and is not a direct substitute.
Which commissioning checks should be completed after fitting FS-IOB-0001R?
Perform a point-by-point connector and jumper check, verify internal and external power groups, then confirm communication and diagnostics for every occupied I/O slot.
Which engineering data is needed to match and quote FS-IOB-0001R?
Provide the complete FS-IOB-0001R reference, controller and chassis type, Safety Manager release, slot or bus arrangement, coating requirement, existing hardware revision, required quantity and project approval requirements.
