          Apter Power can provide IC695ALG704 pricing, quotation assistance, and access to the applicable official General Electric technical documentation.

        IC695ALG704

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        General Electric IC695ALG704 is a PACSystems RX3i 4-Channel Analog Output Module for driving industrial current and voltage signals.
        In Stock
        Ships by Saturday, October 17
        Fast Shipping Available
        Get a quick price for IC695ALG704
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for IC695ALG704

        • Manufacturer:
          General Electric
        • Part Number:
          IC695ALG704
        • Product Family:
          GE PACSystems RX3i
        • Product Type:
          PACSystems RX3i 4-Channel Analog Output Module
        • Stock:
          1
        • Channels:
          4 configurable outputs
        • Signal Types:
          Current and voltage
        • Current Ranges:
          0-20 mA and 4-20 mA
        • Voltage Ranges:
          ±10 V and 0-10 V
        • Configuration:
          Software-configurable; no jumpers
        • Channel Control:
          Individual enable and disable
        • Scaling:
          Configurable scaling and offset per channel
        • Alarm Limits:
          High, low, high-high and low-low
        • Output Behavior:
          Hold Last State or configured defaults
        • Calibration:
          Full autocalibration
        • Field Power:
          External 24 VDC at terminal block
        • Terminal Blocks:
          IC694TBB032/TBB132/TBS032/TBS132
        • Estimated shipping dimensions:
          3.4 x 14.5 x 14 cm
        • Tariff Code:
          8537101190
        • Country of origin:
          United States
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Output Ranges Channel Setup Alarm Behavior Field Wiring

        Features:

        • Drives four independently selected current or voltage control loops.
        • Assigns scaling, limits, and loss-of-communication behavior to each output.
        • Uses autocalibration and output checking to expose conversion or wiring faults.
        IC695ALG704 concentrates four process outputs in an RX3i slot while allowing unrelated loop types to be commissioned separately.

        Each point receives its own engineering scale, offset, alarm thresholds, and hold-last or default response.

        The module relies on external 24 VDC field power and the approved removable terminal block selected for the enclosure wiring method.

        General Electric IC695ALG704 PACSystems RX3i 4-Channel Analog Output Module is available for Apter Power quotation and official-documentation support.
        General Electric IC695ALG704 PACSystems RX3i 4-Channel Analog Output Module Manuals, Datasheets, Links
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        IC695ALG704 Four-Loop Range Assignment

        • Independent choice: Each of the four points may be assigned a supported current or voltage span.
        • Current loop: Use the current mode for 0–20 mA or 4–20 mA devices and verify the complete loop burden.
        • Voltage load: Use the selected unipolar or bipolar voltage span only with a compatible receiving impedance.
        • Field supply: Confirm 24 VDC is present at the output terminal arrangement before testing a current command.

        IC695ALG704 Per-Channel Engineering

        • Enable state: Commission one output at a time while the remaining channels stay disabled.
        • Scale and offset: Map the application command to the required engineering range for that loop.
        • Fallback value: Choose hold-last or a defined default according to the process hazard review.
        • Download check: Verify the stored hardware configuration after any replacement or range change.

        IC695ALG704 Limit and Fault Actions

        • Alarm bands: Set high-high, high, low, and low-low thresholds in engineering units.
        • Latching option: A latched alarm remains active until the configured acknowledgement or clear action occurs.
        • Output checking: Internal supervision compares commanded and produced behavior to identify a channel problem.
        • Module status: Use the RX3i fault record to separate field-loop errors from a module-level failure.

        IC695ALG704 Four-Channel Termination

        • Block choice: Use an approved 36-point box or spring terminal assembly for the four output circuits.
        • Loop routing: Separate current-loop and voltage-output conductors from high-energy switching cable.
        • Common plan: Preserve the defined commons and field-supply return paths instead of joining them arbitrarily.
        • Replacement check: Compare every conductor label with the four-channel pin map before seating the removable block.
        Description
        IC695ALG704 provides 4 configurable outputs for current and voltage signals in an RX3i control system.

        IC695ALG704 configures each channel independently for current or voltage, scaling, offsets, alarm limits, and the required hold-last-state or default response.

        Full autocalibration, onboard checking, latching alarms, and module fault reporting give IC695ALG704 defined diagnostic behavior during process operation.

        Install IC695ALG704 with the selected removable terminal-block style, separate 24 VDC field power, and the shielding arrangement required for its four analog output channels.
        Revisions

        Revision Part #

        Also known as

        IC695ALG704ED
        IC695ALG704-ED, Series ED, Rev ED
        Get Parts Quote
        IC695ALG704EC
        IC695ALG704-EC, Series EC, Rev EC
        Get Parts Quote
        IC695ALG704DC
        IC695ALG704-DC, Series DC, Rev DC
        Get Parts Quote
        IC695ALG704CB
        IC695ALG704-CB, Series CB, Rev CB
        Get Parts Quote
        IC695ALG704BB
        IC695ALG704-BB, Series BB, Rev BB
        Get Parts Quote
        IC695ALG704AA
        IC695ALG704-AA, Series AA, Rev AA
        Get Parts Quote
        Alternative Names
        IC695 ALG704 IC695-ALG704 IC695ALG-704 GE IC695ALG704 GE Fanuc IC695ALG704 General Electric IC695ALG704 PACSystems RX3i IC695ALG704 Analog Output Module IC695ALG704
        Technical notes
        IC695ALG704 powers four field output channels from a separate 24 VDC terminal-block source; the RX3i backplane TB1 connection is not the load supply.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Why does an IC695ALG704 channel remain at its previous value after controller communication is lost?
        For IC695ALG704, the channel is configured to hold last state. Change its fault response to the required default value if the process safety review permits.
        What should be checked when IC695ALG704 reports a terminal-block fault?
        For IC695ALG704, confirm the approved removable terminal block is fully seated, its identification is supported, and the field wiring matches the four-channel pinout.
        Why is an IC695ALG704 current loop not reaching the commanded value?
        For IC695ALG704, check the 24 VDC field source, loop polarity, total load resistance, wiring continuity, and the channel’s current-range and scaling configuration.
        Can IC695ALG704 mix voltage and current outputs?
        For IC695ALG704, yes. Configure each of the four channels independently, then wire each loop for its selected range and common arrangement.
        Why does an IC695ALG704 alarm remain active after the signal returns to range?
        For IC695ALG704, a latching alarm requires the configured acknowledgement or clear action; also check the alarm deadband and limit values.
        Does IC695ALG704 support HART communication?
        For IC695ALG704, no. Use IC695ALG728 when HART communication is required on supported 4–20 mA output channels.
        What must be copied before replacing IC695ALG704?
        For IC695ALG704, record every channel range, scaling, offset, alarm, fallback value, field-supply wiring, terminal-block type, and slot assignment.
